Crest Audio PRO 5200 Feature Overview

Power Specifications
8Ω, 4Ω Stereo and 8Ω Bridged Mono Power ratings @ 1 kHz, <.05% THD+N both channels driven. 2Ω stereo and 4Ω Bridged Mono Power ratings @ 1kHz, <. 1% THD+N
FEATURE OVERVIEW:
• Dramatically reduced net weight
• Latest generation of high speed, wide-bandwidth
output devices
• Dual, variable speed fans
• Balanced XLR inputs
• Speakon® and 5-way binding post speaker outputs
• Mode selector switch for stereo, parallel and bridged-
mono operation
• Input sensitivity selection
• Recessed, stepped attenuators
• Front panel circuit - breaker switch
• Five year warranty*
TOURCLASS/PROTECTION CIRCUITS
ACL™ (Active Clip Limiting) prevents speaker damage by
providing gentle gain reduction when the signal approaches the
clipping threshold.
IGM™ (Instantaneous Gain Modulation) monitors speaker
loads to detect conditions that may overstress output devices. This
allows safe operation into nominal 2Ω speaker loads.
8Ω stereo*
9200 1,300 W
8200 825 W
7200 590 W
5200 290 W
Pro 5200/7200/8200/9200
Power Amplifiers
4Ω stereo* 2Ω stereo*
2,200 W 3,250 W
1,450 W 2,250 W
1,000 W 1,650 W
525 W 850 W
AUTORAMP™ gradually increases gain to the attenuator level
settings when the amplifier is turned on. This prevents abrupt turn-on
level.
Other protection features include: short circuit, DC voltage,
comprehensive thermal management and current in-rush turn-on/off;
transient sub-sonic input.
DESCRIPTION
Crest Audio Pro 200 Series amplifiers are designed to achieve
unsurpassed sonic performance and long-term reliability under
extreme stress in touring or fixed installation applications.
Absolute sonic accuracy is the hallmark of every Crest
amplifier. Bass is solid and defined to the limits of audibility
with ample current reserves. Wide-bandwidth output devices
ensure detailed, transparent high frequency response. And,
thanks to Crest's exclusive IGM
will drive 2Ω loads safely without compromising performance.
Pro 200™
S E R I E S
(Pro 8200 shown)
8Ω bridged**
4Ω bridged**
4,400 W 6,500 W
2,900 W 4,500 W
2,000 W 3,300 W
1,050 W 1,700 W
circuit, the Pro 200 Series
™
®
