PowerTec 71080 Instruction Sheet

INSTRUCTION SHEET
Center Finder
QUESTION...
1•847•780•6120
• Used to find the center on circular, square
and octagon shaped stock up to 8" and on
hexagonal shaped stock up to 5-3/4"
PACKAGING CONTENTS
1 - Center finder
TO USE
NOTE: The center finder features two V-stops,
one on either side, for enhanced versatility.
The 60° V-Stop side is ideal for circular and
hexagonal shapes. The 90° V-Stop is great for
square, octagonal and circular shapes as well.
1. Slide the stock firmly into the center finder
against the V-stop.
2. Score the first line using the straight edge
as a guide.
Visit us on the web at powertecproducts.com
Put these instructions and the original sales invoice in a safe,
Southern Technologies, LLC
Waukegan, IL 60087
3. Rotate the stock 90° and score the
second line.
4. Remove the stock. The point where
the two lines intersect is the center of
the stock.
NOTE: On ovals and rectangles, move the
stock up in the V-Stop to accommodate for the
longer side and shape.
dry place for future reference.
MODEL NO. 71080
19-0626
