INSTRUCTION SHEET
Precision Square
Measurement Ruler for
Measuring and Marking
Each kit contains:
1 - Square
1 - Pentel®* 0.5 mm pen
1 - Hex wrench
* Pentel is the trademark of PENTEL KABUSHIKI KAISHA.
These instructions cover these models:
Imperial
71532 Precision Square 8" Measurement Ruler for Measuring and Marking
71533 Precision Square 12" Measurement Ruler for Measuring and Marking
Outside of Square
Inside
of
Square
Handle
QUESTION...
1•847•780•6120
Imperial graduations are
marked on the outside and
inside in 1/32" increments
Two rows of staged
holes allow marking
points or lines
1/8" apart, 1/16"
apart, if the holes
are staggered
as shown
Metric
71534 Precision Square 200 mm Measurement Ruler for Measuring and Marking
71535 Precision Square 300 mm Measurement Ruler for Measuring and Marking
Outside of Square
Inside
of
Square
Handle
Metric graduations are
marked on the outside and
inside in 1 mm increments
Two rows of staged
holes allow marking
points or lines 2 mm
apart, 1 mm apart,
if the holes are
staggered as shown
Advertisement
Related Manuals for PowerTec 71534
Summary of Contents for PowerTec 71534
- Page 1 INSTRUCTION SHEET Metric 71534 Precision Square 200 mm Measurement Ruler for Measuring and Marking QUESTION... 71535 Precision Square 300 mm Measurement Ruler for Measuring and Marking Precision Square 1•847•780•6120 Measurement Ruler for Metric graduations are marked on the outside and...
- Page 2 RESET THE SQUARE • The outside of square can be used as a butt square to verify 90° angles. Examples: The square's blade is accurately machined building furniture, setting 90° on a table saw and checking 90° angles on other items. from a single piece aluminum and the cast aluminum handle is machined and set to •...
