Cisco Business 145AC Quick Start Manual

Q U I C K STA RT G U I D E
What's in the Box
Cisco Business 145C Access Point
●
Mounting Kit
●
Ethernet Cable
●
Quick Start Guide
●
Technical Support Contact List
●
Pointer Card China RoHS
●
Compliance Information (for EU SKU
●
only)
First, You'll Need...
Cisco Business 145AC Access Point | Quick Start Guide
Cisco Business 145AC Access Point
Thank you for choosing the Cisco Business 145AC Access Point. This access point can be used to
create a new wireless network or added to an existing network to expand coverage.
This Quick Start Guide will get you up and running in no time.
1 2
An active Internet connection
●
A phone with Wi-Fi capability (not
●
connected to an active wireless network)
3 4 5
A PoE (Power over Ethernet) switch, router or PoE injector
●
(802.3af) to supply power to the access point.
A router (to act as your DHCP Server).
●
Product Features
Pass-Thru Port
1
LAN3
2
6
Status LED
3
LAN2
4
7
8
PSE-LAN1
5
6 Mode Button
9
PoE (Power over Ethernet)-In Port
7
(Ethernet Uplink Port)
8 Pass-Thru Port
Kensington Lock (Located on the side)
9
