- Page 1 INSTRUCTION MANUAL Rev00(A) PIUC10B/PIUC10W Utility Cart support@pipishell.net (US/CA) 1-800-556-9829 www.pipishellav.com (UK) 44-808-196-3885 WWW.
- Page 2 Contents Bottom Basket Middle Basket Top Basket [A1] x [A2] x [A3] x [B] x Side Pole Long Handle Short Handle Caster with Lock [C] x [D1] x [D2] x [E1] x Caster Side Plate Hook Caddy [E2] x [F] x [G] x [H] x [I] x...
- Page 3 Step 2 Slide the side poles [C] onto the legs with the screws holes aligned. Position the middle basket [A2] in line with the holes, then insert bolts [J]. Attach nuts [K] to the bolts. Step 3 Slide handles [D1] and [D2] onto the poles. Position the top basket [A3] to line up with the holes, then insert bolts [J] through the holes.
- Page 4 Step 4 Screw the casters [E1] and [E2] into the legs [B]. NOTE: If the utility cart is not level on the floor, turn the large nuts to adjust the caster levels, then tighten the small nuts to fasten. Tighten Tighten Loosen Loosen...
