Joytutus A2701-16201 Usage Manual

IMPORTANT:
Before installation, please make sure that all accessories are ready. (As shown in the picture below).
PRODUCT INFORMATION:
1
Crossbar
2
Bracket
3
Hook Adjustment Rod
4
Hook Assembly
5
Rubber Strap
6
M8*25 Hand-twist Screw
7
M6*40 Hexagon Socket Head Screw
8
10*15*15.5 Sleeve
9
M8*30 Hexagonal Flange Face Bolt
10
50cm Elastic Band
11
30cm Elastic Band
Estimated installation time:
10 - 12 minutes
INSTALLATION METHOD
Remove the two original vehicle parts shown in the
1
diagram.
Remove
3 Fasten the rubber strap [5] into the hook assembly [4]
as shown in the figure. The installation method for
the other three pieces is the same.
4
5
x2
x2
x2
x4
x4
x4
x4
x4 6
x8
x2
x2
Required tools :
Remove
5
USAGE GUIDELINES
SKU: A2701 16201
1
3
7
10 11
(to be prepared by oneself)
Open-end Wrench
Use M8 bolts [9] to install the bracket [2] according to
2
the hole position. The installation method on the other
side is the same.
4 Use M6 screws [7] to fix the Step 3 assembly on the
hook adjustment rod [3], adjust it to the appropriate
position, and tighten the M6 screws [7]. The installation
method on the other side is the same.
Insert the crossbar [1] into the hook adjustment rod [3]
as shown.
7
1
4 5
8
9
2
3
3
3
2
9
3
