BASIC INFORMATION
Device Name
Domestic Trade Name
R&D Author
R&D Assessor
Product Department Assessor
Translator
Assessor
Revise
Version
Version
Producer/Modifier
No.
v1.0
蒋文辉
Note 1：'Modify the directory' & 'Main changes' should fill "no" for the first time filed
the doc;
Note 2：This form is required for each subsequent to archive
9816-B0-BB
X
MARS X
Producer/Modifier
date
2020/1/14
Mars
9816-B0-BB
蒋文辉
January 14th 2020
Alec
February 29th 2020
Lawrence
March 5
V1.0
Modify the
Main changes (Just
directory
mention main points)
No
th
, 2020
No
1
Advertisement
Related Manuals for Hollyland 9816-B0-BB Mars X
Summary of Contents for Hollyland 9816-B0-BB Mars X
- Page 1 9816-B0-BB Mars BASIC INFORMATION Device Name 9816-B0-BB Domestic Trade Name MARS X R&D Author 蒋文辉 January 14th 2020 R&D Assessor Product Department Assessor Translator Alec February 29th 2020 Assessor Lawrence March 5 , 2020 Revise Version V1.0 Version Producer/Modifier Modify the Main changes (Just Producer/Modifier date...
- Page 2 CONTENT INFORMATION DESCRIPTION Thank purchasing Hollyland MARS wireless video transmission system. The product uses the latest coding, decoding technology, and 5G wireless transmission technology and can achieve ultra-low latency wireless video transmission. MARS X transforms a tablet or a smartphone into the monitor. The device is very portable, easy to carry and operate.
-
Page 3: Packing List
PACKING LIST Transmitter Type-D to Type-A HDMI Cable Type-C to Type-A HDMI Cable User Manual Cold Shoe to 1/4"-20 Mount USB Type-A to Micro USB Adapter C-Type Screw CCU Cable (Mini USB to Mircro USB) CCU Cable (Micro USB to Mircro USB) CCU Cable (USB Type-C to Mircro USB) - Page 4 TYPICAL SETUP MARS X wireless HD video transmitter connects the interface through the HDMI Cable. It uses 5G Wi-Fi transmission technology to transmit video to your phones and/or tablets. Open the HollyView APP on your mobile device and scan the QR code on MARS X or manually input the system ID after it is connected to the device Wi-Fi by the password , then you can monitor the real-time video from the camera.
- Page 5 PRODUCT INTERFACES TRANSMITTER Multi-Functional Button USB Type-C Charging Interface Collapsible Antenna OLED Display Screen Micro USB Interface HDMI Input QR Code & Serial Number 1/4 Screw Hole 1/4 Screw Hole DEVICE INSTALLATION...
- Page 6 Adjust the antenna angle as demonstrated Mount the MARS X to the camera Long press the multi-functional button for about 3 seconds to turn the system on...
- Page 7 Caution: the USB flash should be at FAT32 or exFAT format. IOS & ANDROID APP MONITORING Android OS Installation and Use The application name is "HollyView". It is available on Hollyland's official website and Android APP store. Use methods,...
- Page 8 Method No.1 Scan the QR code on the back of the transmitter then the APP will be automatically connected to the device. Enter the main interface and you would be able to monitor the video shot on the camera. Method No.2 Input the device ID number and manually connect the device.
- Page 9 PARAMETERS Transmitter Interface HDMI Input (Type A Female) USB Type-C Power Interface Micro USB Upgrade CCU Control Interface Power Consumption <4W Work temperature -10~+60℃ Display size 0.69'' Net Weight 130g Support device 3 Device connection qty Dimension （L x W x H）: 50*90*18mm Input Video Format HDMI: 480p60...
- Page 10 Connection Issues 1. Check and make sure that the power supply functions well on the transmitter. If the display is off, long-press the multi-functional button for 3 seconds to turn the device on. 2. Check if the battery is too low. Charge the system if that is the case. 3.
-
Page 11: Fcc Requirement
FCC Requirement changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
