Summary of Contents for Wisdom Split Rainbow Xylophone
- Page 1 72-22002 Split Rainbow Xylophone Number Name Model Quantity Hexagon socket screw M8*20 Hexagon socket screw M6*50...
-
Page 2: Installation Steps
72-22002 Split Rainbow Xylophone Installation steps ： Number Name Model Quantity 1 : Locate the footing position, dig a hole In-ground Mount Bracket in size 500*500*400mm. 2:Make concrete base with 140mm height, and put in-ground kit. 3:Pour concrete again with 660mm height. -
Page 3: Concrete Base
72-22002 Split Rainbow Xylophone Installation steps ： Number Name Model Quantity M8*100 Expansion Bolt 1 : Expansion bolt for concrete floor. M8*100 CONCRETE BASE... - Page 4 72-22002 Split Rainbow Xylophone Number Name Model Quantity Remove the black base cover by loosening the screws as shown in below figure.
- Page 5 72-22002 Split Rainbow Xylophone Number Name Model Quantity Fix the black base cover by fastening the screws as shown in below figure.
