HSQ SERIES ELECTRIC FIREPLACE
USER'S MANUAL
Square Insert Electric Fireplace
Model: HSQ24 HSQ33
24" 33"
AC 110-120V 60Hz 750W/1500W
Read and understand this entire owner's manual including all safety
WARNING
information, before plugging in or using this product. Failure to do so
could result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.
www.hiresc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSQ Series and is the answer not in the manual?

Questions and answers

Related Manuals for Hiresc HSQ Series

Summary of Contents for Hiresc HSQ Series

  • Page 1 Hiresc support@hiresc.com HSQ SERIES ELECTRIC FIREPLACE USER’S MANUAL Square Insert Electric Fireplace Model: HSQ24 HSQ33 24" 33" AC 110-120V 60Hz 750W/1500W Read and understand this entire owner’s manual including all safety WARNING information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury.

  • Page 2: Table Of Contents

    HSQ Series Electric Fireplace HW Series Electric Fireplace Table of Contents Parts and Hardware ..............................4 Tools Required................................4 Unpacking and Setup ..............................4 Unpacking Instructions ............................4 BOX CONTENTS ..............................4 Wiring ..................................5 Testing the Fireplace Prior to Installation ......................5 Prong Outlet Installation ............................
  • Page 3 HSQ Series Electric Fireplace                        www.hiresc.com...

  • Page 4: Parts And Hardware

    HSQ Series Electric Fireplace HW Series Electric Fireplace Parts and Hardware Tools Required Phillips screwdriver Stud finder Level Tape measure Electric drill Wood drill bit Unpacking and Setup Unpacking Instructions Remove all parts and hardware from the carton and place them on a clean, soft, dry surface.

  • Page 5: Wiring

    HW Series Electric Fireplace Wiring The HSQ series recessed fireplace can be plugged into a grounded 3-prong outlet. Testing the Fireplace Prior to Installation Before installing the fireplace, test the fireplace to make sure that it operates properly. Due to the motor the fire will have a slight noise when in operation The remote will need syncing to the fire unit.

  • Page 6: Installation

    HSQ Series Electric Fireplace              www.hiresc.com...

  • Page 7: Recessed Installation

    HSQ Series Electric Fireplace HW Series Electric Fireplace Recessed Installation Due to many different finish materials used on walls, it is highly recommended that you consult your local builder before you install this fireplace in the wall. Select a location that is not prone to moisture and is located at least 1000mm away from combustible materials such as curtains, drapes, furniture, bedding, or other combustible materials.

  • Page 8: Recessed Installation Overview

    HSQ Series Electric Fireplace HW Series Electric Fireplace 24 inch-Fire Dimensions Recessed Installation: www.hiresc.com...

  • Page 9: Recessed Installation

    HW Series Electric Fireplace HSQ Series Electric Fireplace Prepare the framed opening according to the Rough Opening Dimensions chart. Provide a 110Vac 13amp circuit for wire install at the top right of the framed opening. Install the L metal mounting bracket onto the top of the fireplace using the provided screws and secure it to the excavated wall Fireplace is fully recessed into the wall.

  • Page 10: Slide-In Cabinet Installation

    Align the glass panel with the glass slot below the fireplace, place the glass panel back into the fireplace, and then push the glass panel into place. Your HSQ Series fireplace is now ready for use! www.hiresc.com...

  • Page 11: Operating Fireplace

    HSQ Series Electric Fireplace HW Series Electric Fireplace Operating Fireplace Once the fireplace has been plugged into a grounded outlet, the fireplace is now ready for operation. Ensure that the house circuit breakers for the power supply are turned on.

  • Page 12: Method Of Operation

    HSQ Series Electric Fireplace www.hiresc.com...

  • Page 13: Method Of Operation

    HSQ Series Electric Fireplace    www.hiresc.com...

  • Page 14: Care And Maintenance

    HSQ Series Electric Fireplace               www.hiresc.com...

  • Page 15: Friendly Faq

    HSQ Series Electric Fireplace Friendly FAQ Q: How much temperature can this fireplace be adjusted? A: the temperature of fireplace can be adjusted from 62℉-82℉ or 17℃-27℃ Q: What is an acceptable heating distance? A: If you would like to feel the heat in front of you, 1.5 meters is great, but if you want to be sit without feel the heat, 2.5 metes is perfect.

  • Page 16: Warranty

    HSQ Series Electric Fireplace Contact us ASAP STOP STOP DO NOT RETURN TO STORE Please Email us at: support@hiresc.com Warranty Our electric fireplaces are to be free of defects in material and workmanship for one year from the date of purchase. This warranty only covers manufacturing faults.
