ASSEMBLY & INSTALLATION INSTRUCTIONS
SS-44 - 44 Inch Storm Shell TV Hard Cover &
Wall Mount
v 3.3
(TV Not Included)
If you have any questions, please contact us at
cs@stormshelltv.com, or call at (435) 752-6611 Mon – Fri
9am – 5pm (MT)
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SS-44 and is the answer not in the manual?

Questions and answers

Related Manuals for Storm Shell SS-44

Summary of Contents for Storm Shell SS-44

  • Page 1 ASSEMBLY & INSTALLATION INSTRUCTIONS SS-44 - 44 Inch Storm Shell TV Hard Cover & Wall Mount v 3.3 (TV Not Included) If you have any questions, please contact us at cs@stormshelltv.com, or call at (435) 752-6611 Mon – Fri 9am – 5pm (MT)
  • Page 2 Before getting started, let’s make sure this Storm Shell will work for you! TV SIZE & VESA PATTERN Maximum TV dimensions (including frame bezel): 41.75 in x 23.5 in x 3.75 in VESA Pattern: Width: 400 mm (15.75 in) Height: 400 mm (15.75 in)
  • Page 3 Before getting started, let’s make sure this Storm Shell will work for you! Wall Material Hardware is included for: • Drywall over Wood Studs • Solid Concrete, structural brick, or YES! masonry (minimum 8 YES! YES! inch thick) Drywall over...
  • Page 4 Installation Tools (Not Included) All Installations Phillips Screw Tape Measure Pen/Pencil Driver Power Drill Socket Wrench Bubble Level Wood Stud Installation 5/32” (4mm) and 1/4” (7mm) Wood Drill Bit Stud Finder Solid Concrete, Brick, Masonry Installation 5/32” (4mm) and 5/16” (8mm) Crescent Wrench Hammer Drill Hammer...

  • Page 5: Safety Caution

    Safety Caution • Prior to installation of this product, the installation instructions should be read and completely understood to prevent personal injury and property damage. Keep these installation instructions in an easily accessible location for future reference. • This mount and hard cover contains small parts which can act as a choking hazard if swallowed.
  • Page 6 The mounting holes must be placed over studs. If the Storm Shell placement is OK, then No Adapter Mounting Plate is required. • If you desire a different placement of the Storm Shell (left or right of the studs), an Adapter Mounting Plate is required. Mounting Holes Do...
  • Page 7 Storm Shell Front (1 PC) Storm Shell Back (1 PC) Cover Hook (2 PC) Buckle Latch (4 PC) Vertical Bracket (2 PC) TV Bracket (1 PC) Pack #1- Storm Shell Assembly Hardware M3.5x20mm M4x8mm M6x30mm D6 Washer M8x60mm (12 PC)
  • Page 8 Supplied Parts & Hardware - continued Pack #2- Mounting Bracket Hardware M4x12mm M4x30mm M6x12mm M6x30mm (4 PC) (4 PC) (8 PC) (4 PC) M8x45mm M4 Washer M8x25mm M6 Washer (4 PC) (4 PC) (4 PC) (4 PC) CAUTION! 5mm Spacer 10mm Spacer CHOKING HAZARD (4 PC)
  • Page 9 Step 1 – Prepare the Storm Shell Back 1-2 Attach Buckle Latches 1-3 Attach Cover Hooks...
  • Page 10 Wall material (cladding) is typically drywall, siding (vinyl or aluminum), stucco, brick veneer. The Storm Shell TV Wall Mount must be secured into concrete, structural brick or masonry, wood or metal studs. Do not mount CAUTION! directly into drywall or plywood.
  • Page 11 2A-2 Locate and mark three studs to mount the Storm Shell Back Mark three stud locations If you desire a different mounting position than shown (left-to- right), an Adapter Mounting Plate is required (not included). See www.StormShellTV.com/accessories Note! 2A-3 Mount Storm Shell Back •...
  • Page 12 2A-4 Mount Storm Shell Back 1.5” 5/32” • Remove Storm Shell Back and drill on top left mark with 5/32” wood drill bit 1.5” deep. 2A-5 Mount Storm Shell Back 10mm • Install C4 in top left location (leave small gap between screw head...
  • Page 13 2A-6 Mount Storm Shell Back • Hang top left key-hole on the installed C4 screw • Place bubble level on Storm Shell Back, swing so that the enclosure is level 2A-7 Mount Storm Shell Back Bubble Level • With the enclosure level, mark position of...
  • Page 14 2A-8 Mount Storm Shell Back 1.5” 5/32” • Remove Storm Shell Back and drill on top right mark with 5/32” wood drill bit 1.5” deep. 2A-9 Mount Storm Shell Back 10mm • Install C4 in top right location (leave small gap between screw head...
  • Page 15 2A-10 Mount Storm Shell Back • Hang Storm Shell Back on the two C4 screws previously mounted into the wall. 2A-11 Mount Storm Shell Back 2.5” for E4 bolt, 4” for F4 bolt 1/4” 1.5” 5/32” • Drill through two lower holes with 5/32” wood drill bit, 1.5” deep.
  • Page 16 2A-12 Mount Storm Shell Back 10mm 2A-13 Mount Storm Shell Back 13mm E4 or F4 Lag Bolts must penetrate wood studs at least 1.5 inches deep. If wall material (siding, stucco, brick veneer) is too think to allow this, longer lag bolts will be required. 8mm, 1/4”, or 5/16” lag bolts are Note! adequate.
  • Page 17 Step 2B – Concrete Wall Installation Be Aware of Electrical Conduit, Gas, or Water Pipes! CAUTION! 2B-1 1.5” 5/32” • Repeat Steps 2A-3 and 2A-4 except use a hammer drill in concrete. Use 5/32” concrete drill bit 1.5” deep. 2B-2 •...
  • Page 18 2B-3 Mount Storm Shell Back • Hang Storm Shell Back on the two C4 screws previously mounted into the wall. 2B-4 Mount Storm Shell Back 3” 5/16” 1.5” 5/32” • Drill through two lower holes with 5/32” concrete drill bit, 1.5 inches deep.
  • Page 19 2B-5 • Repeat Step 2A-13. • Install TV Bracket with J4 bolts. Tap-in J4 with hammer, then tighten nuts with crescent wrench...
  • Page 20 Step 2C – Hollow Wall Installation 2C-1 C90 (Cinder Block) Wall, or Masonry Wall Less Than 8” Thick Toggle Bolt Strap Toggle Bolt • If the C90 wall is filled with concrete, follow Step 2B • If the C90 wall is hollow, follow Step 2B except use Toggle Bolts (1/4”...
  • Page 21 Step 3 – Test Storm Shell 3-1 Before hanging TV, conduct a “wall integrity test” After mounting bracket is assembled, test bracket by putting downward pressure on bracket (equivalent to TV weight) to ensure proper installation 3-2 Install Storm Shell Front – check fit...
  • Page 22 Step 4 – Attach TV to Mounting Bracket 4-1 Select TV Screws VI - V3 - V5 - Yes! Yes! (with spacer) long short 4-2 Determine if Spacers are Needed No Spacer Needed Yes, Spacer Needed...
  • Page 23 4-3 Measure & Mark Vertical Center of TV 4-4 Determine Placement of Vertical Brackets Hooks toward top and facing out Place Vertical Brackets over VESA holes...
  • Page 24 4-5 Determine Placement of Vertical Brackets Bracket Centering Marks VESA Holes Vertical Center Mark • Place one of the “Bracket Centering Marks” over the Vertical Center Mark • Find a position where the bracket covers the VESA holes, but does not overhang the TV 4-6 Determine Placement of Vertical Brackets...
  • Page 25 4-7 Attach Vertical Brackets 4-8a Attachment without Spacers V1-6 V7-8 4-8b Attachment with Spacers V1-6 V1-6 V7-8 V7-8 V9-10 V9-10...
  • Page 26 4-9 Determine Which Hook Position to Use 4-9 Determine Which Hook Position to Use • Vertical Center Determine which Mark “Bracket Centering Mark” covers the Vertical Center Mark • Use the top hook for the top centering Bottom Hook mark, bottom hook for the bottom centering mark.
  • Page 27 4-11 Attach Securing Screws 4-12 Set TV Cables – Cut Cable Grommet...
  • Page 28 4-13 Set TV Cables...
