Medit T Series Function Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Function Manual
Medit Scan for Labs - T500/T300
Revision 3 (September 2020)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T Series and is the answer not in the manual?

Questions and answers

Related Manuals for Medit T Series

Summary of Contents for Medit T Series

  • Page 1 Function Manual Medit Scan for Labs - T500/T300 Revision 3 (September 2020)

  • Page 2: Table Of Contents

    1.6 Components ..................................9 1.7 Hardware Installation ..............................10 1.8 Specifications ................................. 12 Introduction and Overview ............................14 2.1 Medit Scan for Labs Introduction ........................14 2.2 Minimum Requirements............................14 2.3 Medit Link Installation ............................... 15 Medit Scan for Labs: Instruction ..........................18 3.1 Calibration: Table Top and Intraoral Scanners ....................
  • Page 3 3.7 Confirm ..................................... 61 Cases and Workflow Examples ..........................62 4.1 Scanning the bottom side of the wax-up ......................63 4.2 Scanning and Aligning Scanbody ........................68 4.3 Post and Core ................................70 4.4 Flexible Multi-die Process ............................75 Medit T-series User Guide...
  • Page 4 Medit offers high quality table scanners for dental CAD/CAM, including dental plaster models, impressions and prosthesis. With Medit T-Series Scanners, you can efficiently acquire high-quality 3D data in STL and OBJ formats. You can use our scanners with minimal training. Simply place the object in the scanner and follow the on-screen procedure to start scanning.

  • Page 5: General Information

    General Information Intended Use Workflow Scanner and Software General Information Medit T-series User Guide...

  • Page 6: Intended Use

    Post and core ⚫ Telescopic crown ⚫ Custom abutments ⚫ Implant bars and bridges ⚫ Removable partial denture ⚫ Orthodontic cases ⚫ Full denture ⚫ Replica denture ⚫ Provisional crown and bridge ⚫ Attachments ⚫ Splints ⚫ Medit T-series User Guide...

  • Page 7: Workflow

    1) Model or impression scan Together with the scanner itself, Medit Scan for Labs will scan the model according to the information entered in the order form in Medit Link. This enables you to create a prosthesis directly by scanning the impressions as compared to the conventional methods of prosthesis manufacturing.

  • Page 8: For The User

    2) Software: Medit Scan for Las Medit Scan for Labs: The accompanying software is designed to be user friendly, making ⚫ it easy to acquire scanned data. 1.4 For the User The system can only be used by trained dental professionals or technicians.

  • Page 9: Components

    1.6 Components 1. Medit T500 Scanner 2. Screw Jig (2EA) 3. Gum Jig 4. Multi-die 5. Half Block Jig (2EA) 6. Calibration Panel 7. USB for Installation (Installation Guide included in the manual) 8. USB Cable 9. Power Cable & External 10.

  • Page 10: Hardware Installation

    13. KAS Jig 14. 3-Axis Arm (Impression) 15. Impression Jig 16. A7+ Jig 17. Mark330 Jig 1.7 Hardware Installation After the completion of software installation and restarting your PC, you can begin installing ➢ the hardware. Medit T-series User Guide...
  • Page 11 ※ Caution: All the Medit T500 cables should be properly connected to the PC. (Medit T500 includes a power cable and a USB cable.) * Please use USB 3.0 port only while connecting Medit T500 USB with your PC. 1. Connect the power cable.

  • Page 12: Specifications

    LED, 150 ANSI-lumens Light color Blue LED Color Texture Color textures Connection USB 3.0 B Type Power AC 100-240V, 50-60 Hz Power Consumption STAND BY: 20W (IDLE: 35W, SCAN: 48W) Power Requirements POWER SUPPLY: 100-24VAC, 50/60Hz Medit T-series User Guide...

  • Page 13: Introduction And Overview

    Introduction and Overview Medit Scan for Labs is installed with Medit Link. Please make sure you reboot the PC after Medit Link installation and before connecting the scanner to the PC. Medit T-series User Guide...

  • Page 14: Medit Scan For Labs Introduction

    Medit Scan for Labs is a software program that allows to perform model and impression scans using the table top scanner series by Medit. Users can edit data, complement it with data from the intraoral scanner and prepare it for the CAD/CAM processes. Explicit explanations and guide messages are accompanying each stage on the left side of the window.

  • Page 15: Medit Link Installation

    Nvidia Geforce GTX 1060 6G and above Nvidia Geforce GTX 1060 6G and above Window 10 64-bit 2.3 Medit Link Installation Medit Scan for Labs is installed together with Medit Link. Follow the Medit Link instruction for more details. Run Medit_Link_X.X.X.X.exe file. ➢...
  • Page 16 USB 3.0 cable from your PC before installation. ➢ The program will be installed automatically, and it may take a few minutes. Do not turn off or unplug your PC until the installation is complete. Medit T-series User Guide...
  • Page 17 ➢ Please restart your PC after the installation is complete. If you do not have the scanner, you can proceed without restarting the PC. Caution: If you do not restart your PC after the installation is complete, the scanner may not function properly. Medit T-series User Guide...

  • Page 18: Medit Scan For Labs: Instruction

    –– Medit Scan for Labs: Instruction Installation Overview 3D Data Management User Interface Overview Scan Steps Scan Strategy Scan Steps: Scan, Align, Confirm Medit T-series User Guide...

  • Page 19: Calibration: Table Top And Intraoral Scanners

    Medit Scan for Labs: Instruction 3.1 Calibration: Table Top and Intraoral Scanners Calibration is recommended for proper scanning and performance of the device. Please calibrate the device if: ➢ The quality of scan data has decreased as compared to the previous scans.
  • Page 20 2) Manual calibration (you have to have the corresponding PNL file to be able to run Manual Calibration), and click ‘Next’. ➢ For Automatic Calibration, the process will be done automatically. Medit T-series User Guide...
  • Page 21 ➢ If you have the file, click to search for it. ➢ If you do not have the file, click and enter the serial number of the scanner. Medit T-series User Guide...
  • Page 22 ➢ Put the calibration panel on top of the two half-block jigs. ➢ Calibration process might take a few minutes. Please do not touch the scanner. Medit T-series User Guide...

  • Page 23: Intraoral Scanner Calibration

    ➢ Turn the device on and make sure that it is discoverable by the program. ➢ Click intraoral scanner icon on the bottom left to run the Calibration Wizard. ➢ Prepare the calibration tool. ➢ Set the dial of calibration tool to position Medit T-series User Guide...
  • Page 24 ➢ Click ‘Next’ to start the calibration. ➢ If you properly inserted the handpiece, data will be automatically obtained from position ➢ After the completion of data acquisition at position , move the dial to the next position according to on-screen instructions. Medit T-series User Guide...
  • Page 25 ➢ Repeat the above process for positions ➢ After the completion of data acquisition at the position, calibration result will be displayed. Medit T-series User Guide...

  • Page 26: Data Management With Mouse

    Places data in the center by double clicking on the background. Drag Moves the data in view screen. Wheel Scroll Zooms in/out the data in view screen. Click For data tree, allows to access data view options. Right Drag Rotates data in view screen. Medit T-series User Guide...
  • Page 27 Rotates the model. Up, Down, Left and Right Rotates the model. Keys Left Click and Drag Moves the model. Ctrl Up, Down, Left and Right Moves the model. Keys For keyboard shortcuts, go to Settings → Shortcuts. Medit T-series User Guide...

  • Page 28: User Interface Overview

    The title bar includes menu and options such as minimize/maximize/restore, exit; shows case information. The menu includes basic program functions like settings, information, help Menu contents. Minimize Minimizes the program window. Maximize/Restore Maximizes/Restores the program window. Exit Exits the program. Medit T-series User Guide...

  • Page 29: Menu

    Anonymous Usage Select whether you want to send usage statistics anonymously. Statistics Shortcut Keys Check out the default shortcut keys and configure your own. Medit T-series User Guide...
  • Page 30 Different diagnostic information for software and hardware. ⚫ Usage statistics are collected to analyze software usage patterns and frequently used features for the improvement of the product and user experience. Medit does not collect users’ personal information (username, company name, MAC address). Medit T-series User Guide...
  • Page 31 Cover Empty Spaces Turn this option on if you’d like to fill in the empty spaces in scan data with Using the Color of the color of the data located on its sides. Medit T-series User Guide...

  • Page 32: Shortcut Keys

    All the configured settings are set to default. 3.3.4 Shortcut Keys You can use shortcut keys for most of the Medit Scan for Labs functions. These shortcut keys can be changed in Settings by selecting and then pressing the new key on the keyboard.

  • Page 33: Scan Steps

    Completes scanning and starts a post-processing for final results. You can change the order of the steps as well by dragging the scan stages icons, or a set of them, with your mouse. You will see the available spaces marked in green. Medit T-series User Guide...

  • Page 34: Scan Strategy

    You can identify the data acquired from the flexible multi-die after performing the scan. Model Select this type for scanning the model. Impression Select this type for scanning the impression. Medit T-series User Guide...
  • Page 35 Alignment Assign a scanbody for each tooth based on the form information set in Medit Link, and their 3D image will be pulled out from the pre-set scanbody library. Select this option for post and core cases where you need to scan and merge the base and impression scans in order to get the complete and reliable scan data.
  • Page 36 Select this option if you use ARTEX articulator. KAVO Select this option if you use KAVO articulator. Select this option if you use SAM articulator. MARK330 Select this option if you use MARK330 articulator. Select this option if you use A7+ articulator. Medit T-series User Guide...
  • Page 37 Plate articulator. ▷ [Example] Articulator Jig Usage Example ➢ The scan steps are as following: ➢ The scan is performed by using the jig to place mandible model as shown on the picture below. Medit T-series User Guide...
  • Page 38 Put them back on to the base when scanning occlusion for alignment. Select this option to scan the prepared teeth both separately at Base Prepared Teeth step, and on the base while scanning the arch. Align the data at the Align stage. Medit T-series User Guide...
  • Page 39 Gingiva: Select to perform the scan with or without gingiva. With Gum Select this option to scan and align gingiva separately. Without In cases where gingiva is absent, there is no separate alignment process for gingiva. Medit T-series User Guide...
  • Page 40 Align Data step. Group This option can be selected when scanbodies are overlapped or when base data is needed for the missing part of scanbody. ▷ [Example] Scanning Process Group Medit T-series User Guide...
  • Page 41 Select this option when the prepared tooth cannot be detached Solid from the solid model. There is no separate scan stage for prepared tooth, but the scanning can be done using many cuts. ▷ [Example] Scanning Process Multi- Base Solid Medit T-series User Guide...
  • Page 42 Align the data after performing the scan. ▷ [Example] Interproximal Scanning ➢ The scan stages are shown below: The lingual interproximal scan is performed For buccal interproximal scan, the model is by tilting the model scanned in the upright position Medit T-series User Guide...
  • Page 43 Triple Tray Metal & Triple Tray Scan Individual Stump-die: Scanning impression and prepared teeth. Select this option to scan the impression only. Select this option to scan both impression and the prepared teeth on the flexible multi-die. Medit T-series User Guide...

  • Page 44: Scan Steps

    You can save the new sequence of steps and use for next scan. Medit Scan for Labs provides two options for performing a scan with already existing data: 1) Re- scan (‘Scan’) and 2) Add to the existing data (‘Add Another Scanbody’, ‘Additional Scan’. The first option is to be chosen when you want to delete all the existing data and re-scan, while the second option allows to keep the existing data and only scan the newly added parts.

  • Page 45: Scan Sub-Stages

    Multi-die. The number of each tooth appears under the icon. Tooth Occlusion Bite Allows to scan bite materials placed on the arch model. Gingiva Scan Gingiva Allows to scan mandibular gingiva materials. (Mandible) Gingiva (Maxilla) Allows to scan maxillary gingiva materials. Medit T-series User Guide...
  • Page 46 Allows to scan the outer surface of mandibular denture. Outer Surface) Denture (Maxilla; Inner Allows to scan the inner surface of maxillary denture. Surface) Denture (Maxilla; Outer Allows to scan the outer surface of maxillary denture. Surface) Occlusion Allows to scan the occlusion. Medit T-series User Guide...
  • Page 47 Side) Wax-up Allows to scan a mandibular wax-up after placing it on the model. (Mandible) Wax-up Allows to scan a maxillary wax-up after placing it on the model. (Maxilla) Medit T-series User Guide...

  • Page 48: Data Control And Display Options

    The part with higher reliability is shown as green color. Reliability Perform additional scanning to remove the less reliable areas. These data control tools are especially useful while working with touch screen. Medit T-series User Guide...

  • Page 49: Scanning

    ➢ Place the model in the scanner and press ‘Scan’. Before scanning, make sure that 1) the model is facing the cameras; 2) the articulator type settings are same across all linked programs (Medit Link, design program etc.). Medit T-series User Guide...
  • Page 50 Try adjusting the Medit Scan for Labs shortcuts for all major functions in the Settings. By default, ‘Space’ key is set for ‘Scan’. ➢ Before the scan starts, you will be asked to adjust the scan area. ➢ Please make sure that the area and side of model you want to scan fits in the camera view.
  • Page 51 Allows to get additional data on the specific area on the model Additional Scanning without replacing the existing one. ➢ In case you need an additional scan, rotate the model to bring the missing spot to the front, and click ‘Additional Scanning’. Medit T-series User Guide...
  • Page 52 Double-click on the missing spot to turn cameras to the empty spot and press ‘Scan’. The program will indicate which angles are not available for additional scanning. ➢ The empty space has been filled after performing the additional scan. Medit T-series User Guide...
  • Page 53 If you have an i500 scanner, the scan will proceed using it in Scan Using i500 Medit Scan for Labs. ➢ In case you need an additional scan, you can also proceed using the i500. Connect the i500 to the computer and make sure it is calibrated. Turn it on and click ‘Scan ➢...
  • Page 54 When on, deselects the area using various tools. Mode Import Mesh Imports 3D files. Data Clear Data Deletes all the data on the screen. Undo Undoes the previous action like scan, editing etc. Redo Redoes the action. Medit T-series User Guide...
  • Page 55 ▷ [ Example] Trimming Tools Freeform Rectangle Flood To control the selected data, press RMB to see the following options: Select All Selects all the data on the screen. Deselect All Cancels the selection of data. Medit T-series User Guide...
  • Page 56 ➢ Below is an example of a case which requires four scanbodies. In the situation where only two are available, start the ‘Scan’ button using these two scan bodies. Medit T-series User Guide...
  • Page 57 ➢ Switch the position of the scanbodies and click the ‘Add Another Scanbody’ button. The program will perform the additional scan to complement the existing data. Medit T-series User Guide...

  • Page 58: Data Alignment Steps

    Alignment Toolbox Align Automatically aligns all the data displayed on the screen. Automatically Detach Detaches all the aligned data. Remove Alignment Deletes the alignment points. Points Flip Occlusion This option is only available in occlusion alignment. Medit T-series User Guide...
  • Page 59 ➢ Once you move to this stage, alignment process will start automatically. ➢ If you want to perform alignment manually, first click ‘Detach’ to separate the aligned data and go back to the original position. ➢ On each data, set up to three corresponding points. Medit T-series User Guide...
  • Page 60 For individual data alignment, clikc RMB to access the following control options: Detach Data Detaches the specific part of the data. Automatic Automatically aligns only the selected area. Alignment Try Realignment Realigns the data precisely in case there is a mistake in alignment. Medit T-series User Guide...

  • Page 61: Confirm

    Free Selection Allows to freely select data. Rectangular Selects data using rectangular shape. Selection Island Selection Selects all connected data by clicking on it. Deselection Mode When on, deselects the area using various tools Medit T-series User Guide...

  • Page 62: Cases And Workflow Examples

    –– Cases and Workflow Examples Wax-up Bottom Scanning Scanning and Aligning Scanbodies Post and Core Flexible Multi-die Process Medit T-series User Guide...

  • Page 63: Scanning The Bottom Side Of The Wax-Up

    ➢ Here is an example of a maxillary wax-up case. Select Wax-up Bottom from the scan strategy and click ‘Next’. ➢ Select only the wax-ups for which you need the inner surface to be aligned, and click ‘Confirm’. Medit T-series User Guide...
  • Page 64 ➢ Proceed with scanning the maxillary base, and then move on to scanning only the prepared teeth. Medit T-series User Guide...
  • Page 65 ➢ Move on to Maxillary Wax-up step, and perform the scanning. ➢ After finishing scanning the outer surface of the wax-up, move to the next stage. Flip the wax- up and place it on a single die before scanning. Medit T-series User Guide...
  • Page 66 ➢ Proceed with scanning the base and occlusion, and move to Align Data stage. Prepared teeth and base will be aligned automatically. The outer surface of the wax-up and the base will also be aligned automatically. Medit T-series User Guide...
  • Page 67 ➢ The inner and outer surfaces of the wax-up should be aligned manually. Set up to three corresponding alignment points as shown on the picture below to align the data. ➢ Occlusion data will also be aligned automatically. ➢ Proceed to the ‘Confirm’ step to edit the data if necessary. Medit T-series User Guide...

  • Page 68: Scanning And Aligning Scanbody

    4.2 Scanning and Aligning Scanbody Medit Scan for Labs has an integrated Scanbody Library which makes it easier and faster to work with the scanbody cases. You can specify which scanbody is corresponding to each tooth, and the program will automatically insert the library data in to the model scan.
  • Page 69 ➢ Add a library to the favorites and manage it in the Favorites List.. ➢ After selecting the Scanbody library, click ‘Assign’ to assign the tooth with the selected scanbody. ➢ Once the assignment for all teeth is complete, click ‘Confirm’ to finish the process. Medit T-series User Guide...

  • Page 70: Post And Core

    4.3 Post and Core ➢ Selecting ‘Post and Core’ in the Set Scan Strategy dialogue window. ‘Post and Core’ option is possible for the cases where the form information contains Inlay/Onlay’, ‘Veneer’, ‘Telescopic crown’. Medit T-series User Guide...
  • Page 71 ➢ Perform the scan. ➢ Move to the Prep. Teeth stage and scan the trimmed die. ➢ If there is no trimmed die, scan the model again at this stage. Edit it to cut the unnecessary parts. Medit T-series User Guide...
  • Page 72 ➢ Scan the corresponding impression. ➢ Once you move to the Post stage, you will be asked to assign the data for the corresponding tooth. Medit T-series User Guide...
  • Page 73 ➢ Once you press ‘Confirm’, you will be able to align the die scan with the model. ➢ Next, align the model with the impression by setting up to three corresponding points on each data. Medit T-series User Guide...
  • Page 74 ➢ The alignment will be performed as following: ➔ Medit T-series User Guide...

  • Page 75: Flexible Multi-Die Process

    ➢ Click on any of the following stages to select the corresponding data. A dialogue window will open. ➢ You can edit the data using the tools located at the bottom of the window before proceeding. Medit T-series User Guide...
  • Page 76 ➢ Select the scan data and scan stage for assignment. ➢ Click ‘Assign’ to assign the data. ➢ The remaining data is also assigned in the same way. Medit T-series User Guide...
  • Page 77 Manufacturer Medit Corp 23, Goryeodae-ro 22-gil, Seongbuk-gu, Seoul, 02855 Rep. of Korea Tel : +82-2-2193-9600 Medit T-series User Guide...

This manual is also suitable for:
