HSW SERIES ELECTRIC FIREPLACE
USER'S MANUAL
Wall Mounted Electric Fireplace
Model: HSW-50 HSW-60
50" 60"
AC 110-120V 60Hz 750W/1500W
Read and understand this entire owner's manual including all safety
WARNING
information, before plugging in or using this product. Failure to do so
could result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.
www.hiresc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSW Series and is the answer not in the manual?

Questions and answers

Related Manuals for Hiresc HSW Series

Summary of Contents for Hiresc HSW Series

  • Page 1 Hiresc support@hiresc.com HSW SERIES ELECTRIC FIREPLACE USER’S MANUAL Wall Mounted Electric Fireplace Model: HSW-50 HSW-60 50" 60" AC 110-120V 60Hz 750W/1500W Read and understand this entire owner’s manual including all safety WARNING information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury.

  • Page 2: Table Of Contents

    HSW Series Electric Fireplace Table of Contents Parts and Hardware ..............................4 Tools Required................................4 Unpacking and Setup ..............................4 Unpacking Instructions ............................4 BOX CONTENTS ..............................4 Wiring ........

  • Page 3: Method Of Operation

    HSW Series Electric Fireplace IMPORTANT SAFETY INFORMATION WARNING THIS FIREPLACE IS HOT WHEN IN OPERATION AND CAN CAUSE SEVERE BURNS Do not operate fireplace before reading and understanding operation instructions. Failure to operate fireplace according to operation instructions could cause fire or injury.

  • Page 4: Parts And Hardware

    HSW Series Electric Fireplace Parts and Hardware Tools Required Phillips screwdriver Stud finder Level Tape measure Electric drill Wood drill bit Unpacking and Setup Unpacking Instructions Remove all parts and hardware from the carton and place them on a clean, soft, dry surface.

  • Page 5: Wiring

    HSW Series Electric Fireplace Wiring The HSW series recessed fireplace can be plugged into a grounded 3-prong outlet. Testing the Fireplace Prior to Installation Before installing the fireplace, test the fireplace to make sure that it operates properly. Due to the motor the fire will have a slight noise when in operation The remote will need syncing to the fire unit.

  • Page 6: Installation

    HSW Series Electric Fireplace Installation WARNINGS We would always recommend that you employ an experienced, qualified installer when fitting such products. Each installation will vary and specialist expertise is often required to conduct the building work. Giatalia / Your retailer therefore bears no responsibility or liability for any incorrectly installed fires.

  • Page 7: Recessed Installation

    HSW Series Electric Fireplace Recessed Installation Due to many different finish materials used on walls, it is highly recommended that you consult your local builder before you install this fireplace in the wall. Select a location that is not prone to moisture and is located at least 1000mm away from combustible materials such as curtains, drapes, furniture, bedding, or other combustible materials.

  • Page 8: Fire Dimensions

    1526m 1980mm Fireplace Width Recess 627mm 847mm 1103mm 1557mm Fireplace Depth Overall 144mm 144mm 144mm 144mm Fireplace Depth Recess 133m 133mm 133mm 133mm Installation Overview The HSW Series Electric Fireplace can be installed in Two different configurations: Recessed Installation: www.hiresc.com...

  • Page 9: Recessed Installation

    HSW Series Electric Fireplace Prepare the framed opening according to the Rough Opening Dimensions chart. Provide a 110Vac 13amp circuit for wire install at the top right of the framed opening. Install the L metal mounting bracket onto the top of the fireplace using the provided screws and secure it to the excavated wall Fireplace is fully recessed into the wall.

  • Page 10: Slide-In Cabinet Installation

    Align the glass panel with the glass slot below the fireplace, place the glass panel back into the fireplace, and then push the glass panel into place. Your HSW Series fireplace is now ready for use! www.hiresc.com...

  • Page 11: Operating Fireplace

    HSW Series Electric Fireplace Operating Fireplace Once the fireplace has been plugged into a grounded outlet, the fireplace is now ready for operation. Ensure that the house circuit breakers for the power supply are turned on. Power Plug the power cable into a 110v 7.5 amp grounded outlet. Make sure the outlet is in good condition and that the plug is not loose.

  • Page 12: Control Panel Functions

    HSWSeries Electric Fireplace www.hiresc.com...

  • Page 13: Remote Control Operation

    HSW Series Electric Fireplace    www.hiresc.com...

  • Page 14: Cleaning

    HSWSeries Electric Fireplace               www.hiresc.com...

  • Page 15: Friendly Faq

    A: No, we do not produce electric fireplace that is 220V. Q:Is this fireplace cool to the touch when opening heating modes? A:When our Electric Fireplace operating the heat, the air outlet is hot, and other places are cool. www.hiresc.com...

  • Page 16: Warranty

    Contact us ASAP STOP STOP DO NOT RETURN TO STORE Please Email us at: support@hiresc.com Warranty Our electric fireplaces are to be free of defects in material and workmanship for one year from the date of purchase. This warranty only covers manufacturing faults.
