HW1-S712-A
Rainbow House C
FRONT
C
A
WARNING:
- Contains small parts, sharp points
and edges.
- Adult assembly required.
- Two adults recommended.
- Do not stand, sit, kneel, lean or
pull on unit for support.
- Never leave children unattended.
- Adult supervision recommended.
PART LIST
X1
D
A
X1
B
X1
EN1176 Plate has been
assembled here
HARDWARE
TIP!
DO NOT FULLY
TIGHTEN SCREWS
UNTIL ALL SCREWS
HAVE BEEN LOOSELY
POSITIONED.
X1
B
X1
X1
(Ø4*50)
(Ø4*45)
X8
X23
BEFORE
ASSEMBLING,
MAKE SURE THERE
ARE NO
MISSING PARTS.
C X1
D
X1
E X1
F
X1
(Ø4*40)
X26
NOTE:/HINWEIS:
AN ELECTRIC SCREWDRIVER
WILL BE RECOMMENDED FOR
ASSEMBLY (NOT INCLUDED)
PAGE 1/9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wisdom Rainbow House C
Summary of Contents for Wisdom Rainbow House C
- Page 1 HW1-S712-A PART LIST Rainbow House C C X1 FRONT E X1 EN1176 Plate has been assembled here HARDWARE (Ø4*50) (Ø4*40) (Ø4*45) WARNING: - Contains small parts, sharp points NOTE:/HINWEIS: and edges. TIP! BEFORE AN ELECTRIC SCREWDRIVER - Adult assembly required.
- Page 2 (Ø4*45) (Ø4*50) (Ø4*45) (Ø4*50) PAGE 2/9...
- Page 3 (Ø4*45) (Ø4*45) (Ø4*40) Ø4*45 PAGE 3/9...
-
Page 4: Care And Cleaning
Record the Batch-Number here. Information is located on the shipping carton and / or the product itself. Keep this sheet in an accessible place. Model Number: HW1-S712-A Batch-Number: Distribution: Wisdom Education Europe GmbH Drosselweg 10 09526 Olbernhau,Germany www.wisdomeurope.eu PAGE 4/9... - Page 5 safety range of product/Sicherheitsabstand:3916*2832MM PAGE 5/9...
-
Page 6: Installation Instructions
Description: Rainbow House C ： Item Code HW1-S712-A Imported into EU by: Wisdom Education Europe GmbH,Drosselweg 10,09526 Olbernhau, Germany Manufacturer: Wisdom Educational Product Co.,Ltd Manufacturer Address: Building 4, Lane 2777, Baoan Road, Malu Town, Jiading District, Shanghai, China Test standard: EN 1176-1:2017/A1:2023 Over all Dimension: 208.6*100.2*182.6 CM... - Page 7 Instruction of anchor for grass ground 1 ) Firstly determine the coordinate points that need to be fixed to the product. With the digging tool, dig 46CM downward the grass, bury the grass anchor, then tamp the soil. 2 ) Fixed the product on a suitable position, use the fabric loop to hook the grass anchor and fix the fabric loop to the suitable position with M4*25 tapping screws to complete the installation.
-
Page 8: Maintenance
INSTRUCTIONS Please read the instructions and warning labels carefully before use. Inspect items and play area for any potential hazards prior to use. 3.Maximum number of people using the equipment at the same time is 4 . 4.User age group: 3 ~ 14 years old. 5.Never leave children unattended.Ensure constant adult supervision. - Page 9 INSPECTION INFORMATION Inspection cycle Inspection Project YES/NO Solution Signature Check screws, bolts and fasteners are tightened. Installed on a flat surfact and no hazards are present. Equipment is free of dirt and moisture. Daily Inspection on Items Hook and loop attachments are securely fastened. Check for a signs of damage and wear.
