CB2000 - Combination Slide Bolt
Included Components
Combi-Bolt
One-way
screws
Recessed Mounting
Step 1 Position the Strike Plate in its intended position. The
5/8" cutout in the Strike Plate must be over a recess
in the door frame.
Step 2 Mark the positions for the screws on the mounting
surface.
Step 3 Drill pilot holes for the screws.
Step 4 Screw the Strike Plate into place with the included One-Way
Screws.
Flush Mounting
Step 1 Complete Steps 1-3 above, then contunue to Step 2 below.
Step 2 Hold the Combi-Bolt slide bolt latch in its intended position,
then mark the positions for the screws on the mounting
surface.
Step 3 Drill pilot holes for the screws.
Step 4 Screw the Combi-Bolt into place using the included One-Way
Screws.
Step 5 Install the Bolt Receiver. Before screwing in the One-Way
Screws be certain the Bolt slides smoothly into the Bolt
Receiver.
www.fjmsecurity.com | info@fjmsecurity.com
Toll free 800-654-1786
Recessed Flush
mount mount
strike strike
CB2000
INSTALLATION
Recessed Mounting
Flush Mounting
WARNING: This product can expose you to chemicals
including chromium, which is known to the State of California
to cause cancer and birth defects or other reproductive
harm. For more information go to www.P65Warnings.ca.gov.
