  • Page 1 Product Manual SV35.2 Series PATA ® ST3750640AV ST3500630AV ST3320620AV ST3250820AV ST3160815AV 100440155 Rev. E December 2007...
  • Page 2: Revision History

    United States and/or other countries. SV35 Series, SeaTools and SeaTDD are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
  • Page 3: Table Of Contents

    Seagate Technology support services ........
  • Page 4 SV35.2 Series PATA Product Manual, Rev. E...
  • Page 5: List Of Figures

    List of Figures Figure 1. Typical 5V startup and operation current profile ........12 Figure 2.
  • Page 6 SV35.2 Series PATA Product Manual, Rev. E...
  • Page 7: Introduction

    Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate ® SV35.2 Series PATA model drives: ® ST3750640AV ST3500630AV ST3320620AV ST3250820AV ST3160815AV These drives provide the following key features: • 7,200-RPM spindle speed • High instantaneous (burst) data transfer rates (up to 100 Mbytes per second) using Ultra DMA mode 6.
  • Page 8 SV35.2 Series PATA Product Manual, Rev. E...
  • Page 9: Drive Specifications

    Drive specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models: ST3750640AV ST3500630AV ST3320620AV ST3250820AV ST3160815AV Specification summary table...
  • Page 10 Table 1: Drive specifications summary for 750 and 500 Gbyte models Drive specification ST3750640AV ST3500630AV Formatted capacity (512 bytes/sector)* 750 Gbytes 500 Gbytes Guaranteed sectors 1,465,149,168 976,773,168 Heads Discs Bytes per sector Default sectors per track Default read/write heads Default cylinders 16,383 Recording density 926 kbits/in max...
  • Page 11 To determine the warranty for a specific drive, use a web browser to access the following web page: www.seagate.com/support/service/ From this page, click on the “Verify Your Warranty” link. You will be asked to provide the drive serial number, model number (or part number) and country of purchase.
  • Page 12 Drive specifications summary Table 2: for 320, 250 and 160 Gbyte models Drive specification ST3320620AV ST3250820AV ST3160815AV Formatted capacity (512 bytes/sector)* 320 Gbytes 250 Gbytes 160 Gbytes Guaranteed sectors 781,422,768 488,397,168 312,581,808 Heads Discs Bytes per sector Default sectors per track Default read/write heads Default cylinders 16,383...
  • Page 13 To determine the warranty for a specific drive, use a web browser to access the follow- ing web page: www.seagate.com/support/service/ From this page, click on the “Verify Your Warranty” link. You will be asked to provide the drive serial number, model number (or part number) and country of purchase. The sys- tem will display the warranty information for your drive.
  • Page 14: Formatted Capacity

    Formatted capacity Formatted Guaranteed Model capacity* sectors Bytes per sector ST3750640AV 750 Gbytes 1,465,149,168 ST3500630AV 500 Gbytes 976,773,168 ST3320620AV 320 Gbytes 781,422,768 ST3250820AV 250 Gbytes 488,397,168 ST3160815AV 160 Gbytes 312,581,808 *One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environ- ment and formatting.
  • Page 15: Recording And Interface Technology

    Recording and interface technology 750GB 500GB 320GB 250GB 160GB Interface Recording method Perpendicular Recording density, KBPI (kbits/inch max) Track density, KTPI (ktracks/inch avg) 137.259 Areal density (Gbits/inch avg) 128.2 114.4 Spindle speed (RPM) (± 0.2%) 7,200 Internal data transfer rate (Mbits/sec max) 1,030 Sustained data transfer rate (Mbytes/sec max) I/O data-transfer rate (Mbytes/sec max)
  • Page 16: Seek Time

    Seek time Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using drive diagnostics. The specifications in the table below are defined as follows: • Track-to-track seek time is an average of all possible single-track seeks in both directions. •...
  • Page 17 Operating power is measured using 40 percent random seeks, 40 percent read/write mode (1 write for each 10 reads) and 20 percent drive idle mode. • Idle mode power Idle mode power is measured with the drive up to speed, with servo electronics active and with the heads in a random track location.
  • Page 18: Conducted Noise

    2.8.1.1 Typical current profile Figure 1 Typical 5V startup and operation current profile Figure 2 Typical 12V startup and operation current profile 2.8.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12 volt line or an equivalent 15-ohm resistive load on the +5 volt line.
  • Page 19: Power Management Modes

    2.8.4 Power management modes The drive provides programmable power management to provide greater energy efficiency. In most systems, you can control power management through the system setup program. The drive features the following power management modes: Power mode Heads Spindle Buffer Active Tracking...
  • Page 20: Environmental Specifications

    Environmental specifications 2.9.1 Ambient temperature Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Actual drive case temperature should not exceed 69°C (156°F) within the operating ambient conditions. Rec- ommended measurement locations are shown in See Figure 6 on page 25. Above 1,000 feet (305 meters), the maximum temperature is derated linearly to 112°F (44°C) at 10,000 feet (3,048 meters).
  • Page 21: Shock

    2.9.5 Shock All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws. Shock may be applied in the X, Y or Z axis. 2.9.5.1 Operating shock These drives comply with the performance levels specified in this document when subjected to a maximum operating shock of 63 Gs based on half-sine shock pulses of 2 msec.
  • Page 22: Acoustics

    2.10 Acoustics Drive acoustics are measured as overall A-weighted acoustic sound power levels (no pure tones). All mea- surements are consistent with ISO document 7779. Sound power measurements are taken under essentially free-field conditions over a reflecting plane. For all tests, the drive is oriented with the cover facing upward. Note.
  • Page 23: Reliability

    EN 55024. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives.
  • Page 24: Fcc Verification

    As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disc drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.
  • Page 25: European Union Restriction Of Hazardous Substances (Rohs)

    Lead (Pb), in electronic products effective July 2006. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the rep- resentations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our...
  • Page 26 SV35.2 Series PATA Product Manual, Rev. E...
  • Page 27: Configuring And Mounting The Drive

    Configuring and mounting the drive This section contains the specifications and instructions for configuring and mounting the drive. Handling and static discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic dis- charge (ESD) hazards. Observe the following standard handling and static-discharge precautions: Caution: •...
  • Page 28: Breather Filter Hole Precautions

    Breather filter hole precautions This section contains information regarding the precautions which should be taken regarding the breather filter hole in Seagate hard disc drives. Proper precautions should be taken to ensure full functionality and prevent possible damage to the drive.
  • Page 29: Jumper Settings

    Jumper settings 3.3.1 Master/slave configuration The options jumper block shown in Figure 4 is used to configure the drive for operation. It is the 8-pin dual header between the interface connector and the power connector. Use the following settings to configure the drive as a master or a slave.
  • Page 30: Ultra Ata/100 Cable

    3.3.3 Ultra ATA/100 cable An 80-conductor 40-pin cable is required to run Ultra DMA mode 3, mode 4, and mode 5. This cable uses even-numbered conductors connected to the ground pins to improve signal integrity. Note. If you are using a 40-pin, 80-conductor cable, attach the blue connector to the motherboard, the black connector to the Master...
  • Page 31: Figure 6 Mounting Dimensions-Top, Side And End View

    Notes: 1. Dimensions are shown in inches (mm). 2 Dimensions per SFF-8301 specification. 0.228 0.178 2.23 (5.79) (4.27) (56.56) 1.028 max 2.83 (26.11) (71.80) 3 x 0.25 0.010 3.71 (6.35 0.037) (94.35) both sides 1.122 0.02 1.625 0.020 (28.5 0.51) (41.28 0.51) 1.638...
  • Page 32 SV35.2 Series PATA Product Manual, Rev. E...
  • Page 33: Ata Interface

    ATA interface These drives use the industry-standard ATA task file interface that supports 16-bit data transfers. It supports ATA programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–5. The drive also supports the use of the IORDY signal to provide reliable high-speed data transfers. You can use a daisy-chain cable to connect two drives to a single AT host bus.
  • Page 34: Supported Ata Commands

    4.1.1 Supported ATA commands The following table lists ATA-standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Draft ATA-7 Standard. See “S.M.A.R.T. commands” on page 34 for details and sub- commands used in the S.M.A.R.T. implementation. Table 6: Supported ATA commands Command name...
  • Page 35 Command name Command code (in hex) Security Erase Unit Security Freeze Security Set Password Security Unlock Seek Set Features Set Max Address Note: Individual Set Max Address Address: commands are identified by the value Password: placed in the Set Max Features regis- Lock: ter as defined to the right.
  • Page 36: Identify Device Command

    4.1.2 Identify Device command The Identify Device command (command code EC ) transfers information about the drive to the host following power up. The data is organized as a single 512-byte block of data, whose contents are shown in the Table 6 on page 28.
  • Page 37 2.2 for related information). These words are required for drives that ST3500630AV = 976,773,168 support the 48-bit addressing feature. Maximum value: ST3320620AV = 781,422,768 0000FFFFFFFFFFFFh. ST3250820AV = 488,397,168 ST3160815AV = 312,581,808 104–127 ATA-reserved 0000 Security status 0001 129–159 Seagate-reserved xxxx 160–254 ATA-reserved 0000 SV35.2 Series PATA Product Manual, Rev. E...
  • Page 38 Word Description Value Integrity word xxA5 Advanced Power Management (APM) and Automatic Acoustic Management (AAM) features are not supported Note. See the bit descriptions below for words 63, 88, and 93 of the Identify Drive data: Note. Description (if bit is set to 1) Word 63 Multiword DMA mode 0 is supported.
  • Page 39: Set Features Command

    4.1.3 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an inter- rupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. Power-on default has the read look-ahead and write caching features enabled.
  • Page 40: Commands

    ) that elimi- nates unnecessary drive returns. The diagnostic software ships with all new drives and is also available at: http://seatools.seagate.com. This drive is shipped with S.M.A.R.T. features disabled. You must have a recent BIOS or software package that supports S.M.A.R.T. to enable this feature. The table below shows the S.M.A.R.T. command codes that the drive uses.
  • Page 41: Seagate Technology Support Services

    Seagate Service Centers Presales Support Our Presales Support staff can help you determine which Seagate products are best suited for your specific application or computer system, as well as product availability and compatibility. Technical Support Seagate technical support is available to assist you online at support.seagate.com...
  • Page 42 Seagate Customer Service Operations (CSO) representative for warranty- related issues. Resellers or end users of drive products should contact their place of purchase or Seagate warranty service for assistance. Have your serial number and model or part number available.
  • Page 43 Index Device Configuration Restore 28 Device Configuration Set 28 Device Reset 28 diagnostic software 1 dissipation 11 acoustics 16 Download Microcode 28 Active mode 13 drive diagnostics 10 AFR 17 drive monitoring 1 agency certification (regulatory) 17 drive self-test 1 altitude 14 DST 34 ambient conditions 3...
  • Page 44 Idle and Standby timers 13 pins 27 Idle Immediate 28 PIO 27 Idle mode 13 power consumption 10 Idle mode power 11 power dissipation 11 IEC950 17 power management 13 Information Technology Equipment 17 power specifications 10 Initialize Device Parameters 28 power-management modes 13 interface 9 Power-on to Ready 10...
  • Page 45 S.M.A.R.T. Read Attribute Thresholds 29 track-to-track seek time 10 S.M.A.R.T. Read Data 29 S.M.A.R.T. Read Log Sector 29 S.M.A.R.T. Return Status 29 UL 1950 17 S.M.A.R.T. Save Attribute Values 29 Ultra ATA/100 24 S.M.A.R.T. Write Log sector 29 Ultra DMA 24 safety certification 17 screws 24 SeaTools 1...
  • Page 46 SV35.2 Series PATA Product Manual, Rev. E...
