Product Specifications

Stereo Power:
Bridged Mono Power:
Output Voltage RMS
8Ω and 4Ω Stereo Power ratings @1kHz, <0.05% THD+N both channels driven 2Ω stereo & 4Ω Bridged Mono Power ratings @1 kHz, <0.1%THD+N
Frequency Response:
Power Bandwidth:
Damping factor:
Input CMRR:
Gain:
Input Sensitivity (x40) 4Ω rated power
+/-3%:
Input Impedance
Hum and Noise A-weighted @ 8Ω rated
power
Crosstalk 1kHz @ 8Ω rated power
Class
Power Supply
Current Draw @ 120 VAC
Thermal Emissions 1/3 power, 4Ω
Bridged BTU/hr
Cooling
Input connectors
Output connectors
Controls
LED indicators
Construction
Dimensions
Weight
Architects' & Engineers' Specifications:
The power amplifier shall consist of 2 channels. Each channel will delver a minimum of (290 / 590 / 825 / 1300) watts at 8 ohms, (525 / 1000 / 1450 / 2200) watts at 4 ohms, (850 / 1650 / 2250
/ 3250) watts at 2 ohms, 20 Hz – 20 kHz. In Bridged mono mode, it will deliver a minimum of (1050 / 2000 / 2900 / 4400) at 8 ohms, (1700 / 3300 / 4500 / 6500) at 4 ohms, 20Hz – 20 kHz. It
shall weigh 24 lbs. The amplifier shall incorporate protection circuitry against output short circuits, DC voltage on outputs, thermal overload and load protection due to any form of amp failure. It
will include impedance sensing circuitry, a RMS clip limiter and Autoramp signal control. The amplifier shall have a sensitivity of 1.12 / 1.58 / 1.87 / 2.35 volts (x40) at the input, which will deliver full
rated output power in any output configuration. Gain can be changed to x20. The hum and noise level shall be greater than (-110 dB / -110 dB / -110 dB / -113 dB) "A" weighted. The amplifier
shall have a class (A / B, H, H, H) output stage with a switch power supply. The frequency response shall be greater than 10 Hz – 100 kHz +0, -2 dB at1 watt at full rated output power @ 4
ohms .05% THD. The amplifier will operate at either 120 VAC, 60 Hz (safe operating range 100-132 VAC) or at 230 VAC, 50 Hz (safe operating range 200-264), voltage selection determined at
factory. Maximum current draw at 120 V shall be no greater then 30amps, both channels driven continuously into a 2 ohm load at 1/8 power. Front panel indicators shall include LED indicators
for signal present, ACL (automatic clip limiting), Temp, and Active status. Front panel attenuators will be recessed and detented. Input connectors shall be XLR per channel. Output connectors
shall be 5-way binding posts and Speakon®, per channel. The packaging of the amplifier shall allow for standard rack mounting without requiring space between similar units as long as the rack is
properly ventilated. Dimensions main chassis shall be 19" wide (483mm), 12.25" deep (311mm), 3.5" high (89mm). The amplifiers shall be designated the Crest Audio model Pro 5200.
*Five Year warranty for the United States
Logo referenced in Directive 2002/96/EC Annex IV
(OJ(L)37/38,13.02.03 and defined in EN 50419: 2005
The bar is the symbol for marking of new waste and
is applied only to equipment manufactured after
13 August 2005
5200
8Ω 290 W
4Ω 525 W
2Ω 850 W
8Ω 1,050 W
4Ω 1,700 W
52 V
1.12 V
>-110 dB
>-65 dB
A/B
1/8 power 4Ω
875 W 7.3 A
2Ω 1,380 W 11.5 A
1/3 power 4Ω 1,310 W 10.9 A
2Ω
2,100 W 17.5 A
7,165
Front panel:
Rear panel:
Crest Audio reserves the right to make improvements in manufacturing or design which may affect specifications.
7200
590 W
1,000 W
1,650 W
2,000 W
3,300 W
75 V
10 Hz – 100 kHz; +0, -2 dB at 1 watt
10 Hz – 35 kHz; +0, -2 dB at rated 4Ω power
>300:1 8Ω @ 20 Hz to 1kHz
> -85 dB @1kHz
selectable between x40 (32 dB) and x20 (26 dB)
1.58 V
15kΩ Balanced
>-110 dB
>-70 dB
H
875 W 7.3 A
1,400 W 11.7 A
2,500 W 20.8 A
3,900 W 32.5 A
13,308
Speakon ® connectors and five-way binding post
twin recessed stepped attenuators, circuit breaker/power switch
Signal presence, ACL™ (Active clip limiting), Active status, Temp
3.5" x 19" x 12.25" (13.75" to rack ears) 89 mm x 483 mm x 311 mm (349 mm to rack
ver 1.0 09/22/05
711 A Street, Meridian, MS 39301 USA • TEL: 866.812.7378 • FAX: 601.486.1380 • www.crestaudio.com
Pro 200™ Series
8200
825 W
1,450 W
2,250 W
2,900 W
4,500 W
90 V
1.87 V
>-110 dB
>-70 dB
H
Switched Mode
1,250 W 10.5 A
1,875 W 15.7 A
3,050 W 25.4 A
4,350 W 36.25 A
14,843
Back to front via 2 variable speed fans
Balanced female XLR
mode select, gain select
Aluminum Chassis
ears)
24 lbs. (10.9 kg)
9200
1,300 W
2,200 W
3,250 W
4,400 W
6,500 W
113 V
2.35 V
>-113 dB
>-70 dB
H
2,200 W 18.4 A
3,350 W 27.9 A
5,000 W 41.7 A
7,300 W 60.9 A
24,909
®
