Pyle PMP52BT Quick Manual

BLUETOOTH MEGAPHONE
Professional Compact Power Megaphone
QUICK GUIDE
This user manual contains important information for safe operation and optimal megaphone performance. Please carefully read and follow
safety notes and instructions. Save this manual for future reference. Make sure that it is available to all persons using this device.
SAFETY
This megaphone is intended to be used only as described in this user
manual. Any other use or use under other operating conditions is consid-
ered to be improper and may result in personal injury or device damage.
Please use the megaphone as described and under supervision if used
by children or minors.
• Ensure that plastic bags, packaging, etc.
• Never let children unattended use electrical devices.
• Use proper polarity is observed when inserting batteries.
• Incorrectly inserted batteries may cause damage and risk of fire.
• Leaking batteries can cause permanent damage to the device.
• Remove batteries if the megaphone will not be used for long periods of
time.
OPERATING INSTRUCTIONS
Use the sliding switch to choose between the (3) PA Modes: Speak,
Siren, USB/SD/BT/AUX
Speak: While in 'Speak Mode', speak through the microphone
mouthpiece while holding the 'Press to Talk' button on the detachable
handheld differential mic. The user also has the ability to use the 'PA Talk
Trigger Switch' on the megaphone's handheld pistol grip.
Siren: Slide the switch over to 'Siren' and an automatic, continuous
alarm siren plays. Switch to another mode to discontinue the alarm siren
play.
USB/SD/BT/AUX: Slide the switch over to 'USB/SD/BT/AUX' to project
externally connected devices or digital media files, via inserted USB
Flash or SD Memory Card, through the megaphone. Control your media
with the previous, next, play/pause buttons.
Adjust volume control located on the right hand side of the removable
differential microphone.
BATTERY INSERTION
Unfasten the clip located near the top, back-side of the unit.
The clip will release the lid to reveal the battery compartment.
Please see correct battery direction placement on the top
side of the opening battery compartment lid. Insert batteries,
close the cover and fasten clip until locked.
NOTE: Make sure the batteries are inserted correctly
observing correct polarity.
Model: PMP52BT
BLUETOOTH CONNECTION
Switch the megaphone ' USB/SD/AUX/BT' Mode. The
megaphone's LED indicator will then
blink signaling it is ready to be paired, via Bluetooth, with
your device.
The megaphone will appear as 'HC_Bluetooth' in your
Bluetooth device list. Connect to the
megaphone and you will be able to instantly stream me-
dia through the megaphone's speaker.
Control your media with the previous, next, play/pause
buttons.
FEATURES & SPECIFICATIONS:
• Built-in Bluetooth for Wireless Music Streaming
• Works with Virtually Any Bluetooth Device
• (iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
• 1,200 Yard Range
• For Indoor/Outdoor Use
• Used by U.S. Armed Forces
• Maximum Power Output: 50 Watt
• SD Card & USB Flash Memory Readers
• Ergonomic Pistol Grip and Light-Weight Chassis
• Batteries Required: 8 x "C" Batteries, Not Included
• Battery Life: Up to 16 Hours
• 6 Audio Functions Including Talk, Siren & USB/SD Modes
• Aux-Input (3.5mm) Jack to Connect External Devices
• Dimensions: Diameter 9.44'' x Length 13.77''
