HSL SERIES ELECTRIC FIREPLACE HEATER
USER'S MANUAL
Three Sided Electric Fireplace
WARNING
CAUTION
50" 60" 70" 80" 100"
AC 110-120V 60Hz 750W/1500W
Read and understand this entire owner's manual including all safety
information, before plugging in or using this product. Failure to do so
could result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
product away, make sure this manual accompanies this product.
www.hiresc.com
support@hiresc.com
HSL-50
HSL-60
HSL-70
HSL-80
HSL-90
Advertisement
Table of Contents
Related Manuals for Hiresc HSL-80
Summary of Contents for Hiresc HSL-80
- Page 1 USER’S MANUAL HSL-50 HSL-60 Three Sided Electric Fireplace HSL-70 HSL-80 HSL-90 50" 60" 70" 80" 100" AC 110-120V 60Hz 750W/1500W Read and understand this entire owner’s manual including all safety information, before plugging in or using this product. Failure to do so WARNING could result in fire, electric shock, or serious personal injury.
-
Page 2: Table Of Contents
Method of Operation ..........................13 Wireless Remote Control Functions ....................13 Remote Control Operation ........................13 Smart Life APP Control ......................... 14 Care and Maintenance ..........................15 Cleaning ..............................15 Maintenance ............................15 Friendly FAQ ............................16 Warranty ..............................17 www.hiresc.com... - Page 3 • Ensure clearances to combustibles are maintained when building a mantel or shelves above the fireplace. Elevated temperatures on the wall or in the air above the fireplace can cause melting, discoloration or damage to the decorations, a TV or other electronic components. www.hiresc.com...
-
Page 4: Parts And Hardware
NOTE: Dispose of plastic bag, as it may cause choking hazard with young children. Do not let children play with plastic bag. BOX CONTENTS 1 Fireplace 2 Side Glass Pieces 1 Remote Control Front Glass Canyon Driftwood Logs Crystal Embers Metal Bracket 2 Side Covers Screws www.hiresc.com... -
Page 5: Wiring
• Make sure this plug fits securely into the outlet. Faulty wall outlet connections or loose plugs can cause the outlet to overheat. If the outlet or face plate is hot, discontinue use immediately and have a qualified electrician inspect and/or replace the faulty outlet. Power Data Model HSL-60 HSL-70 HSL-80 HSL-90 HSL-50 Voltage 110Vac 110Vac 110Vac... -
Page 6: Installation
How to remove the glass panel bracket 1. There are 4 screws that fasten the glass panel bracket to the fireplace. Remove all 4 screws to remove the glass panel bracket. 2. After removing screws, the glass panel bracket away from the fireplace. www.hiresc.com... -
Page 7: Recessed Installation
1. Choose a location in the wall to install fireplace. 2. Make an opening in the wall based on metal firebox size. Drywall stops Drywall stops Fire Dimensions Model HSL-70 HSL-80 HSL-90 HSL-50 HSL-60 Fireplace Height Overall 521mm 521mm 521mm... -
Page 8: Recessed Installation Overview
• Glass exposed on the left, front, and right sides • Fireplace is fully recessed into the wall with both sides open Slide-in cabinet installation: • Glass exposed on the left, front, and right sides • Fireplace is fully recessed into the wall with both sides open www.hiresc.com... -
Page 9: Recessed Installation
2. Remove the drywall stops on both sides of the fire unit. 3. Install the side glass then side covers on both sides of the fire unit. 4. Install the fire unit in the framed opening with a minimum 1 ¼ drywall screws to secure the unit. www.hiresc.com... -
Page 10: Installing The Crystal Ember And Log-Set
Once completed installing crystal embers or fire log, you are now ready to reinstall the glass panel. 1. Place the glass panel back inside the fireplace and push the glass panel into place. 2. Reattach the screws holding the glass panel in place, as shown below. Your HSL Series fireplace is now ready for use! www.hiresc.com... -
Page 11: Operating Fireplace
This electric fireplace can be operated by the CONTROL PANEL, located in the upper right hand corner of the fireplace, or by the WIRELESS REMOTE CONTROL. The operation and functions of both methods are the same. Control Panel Wireless Remote Control www.hiresc.com... -
Page 12: Method Of Operation
3. Press again. Heaters turn off. blows cool air for 30 seconds after it turns The fan blows cool air for 30 seconds and then off. turns off. HEATER Reset button: Reset to default state. 1. Press 3S. Reset to default state. RESET www.hiresc.com... -
Page 13: Method Of Operation
DO NOT PRESS the buttons too quickly. Give the unit time to respond to each command. • NOTICE: NEVER dispose of batteries in fire. Failure to observe this precaution may result in an explosion. Dispose of batteries at your local hazardous material processing center. www.hiresc.com... -
Page 14: Smart Life App Control
3.Navigate to the Home 4.WIFI Setting:Set up the 5.Press the Add button screen in the app and Wifi network on your and then complete. press the Add Device phone,then you will see button. the Discovering devices on the add page. www.hiresc.com... -
Page 15: Care And Maintenance
• The fan motors are lubricated at the factory and will not require lubrication. • Electrical components are integrated in the fireplace and are not serviceable by the customer. Storage: • Store fireplace in a clean, dry place when not in use. www.hiresc.com... -
Page 16: Friendly Faq
A: No, we do not produce electric fireplace that is 220V. Q:Is this fireplace cool to the touch when opening heating modes? A:When our Electric Fireplace operating the heat, the air outlet is hot, and other places are cool. www.hiresc.com... -
Page 17: Warranty
Contact us ASAP STOP STOP DO NOT RETURN TO STORE Please Email us at: support@hiresc.com Warranty Our electric fireplaces are to be free of defects in material and workmanship for one year from the date of purchase. This warranty only covers manufacturing faults.
