Cisco Business 140AC Quick Start Manual

Q U I C K STA RT G U I D E
What's in the Box
Cisco Business 140AC Access Point
●
Mounting Kit
●
Ethernet Cable
●
Quick Start Guide
●
Technical Support Contact List
●
Pointer Card China RoHS
●
Compliance Information (for EU SKU only)
●
First, You'll Need...
Cisco Business 140AC Access Point | Quick Start Guide
Cisco Business 140AC Access Point
Thank you for choosing the Cisco Business 140AC Access Point. This access point can be used to
create a new wireless network or added to an existing network to expand coverage.
This Quick Start Guide will get you up and running in no time.
2 3
CONSOLE POE
1
An active Internet connection
●
A phone or tablet with Wi-Fi capability (not
●
connected to an active wireless network)
4
5
6
A PoE (Power over Ethernet) switch, router or PoE injector
●
(802.3af) to supply power to the access point.
A router (to act as your DHCP Server).
●
Product Features
Status LED
1
RJ-45 Console Port
2
(For tech support only)
PoE (Power over Ethernet)-In Port
3
(Ethernet Uplink Port)
4 Mode Button
Security Screw Hole
5
Mounting Bracket
6
