Delta Electronics SMT Power Inductor SIR136 Specification Sheet

SMT Power Inductor
SIR136 Type
Features
RoHS compliant.
Low profile (5.9mm max. height) SMD type.
Magnetically shielded.
Self-leads, suitable for high density
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here,
customized inductors are available to meet your exact requirements.
Mechanical Dimension:
C
D
Electrical Characteristics:
L
PART NO.
(uH)
SIR136 - 100 10
SIR136 - 120 12
SIR136 - 150 15
SIR136 - 180 18
SIR136 - 220 22
SIR136 - 270 27
SIR136 - 330 33
SIR136 - 390 39
SIR136 - 470 47
SIR136 - 560 56
SIR136 - 680 68
SIR136 - 820 82
SIR136 - 101 100
SIR136 - 121 120
SIR136 - 151 150
SIR136 - 181 180
SIR136 - 221 220
SIR136 - 271 270
SIR136 - 331 330
SIR136 - 391 390
SIR136 - 471 470
SIR136 - 561 560
SIR136 - 681 680
SIR136 - 821 820
1. Tolerance of inductance: 20% for 10~18uH,
2. Irated is the DC current which cause the inductance drop less than 25% of its nominal inductance without current for 10~18uH and
drop less than 20% of its nominal inductance for 22~820uH and the surface temperature of the part increase less then 45
3. Operating temperature : -20
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
mounting.
B
A
o
25 C, 10~18uH 100KHz, 0.1V.
2
1 DCR Irated
( ) MAX
(Adc)
0.05 2.65
0.05 2.50
0.06 2.45
0.06 2.40
0.07 2.20
0.08 2.00
0.10 1.80
0.11 1.65
0.12 1.50
0.15 1.38
0.17 1.26
0.20 1.14
0.25 1.05
0.28 0.95
0.40 0.85
0.48 0.77
0.52 0.70
0.70 0.63
0.80 0.57
1.08 0.52
1.20 0.48
1.34 0.44
1.78 0.40
2.00 0.36
15% for 22~820uH.
o o
C to 105 C (including self-temperature rise).
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
4.4
10.0
1.8
100~820uH 1KHz, 1V.
1000.00
100.00
10.00
1.00
0.00
18
UNIT:mm/inch
A = 12.6 ¡Ó 0.5 / 0.496 0.020 ¡Ó
B = 11.6 ¡Ó 0.5 / 0.457 0.020 ¡Ó
C = 5.4 0.5 / 0.213 0.020 ¡Ó ¡Ó
D = 1.5 0.2 / 0.059 0.008 ¡Ó ¡Ó
821
681
561
471
391
331
271
221
181
151
121
101
820
680
560
470
390
330
270
220
180
150.
120
100
0.01 0.10 1.00 10.00 100.00
CURRENT (A)
o
C.
