FJM security Combi-Cam E Operating Manual

Electronic cabinet lock
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Electronic Cabinet Lock

Table of Contents

1.
Getting Started
Introduction ...........................................................................................................2
Thank You ...............................................................................................................2
Component Diagram .........................................................................................3
2.
Lock Operation Modes
Operating Modes .................................................................................................4
Single User Mode .................................................................................................4
Opening with User Password ..........................................................................4
Changing User Password ..................................................................................4
Forgotten Password ............................................................................................5
3.
Service Password Information
Service Password .................................................................................................5
Opening with Service Password .....................................................................5
Changing Service Password .............................................................................5
4.
Master Password Information
Master Password ..................................................................................................6
Opening with Master Password .....................................................................6
Changing Master Password .............................................................................6
5.
Accessing the Program Menu .........................................................................6
Program Menu Definitions/Options .........................................................7-8
Light and Audio Notification ...........................................................................9
6.
General Warnings ................................................................................................9
Maintenance ..........................................................................................................9
Changing the Battery ...................................................................................... 10
Battery Override ................................................................................................ 10
Cams ...................................................................................................................... 10
Quick Info ............................................................................................................ 11
7.
FJM Limited Warranty ...................................................................................... 12
Liability Disclaimer ........................................................................................... 12
Technical Specifications ................................................................................. 12
Page 1
www.fjmsecurity.com
7910-K10
Combi-Cam E
OPERATING MANUAL
Note: Please read this manual before
using the Combi-Cam E.
206-363-3290 | 800-525-0954
www.fjmsecurity.com
© 2025 Olympus Lock, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Combi-Cam E and is the answer not in the manual?

Questions and answers

Related Manuals for FJM security Combi-Cam E

Summary of Contents for FJM security Combi-Cam E

  • Page 1: Table Of Contents

    7910-K10 Combi-Cam E OPERATING MANUAL Electronic Cabinet Lock Note: Please read this manual before Table of Contents using the Combi-Cam E. Getting Started Introduction ......................2 Thank You .......................2 Component Diagram ..................3 Lock Operation Modes Operating Modes ....................4 Single User Mode ....................4 Opening with User Password ................4...

  • Page 2: Introduction

    The Combi-Cam E is an electronic cabinet lock featuring master and manager code access, one-time-use functionality, and an extended battery life up to 10 years. Designed for flexibility, the Combi-Cam E supports both right- and left-handed installations, making it ideal for a wide range of applications where controlled access is essential.

  • Page 3: Component Diagram

    7910-K10 Combi-Cam E OPERATING MANUAL Electronic Cabinet Lock COMPONENT DIAGRAM Back to Table of Contents 206-363-3290 | 800-525-0954 Page 3 www.fjmsecurity.com © 2025 Olympus Lock, Inc.

  • Page 4: Operating Modes

    OPERATING MANUAL Electronic Cabinet Lock OPERATING MODES The Combi-Cam E offers two configurable modes of operation: 1. Single User Mode (factory default): A fixed password is set, and the same user enters that password each time to open the lock.

  • Page 5: Forgotten Password

    7910-K10 Combi-Cam E OPERATING MANUAL Electronic Cabinet Lock FORGOTTEN PASSWORD Single User Mode 1. Use the master code to reset the lock to factory settings. Enter # XXXXXX * 4 0 where XXXXXX is the master code. 2. The default user code will be reset to 1010, which can then be changed as needed.

  • Page 6: Master Password

    7910-K10 Combi-Cam E OPERATING MANUAL Electronic Cabinet Lock MASTER PASSWORD The master password opens the lock and provides access to all programming features. Opening with Master Password Default: 101010 1. Press the * button and enter the current 6-digit master password.

  • Page 7: Program Menu Definitions/Options

    7910-K10 Combi-Cam E OPERATING MANUAL Electronic Cabinet Lock PROGRAM MENU DEFINITIONS Prog. Default Feature Definition Setting Restore Resets all settings to factory defaults. User password resets to 1010 and Factory — master password to 101010. Settings Single Default is single user (individual) mode, where a single 4-digit code is User or used repeatedly.

  • Page 8: Program Menu Options

    7910-K10 Combi-Cam E OPERATING MANUAL Electronic Cabinet Lock PROGRAM MENU OPTIONS Program Selection Option Restores factory default settings Single User (Individual Use) Mode Multiple User (One-Time Use/Locker) Mode Mute all sounds except warning beeps Enable all audible feedback: button tones, warnings, and confirmations...

  • Page 9: Light And Audio Notification

    7910-K10 Combi-Cam E OPERATING MANUAL Electronic Cabinet Lock LIGHT & AUDIO NOTIFICATIONS • Password Accepted: Green LED lights with two repeated audio warnings • Wrong Password: Red LED lights with four repeated audio warnings • Low Battery: Red LED lights blink five times after each operation •...

  • Page 10: Changing The Battery

    150 times before the battery is fully depleted. Battery Override In case of battery failure, the Combi-Cam E features two external contact points located around the red and green LED indicators. You can temporarily connect an external battery to these nodes to power the lock long enough to enter the correct code and unlock it, allowing internal batteries to be replaced.

  • Page 11: Quick Info

    7910-K10 Combi-Cam E OPERATING MANUAL Electronic Cabinet Lock QUICK INFO Important: These are the factory default settings. Once they are changed, keep your new codes in a safe place. Opening direction depends on which type of door the lock is installed in.

  • Page 12: Warranty & Technical Information

    WARRANTY & TECHNICAL INFORMATION Limited Warranty FJM Security provides a one-year limited warranty on all products, guaranteeing them to be free from manufacturing defects in materials and workmanship. This warranty does not cover batteries, lost combinations, or any damage resulting from improper installation, misuse, or unreasonable handling.
