Delta Electronics SMT Power Inductor SIL620 Specification Sheet

SMT Power Inductor
SIL620 Type
Features
RoHS compliant.
Small size (5.6mm*5.6mm), Low profile (2.0mm max. height) SMD type.
Magnetically shielded, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.
Mechanical Dimension:
C
A

Electrical Characteristics:

PART NO.
(uH)
SIL620 - 1R1
SIL620 - 1R5
SIL620 - 2R5
SIL620 - 3R3
SIL620 - 4R1
SIL620 - 4R7
SIL620 - 6R0
SIL620 - 6R8
SIL620 - 8R9
SIL620 - 100 10.0
SIL620 - 120 12.0
SIL620 - 150 15.0
SIL620 - 180 18.0
SIL620 - 220 22.0
SIL620 - 270 27.0
SIL620 - 330 33.0
SIL620 - 390 39.0
SIL620 - 470 47.0
SIL620 - 560 56.0
SIL620 - 680 68.0
SIL620 - 820 82.0
SIL620 - 101 100.0
1. Tolerance of inductance :
2. Irated is the DC current which cause the inductance drop less than 35% of its nominal inductance without current
and the surface temperature of the part increase less than 45 C.
3. Operating temperature: -20 C to 105 C (including self-temperature rise).
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
B
D
1
o
25 C: 100KHz, 0.1V
1
L
2
DCR Irated
( ) MAX (Adc)
1.1 0.030 3.70
1.5 0.040 3.00
2.5 0.048 2.50
3.3 0.054 2.10
4.1 0.057 1.95
4.7 0.080 1.70
6.0 0.100 1.50
6.8 0.110 1.40
8.9 0.140 1.25
0.160 1.20
0.215 1.10
0.224 0.97
0.247 0.85
0.290 0.80
0.330 0.75
0.386 0.65
0.520 0.57
0.595 0.54
0.665 0.50
0.840 0.43
0.978 0.41
1.200 0.36
3 0%.
o o
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
6.3
6.3
2
100.00
10.00
0.
00
o
37
UNIT:mm/inch UNIT:mm/inch
1.5
A = 6.0 / 0.236 Max.
B = 6.0 / 0.236 Max.
C = 2.0 / 0.079 Max.
D = 2.0 0.1 / 0.079 0.004
101
820
680
560
470
390
330
270
220
180
150
120
100
8R2
6R2
5R4
4R1
4R1
0.01 0.10 1.00 10.00
CURRENT (A)
