Universal Remote Control UR3-SR2 Operating Manual page 4

STEP2
Press the [DEVICE] button and the [SELECT]
button simultaneously for three seconds. The
device LED will turn on indicating that it is ready
to be programmed. The LED will remain on for 20
seconds. The next step must be entered while
the LED is on.
STEP3
Press the [CH+] or [CH-] button one at a time or
keep it pressed. The remote will emit a series of
Power ON/OFF code signals. Release the [CH+] or
[CH-] button as soon as the equipment turns off.
*Note : You can verify that you selected the correct code
by pressing the [MUTE] button. The equipment
should turn On or Off.
STEP4
Press the same [DEVICE] button to store the
code. The Device LED will blink twice to confirm
that the code has been stored.
C. T o find the Thr ee-Digit Code that W
C. T o find the Thr ee-Digit Code that W
Pr ogrammed using the Auto Sear
Pr ogrammed using the Auto Sear
Method
Method
STEP1
Press the appropriate [DEVICE] button and the
[SELECT] button simultaneously for three
seconds. The device LED will turn on for 20
seconds. The next step must be performed while
the LED is on.
STEP2
Press the [INFO] button. The device LED will blink
a number of times indicating the number of each
digit for the code. Each digit is separated by a
one second interval of the LED being off.
Example : One blink, then three blinks, then eight blinks
indicates the code number 138.
*Note : Ten blinks indicates the number 0.
4
D. Pr ogramming a Second TV to the VCR
D. Pr ogramming a Second TV to the VCR
Button
Button
STEP1
Press the [VCR] button and the [SELECT] button
simultaneously for 3 seconds. The VCR LED will
turn on for 20 seconds. The next step must be
performed while the LED is on.
STEP2
Press the [TV] button.
STEP3
Point the remote control toward the TV and enter
the three-digit code for your TV from the TV
codes table.
STEP4
Store the three-digit code by pressing the [VCR]
button. The device LED will blink twice to confirm
that the code has been stored.
E. Pr ogramming for Advanced Functions.
E. Pr ogramming for Advanced Functions.
In the CABLE device mode, the A,B,C and blank macro
as
as
buttons can be programmed to act as macro buttons to
ch
ch send out up to 10 commands with one button press. In this
section, when you're instructed to press a [MACRO]
button, you need to press either the A, B, C or blank macro
button (depending on which button you are attempting to
program).
*Note : The A, B, and C buttons are not programmable if
you have a Digital Cable Box made by Pace,
Pioneer, or Scientific-Atlanta.
STEP1
Press the [CBL] button to select the CABLE
mode.
STEP2
Press a [MACRO] button and the [SELECT] button
simultaneously for 3 seconds. The CBL device
LED will turn on for 20 seconds. The next step
must be performed while the LED is on.
STEP3
Press up to 10 buttons you wish to store. The CBL
device LED will blink once for each command
entered.
5
