Summary of Contents for Hollyland Mars M1 Enhanced

  • Page 1 Mars M1 Enhanced V1.0...
  • Page 2: Table Of Contents

    Pre-sales FAQ ---------------------------------------------------------------------1 1.Parameters ----------------------------------------------------------------------1 2. Power supply --------------------------------------------------------------------2 3. The differences between M1 Enhanced and M1-3 Operation FAQ -------------------3 Operation FAQ --------------------------------------------------------------------6 1. Interference ---------------------------------------------------------------------6 2. Display abnormal issue -----------------------------------------------------------6 3. Connection ----------------------------------------------------------------------8 4. Others --------------------------------------------------------------------------9 Troubleshooting ------------------------------------------------------------------16 1. FunctionFail --------------------------------------------------------------------16 2.
  • Page 3: Pre-Sales Faq

    Pre-sales FAQ Pre-sales FAQ 1 Parameters: LOS: 150 meters. It is not recommended to use high-frequency wireless Transmission distance signal through walls as the signal strength drops significantly. HDMI input HDMI output SDI input External antenna (RP-SMI male) Ports DC in (Lock Nut) DC out...
  • Page 4: Power Supply

    Pre-sales FAQ 2 Power supply 2.1 What kinds of battery are suggested for M1 Enhanced? We suggest using SONY NP-F series batteries such as F970, F750, and F550. Alternatively, you can use a V-mount battery, but you will need to power the device via a D-Tap to DC cable. 2.2 How to check battery capacity? You can check the battery capacity of the device on the top right side of the screen.
  • Page 5: The Differences Between M1 Enhanced And M1-3 Operation Faq

    Pre-sales FAQ 3 The differences between M1 Enhanced and M1 3.1 DC port The M1 Enhanced device adopts a lock nut. 3.2 Main Menu When using the M1 as a head-monitor, it is possible to turn off the Wireless module to reduce power consumption.
  • Page 6 Pre-sales FAQ R/G/B: Supports tuning the color temperature of the screen according to the CAM image. The default value is 6500. Input: Users have two choices for the video input resource - HDMI and SDI. Especially when there are two CAMS, users can connect one with HDMI and another one with SDI, and the device will switch seamlessly.
  • Page 7 Pre-sales 3.3 Image Analysis 3D Lut: Mars M1 only supports 17/33 two sizes, Mars M1 Enhanced can support 16/17/32/33/64/65, which is more compatible with CUBE files. Zebra Pattern: Adjustable upper and lower limits value. Anamorphic: Supports customization, which allows users to define the ratio by themselves.
  • Page 8: Operation Faq

    Operaon FAQ Operation FAQ 1 Interference 1.1 The walkie talkie singal interference. Our devices are made of metal casing, so the inside circuit is not interfered by other wireless signals. However, the power of the walkie talkie is always huge, which could affect the transmission if the HDMI/SDI cable shielding properties are not good.
  • Page 9 Operaon FAQ 2.4 The camera's screen turns black when it takes 4K recording This is due to the limitation of the camera itself, which only allows one of the HDMI video output or the camera's screen display to be enabled at a time. To resolve this issue, you can try setting the shooting format to 1080.
  • Page 10: Connection

    3.3 How many smartphones/tablets could connect simultaneously? Only support when M1 Enhanced worked as transmitter Mars M1 Enhanced supports connectivity to smartphones or tablets only when it works as a transmitter. One single transmitter can connect with up to four smartphones or tablets. If there is one transmitter and one receiver, it can connect with two smartphones or tablets.
  • Page 11: Others

    4.2 How to import LUT file to Mars M1 Enhanced? To import a LUT file to the Mars M1 Enhanced, please follow the appropriate instructions. Please follow the steps below to import a 3D-LUT file (.cube) to your Mars M1 Enhanced using a USB disk: 1.
  • Page 12 Operaon FAQ 4.3 How can I use Mars M1 Enhanced to power my camera through the DC out interface? The DC OUT interface can power the camera when it is powered via an NP-F battery or through DC IN. To achieve this, you will need a 2.0mm DC port to dummy battery or a DC port to DC port cable.
  • Page 13 Operaon FAQ Overviews: Mars M1 Enhanced comes with several built-in features conveniently located at the bottom of the screen, enhancing your viewing experience. In this article, we will provide a brief overview of these features. Zebra Pattern: the Zebra Pattern tool helps you monitor exposure to your image properly by displaying a stripe pattern over a specific brightness range (IRE) on your image.
  • Page 14 Anamorphic: this feature is designed to process footage captured with an anamorphic lens, ensuring the restoration of its accurate aspect ratio. Mars M1 Enhanced supports various deformation ratios, including 1.25X, 1.33X, 1.5X, 1.6X, 1.66X, 1.78X, 1.8X, 2.0X, and custom settings.
  • Page 15 Operaon FAQ *Adjustable Intensity/Transparency/Size. *Supports LUMA/RGB modes: regular and RGB waveforms. Vectorscope: displays the colors present in an image along with their corresponding saturation levels. *Adjustable transparency and size. Histogram: show the proportional information of the exposure level in the image. 1 3 / 1 7...
  • Page 16 Operaon FAQ According to the distribution level of the histogram, you can judge whether the image is overexposed or underexposed: the left side is darker and the right side is brighter. Focus Assist: when focus assist is turned on, the selected colored lines of red, green, blue, yellow, white and black will be displayed on the sharp edge of the image.
  • Page 17 Operaon FAQ Aspect Mark: Pre-edit effect. Change the aspect ratio of the image by covering the upper and lower sides of the image according to the set aspect ratio. The transparency can be adjusted in the range of 0~100 and support set line width. Support the following ratio adjustments: off, 16: 9 | 16: 10 | 4: 3 | 2.35: 1 | 1.85:1, customization.
  • Page 18: Troubleshooting

    Troubleshooting 1 Function Fail 1.1 Factory Reset Please reset the device through click Device Reset: settings-Device Info-Factory Reset 1.2 Firmware Upgrade ● USB-C flash disk / USB flash disk + OTG convertor ● Download Upgrade File -->TBD Please follow the steps below: 1.Prepare a small USB flash drive (16/32GB) and format it as FAT32.
  • Page 19: Others

    Troubleshooting Note:It also supports manual firmware selection through Device Info > System Upgrade. 2 Others 2.1 Why can't I turn on the device using the NPF battery, but the DC adapter works perfectly? Please go to the local service center for repair. Please go local service center for repairing works 2.2 Device's casing and structure damage If you discover any damage to the device's casing, battery connectors, DC adapter ports, or...
