ClosetMaid 2800 Manual

SHELFTRACK
®
1. USE THE CORRECT HARDWARE
Select the hardware that is right for your wall type:
Drywall Studs
Secure to the wall
Drill 1/2 in. holes and
with #12 x 2 in. pan
secure to the wall with
toggle bolts. head screws at stud
locations.
2. HANG TRACK LOCATION
Track can be installed at any height. However, for maximum
adjustability and strongest installation, install track flush to ceiling
and screw into wood header behind wallboard. Stud installation is
recommended whenever possible for the strongest installation.
3. DETERMINE LENGTH AND SPACING OF STANDARDS
Standards are available in several lengths, depending on the number
of shelves you want and the spacing between the shelves. The closer
the standards are placed together, the stronger the installation.
Standards should be spaced no more than 24 in. apart, and no more
than 4 in. from the end of the shelf.
24 IN. MAXIMUM
ClosetMaid Superslide shelf system is manufactured by ClosetMaid LLC., Orlando, Florida. Manufacturer reserves the right to change specifications without notice.
®
13485 Veterans Way | Orlando, Florida 32827
INSTALLATION TIPS
Concrete
Drill 1/4 in. holes.
insert #12 wall
anchors and secure to
the wall with #12 x 2
in. pan head screws.
| 1-800-874-0008
G
Choose Your Hardware
A
Hang Track
B
Standard
C
Bracket
4. SECURING STANDARDS
Each standard must be secured to the wall with one screw at the
closest hole to the center of the standards. When using toggle bolts,
remove toggle, put bolt through standard and re-attach toggle to bolt
before placing standard on track.
5. ATTACHING BRACKETS
Attach brackets at desired shelf height.
NOTE: Always match bracket size to shelving depth except when using
Shelf & Rod shelving. Always use 12 in. brackets for this type of shelving.
When installing 16 in. SuperSlide
in. brackets.
6. CUTTING SHELVING, CLOSET RODS, AND HANG TRACKS
Wire shelving can be cut using a bolt cutter or hacksaw. Closet rods can
be cut using a pipe cutter (recommended) or a hacksaw. Hang tracks
can be cut with a hacksaw.
7. CORNERS
When two shelves come together in a corner, use a corner shelf support
to connect them. Use a corner closet rod to allow clothes to slide
uninterrupted around corners.
Note: SuperSlide
8. END CAPS
Add caps to every exposed wire on both ends of each shelf and to
the ends of closet rods. End caps protect you, your clothing and the
shelving materials.
| US: closetmaidpro.com, closetmaid.com
A
E
D
with
D
Closet Rod
E
Closet Rod Support
F
Closet Rod Cap
G
Shelf End Cap
with Closet Rod & Support always use 12
®
Closet rod supports should be placed where closet rods join.
®
| Canada: closetmaid.ca © 2020 ClosetMaid LLC (01/21)
24in.
B
61cm
C
F
