HSL SERIES ELECTRIC FIREPLACE HEATER
USER'S MANUAL
Three Sided Electric Fireplace
WARNING
CAUTION
Read and understand this entire owner's manual including all safety
information, before plugging in or using this product. Failure to do so
could result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
product away, make sure this manual accompanies this product.
HSL-50
HSL-60
HSL-70
Advertisement
Table of Contents
Related Manuals for Hiresc HSL Series
Summary of Contents for Hiresc HSL Series
- Page 1 Hiresc HSL SERIES ELECTRIC FIREPLACE HEATER USER’S MANUAL HSL-50 Three Sided Electric Fireplace HSL-60 HSL-70 Read and understand this entire owner’s manual including all safety WARNING information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury.
-
Page 2: Table Of Contents
Contents Parts and Hardware ............................. 4 Tools Required ............................4 Unpacking and Setup ..........................4 Unpacking Instructions ..........................4 BOX CONTENTS ..........................4 Wiring ............................... 5 Testing the Fireplace Prior to Installation ..................... 5 Prong Outlet Installation ........................5 Power Data ..............................5 Installation .............................. - Page 3 IMPORTANT SAFETY INFORMATION WARNING THIS FIREPLACE IS HOT WHEN IN OPERATION AND CAN CAUSE SEVERE BURNS Do not operate fireplace before reading and understanding operation instructions. Failure to operate fireplace according to operation instructions could cause fire or injury. Risk of burns. This fireplace is HOT when in operation and heating element is ON. Power to the fireplace should be turned off and the fireplace allowed to cool before servicing.
-
Page 4: Parts And Hardware
Parts and Hardware Tools Required Phillips screwdriver Stud finder Level Tape measure Electric drill Wood drill bit Unpacking and Setup Unpacking Instructions Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Check the parts list to make sure no parts are missing. If parts are missing, please contact technical support for replacement parts. -
Page 5: Wiring
Wiring The HSL series recessed fireplace can be plugged into a grounded 3 -prong outlet. Testing the Fireplace Prior to Installation • Before installing the fireplace, test the fireplace to make sure that it operates properly. Due to the motor the fire will have a slight noise when in operation •... -
Page 6: Installation
Installation WARNINGS Due to high temperatures, keep the fireplace out of high traffic locations. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 1M away from the front of the fireplace. Never install the fireplace where it may fall into a bathtub or other body of water. Wear safety gloves and safety glasses for protection during installation. -
Page 7: Recessed Installation
Recessed Installation • Due to many different finish materials used on walls, it is highly recommended that you consult your local builder before you install this fireplace in the wall. • Select a location that is not prone to moisture and is located at least 1000mm away from combustible materials such as curtains, drapes, furniture, bedding, or other combustible materials. -
Page 8: Recessed Installation Overview
Recessed Installation Overview The HSL three - sided Electric Fireplace can be installed in five different recessed configurations: Three-Sided Installation: • Glass exposed on the left, front, and right sides • Fireplace is fully recessed into the wall with both sides open Two-Sided Installation: •... -
Page 9: Recessed Installation
Recessed Installation Three-Sided Installation: 1. Prepare the framed opening according to the Rough Opening Dimensions chart. Provide a 110Vac 13amp circuit for wire install at the top right of the framed opening. 2. Install Metal Bracket. 3. Install the fire unit in the framed opening with a minimum 1 ¼ drywall screws to secure the unit. 4. -
Page 10: Installing The Crystal Ember And Log-Set
Once completed installing crystal embers or fire log, you are now ready to reinstall the glass panel. 1. Place the glass panel back inside the fireplace and push the glass panel into place. 2. Reattach the screws holding the glass panel in place, as shown below. Your HSL Series fireplace is now ready for use! -
Page 11: Operating Fireplace
Operating Fireplace Once the fireplace has been plugged into a grounded outlet, the fireplace is now ready for operation. Ensure that the house circuit breakers for the power supply are turned on. Power Plug the power cable into a 110v 7.5 amp grounded outlet. Make sure the outlet is in good condition and that the plug is not loose. -
Page 12: Method Of Operation
Method of Operation Control Panel Functions BUTTON ACTION & INDICATION FUNCTION ON: Enables control panel functions and 1. Press once. Indicator light turns on. Power turns remote control. Turns on flame effect. on. All functions enabled. OFF: Disables control panel functions and 2. -
Page 13: Method Of Operation
Method of Operation Wireless Remote Control Functions The machine can be turned on and off Power button cyclically Color ring Adjustable global or single group color Adjustable global or single group Dimmer brightness Flame After selection, you can adjust the flame selection button color, brightness and mode Ambient Light... -
Page 14: Care And Maintenance
Care and Maintenance Cleaning ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving the fireplace. Failure to do so could result in electric shock, fire, or personal injury. NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury. -
Page 15: Warranty
Warranty Our electric fireplaces are to be free of defects in material and workmanship for one year from the date of purchase. This warranty only covers manufacturing faults. This warranty does not cover damages, accidents, lack of maintenance, abuse or neglect. The warranty does not cover paint scratches, cosmetic blemishes, dents, corrosion or other normal wear and tear associated with the fireplace.
