Summary of Contents for Emerson HD70020
- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. EMERSON HD70020 Owner's Manual Shop genuine replacement parts for EMERSON HD70020 Find Your EMERSON Humidifier Parts - Select From 160 Models -------- Manual continues below --------...
- Page 2 CAUTION: Read all instructions carefully before installation. Save this Owner’s Manual for future reference. Model Nos. HD7002 1 & HD7005 0 EMERSON ® HD7002 & HD7005 ™ MoistAIR Evaporative Console Humidifier Owner’s Manual Part No. SP6470 Printed in Canada...
-
Page 3: General Safety Instructions
Emerson. It is agreed that such repair or replacement is the exclusive remedy avail- able from Emerson Electric Co. and that Emerson Is Not Responsible For Damages Of Any Kind, Including Incidental And Consequential Damage. -
Page 4: Know Your Humidifier
Know Your Humidifier Fan Assembly Controls Bottle Cover Filter Support Assembly Filters Replacement No. HDC-2R or HDC411 NOTE: HDC411 provides two filter changes. Description HD7002 & HD7005 Gallon Output / 24 hrs Litre Output / 24 hrs. 26.5 Capacity of Bottle 2.5 Gallons Capacity of Bottle 9.4 Litres... -
Page 5: Humidifier Operations
Humidifier Operations Humidified Air is Your new Emerson humidifier is designed to Then Released satisfy home humidity requirements through Through the Top the principle of evaporation of water into the air. After water is added to the bottle and positioned in the humidifier, the filters... -
Page 6: Location Instructions
Location Instructions next to an inside wall. Hot air registers WARNING: For your own safety, do and cold air from outside walls can affect not use humidifier if any parts are the efficiencies of the controls. Unit damaged or missing. should not be placed where warm air 1. - Page 7 Water Fill (continued) Turn Counterclockwise To fill this humidifier, close the control cover to Remove “E-Z-Fill Side-Cap and remove the bottle cover. To remove the water bottle, lift the bottle straight up and out of the cabinet. The water bottle is designed with an “E-Z- Fill Side-Cap”.
-
Page 8: Operating Humidifier Controls
Operating Humidifier Controls The operating controls of your Emerson Fill Light evaporative humidifier are located on the When the unit has a small amount of water top right of the humidifier. The controls are left in it, the fill light... -
Page 9: Using Your Humidifier
Using Your Humidifier 1. Be sure unit is full of water and plugged 4. If humidifier stops running and the Fill Light is not illuminated, the humidity level is at the normal requirements for 2. Set air flow control to desired fan that setting or it is adjusting to the home speed. -
Page 10: Replacement And Care Of Filters
Use only Emerson HDC-2R or HDC411 replacement filters. NOTE: HDC411 provides two com- Fan Assembly plete filter changes. - Page 11 Replacement and Care of Filters (continued) 3. a. Remove the two filters and dispose Water Level of properly. Float b. Clean internal parts of the humidifier per the “Cleaning Your Humidifier” Float Retainer section of your owner’s manual. c. Install new filters inside the cabinet with the glue beads on the filter fac- Filters ing the center of the cabinet.
-
Page 12: Cleaning Your Humidifier
Emerson HDC-2R rear of the cabinet. or HDC411 replacement filters. We 5. Empty any remaining water in the bot- also recommend using liquid EPA- tom of cabinet. -
Page 13: Bi-Weekly Maintenance
Cleaning Your Humidifier (continued) Bi-Weekly Maintenance End of Season Maintenance Removing Scale 1. Follow “Bi-Weekly Maintenance” 1. Pour one 8 ounce cup of undiluted instructions at end of humidification white vinegar into the cabinet. Let solu- season. tion stay in for 20 minutes. 2. -
Page 14: Troubleshooting
Troubleshooting TROUBLE PROBABLE CAUSE REMEDY Unit will not run • Speed control in off position. • Turn speed control clockwise. and Fill Light is not • Selected humidity level is • Raise humidistat setting if obtained. desired. • No power. •... -
Page 15: Repair Parts
Repair Parts PARTS LIST FOR EMERSON HUMIDIFIER MODEL NO. HD7002 1 & HD7005 0... - Page 16 Bottle (includes Key No's 26 & 27) 825849 825849 Cord w/Plug 821904 821904 – Owners Manual (Not Illustrated) SP6470 SP6470 FOR PARTS: If in the USA call 1-800-654-3545 If in Canada call 1-866-258-7847 For more information about Emerson MoistAIR ™ humidifiers visit our website at www.moistair.com...
- Page 17 FOR TECHNICAL HELP, CALL (800) 654-3545 FROM USA OR (888) 744-4687 FROM CANADA (Please have complete model number) 9999 Highway 48 Markham, Ontario Canada L3P 3J3 © 2002 Emerson Electric Co. Part. No. SP6470 Form. No. SP6470 Printed in Canada 06/02...
