IMPORTANT:
1. Please read the installation instructions carefully before you start.
2. For your safety and to ensure a satisfactory installation, please complete all the installation steps in the order shown below.
PRODUCT INFORMATION:
1
Mirror - Left
2
Mirror - Right
3
Short - Support Cylinder
4
Long - Support Cylinder
5
Metal Spring Washer M8
6
Socket Head Cap Screw M8*L90
7
Socket Head Cap Screw M8*L75
8
Allen Wrench 4mm
9
Allen Wrench 6mm
FUNCTION:
360°
The mirror can be rotated up and down 360°.
x1
x1
x2
x2
x4
x2
x2
x1
x1
180°
1 of 2
USAGE GUIDELINES
SKU: A3301-00203-BK
1
2
3
4
180°
The mirror can be adjusted front and back 180°.
Swinging the mirror, it can be rotated as shown
above:
Vertical installation, inclined installation and
upside-down installation. The adjustment angle is
about 180°.
5
6
7
8
9
