Utility Cart Instruction Manual
English
Français
Thank you for choosing this product! We strive to provide you with the best
quality products and services in the industry. Should you have any issues,
please don't hesitate to contact us at
Technical Support:
(US/CA)1-800-556-9829 Mon-Fri 8am - 8pm(CST)
(UK)44-808-196-3885 Mon-Fri 2pm - 10pm(UTC)
Other Info: support@pipishell.net
Website: www.pipishellav.com
Model: PIUC03B/PIUC03W
--------------------------- 01-03
--------------------------- 04-06
V2.0(D)
Advertisement
Table of Contents
Related Manuals for Pipishell PIUC03B
Summary of Contents for Pipishell PIUC03B
- Page 1 Utility Cart Instruction Manual V2.0(D) Model: PIUC03B/PIUC03W English --------------------------- 01-03 Français --------------------------- 04-06 Thank you for choosing this product! We strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact us at...
- Page 2 Supplied Parts and Hardware List Double Bolts Headed Bolt E 8 PCS F 4 PCS Castor with Castor without M6x10mm Wrench Allen Key Bolts Brake Brake Rivet Nut 2 PCS 2 PCS 1 PC 1 PC J 1 PC K 2 PCS L 4 PCS ASSEMBLY STEPS ②...
- Page 3 Step 3 Screw the 4 side poles [D] into the 4 double-headed bolts [E]. Then screw another 4 double-headed bolts [E] to the top of the side poles [D] ②] and slide the second basket [A to the double-headed bolts. Finally screw another 4 side poles [D] into the 4 double-headed bolts [E].
- Page 4 Step 5 Insert the four rivet nuts [L] into the four holes on the bent tubes [B②]. Fix the rivet nut [L] using Allen key [J] while screwing the castor [G] onto the rivet nut [L] using wrench [H]. Or fix the castor using wrench [H] while tightening the rivet nut [L] using Allen key [J].
- Page 5 List des matériels et pièces Poteau Panier tube coudé Boulon Boulon à Boulon latéral double tête E 8 PCS F 4 PCS Avec Sans M6x10mm Clé clé Allen Boulon roulette frein roulette frein Écrou rivet 2 PCS 2 PCS 1 PC 1 PC J 1 PC K 2 PCS...
- Page 6 Étape 3 Visser les quatres poteaux latéraux [D] dans les quatres boulons à double tête [E], puis visser les autres quatres boulons à double tête [E] dash la partie supérieure des poteaux latéraux [D] et baisser la deuxième panier dans les boulons à double tête. Au final, visser les autres quatres poteaux latéraux [D] dans les quatres boulons à...
- Page 7 Étape 5 Insérer les quatres écrous rivet [L] dans les quatres trous des tubes coudés [B②]. Fixer l’écrou rivet en utilisant clé Allen [J] lors que visser la roulette [G] dans l’écrou rivet [L] en utilisant clé [H]. Ou fixer la roulette en utilisant clé...
- Page 8 If you have any questions please don't hesitate to contact us at Technical Support: (US/CA)1-800-556-9829 Mon-Fri 8am - 8pm(CST) (UK)44-808-196-3885 Mon-Fri 2pm - 10pm(UTC) Other Info: support@pipishell.net Website: www.pipishellav.com...
