IMPORTANT SAFETY INSTRUCTIONS
WARNING
If the instructions contained in this manual are not followed
precisely, a fire or explosion may result causing property
damage, personal injury or loss of life.
INSTALLATION AND SERVICE MUST BE PERFORMED BY A
QUALIFIED INSTALLER.
IMPORTANT:
Important Notes to the Installer
• Read all instructions contained in these installation instructions before
installing the range.
• Remove all packing material from the oven and the drawer compartments
before connecting the electrical supply to the range.
• Observe all governing codes and ordinances. Be sure to leave these
instructions with the consumer.
Important Note to the Customer
• Keep these instructions with your owner's guide for future reference.
Definitions
• This manual contains important safety symbols and instructions.
• Please pay attention to these symbols and follow all instructions given.
Table of Contents
SAVE FOR THE LOCAL INSPECTOR'S USE.
9
9
12
13
14
18
3
Advertisement
Table of Contents
Related Manuals for Smeg SPR36UIMAN
Summary of Contents for Smeg SPR36UIMAN
-
Page 1: Table Of Contents
Table of Contents 1 Installation 1.1 Product dimensions 1.2 Unpacking, moving and positioning the range 1.3 Electrical connection 1.4 Wall and floor attachment 1.5 For the installer IMPORTANT SAFETY INSTRUCTIONS WARNING If the instructions contained in this manual are not followed precisely, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 2: Important Safety Instructions
Important Safety Instructions • Check for proper installation and use of the anti-tip bracket. WARNING Carefully tip the range forward by pulling it from the back to ensure that the anti-tip bracket This symbol will help alert you to engages the range leg and situations that may cause serious bodily prevents tip-over. - Page 3 Important Safety Instructions Safety Codes and Standards • Make sure the wall coverings around the range can withstand This appliance complies with one or the heat generated by the range. more of the following Standards: UL 858 - The Standard for the WARNING safety of Household Electric Ranges CAN/CSA-C22.2 No.
-
Page 4: Electric Safety
Important Safety Instructions • THIS COOKTOP IS NOT • For appliances equipped with a REMOVABLE. Do not attempt to cord and plug, do not cut or remove the cooktop. remove the ground prong. It must be plugged into a matching grounding type receptacle to WARNING avoid electrical shock. - Page 5 Important Safety Instructions Related Equipment Safety Ventilation Recommendations • The appliance should only be • Do not obstruct air vents or heat used if installed by a qualified vent openings. technician in accordance with • We strongly recommend the these installation instructions and installation of a ventilation hood all applicable regulations and above this appliance.
- Page 6 Important Safety Instructions High altitude installation How to read the user manual • This appliance can operate up to This user manual uses the following reading conventions: an altitude of 10,000 ft. (3048 m.) elevation above sea Installation level. If desired, for altitudes Information for the qualified above 2,000 ft (610 m) elevation technician: installation, operation...
-
Page 7: Installation
Important Safety Instructions 1 Installation 1.1 Product dimensions Overall dimensions: Location of electrical connection point. 912.4 mm " min. 626 mm min. 24 " Max. 630 mm Max. 25” 130 mm " 1088 mm " 29 mm " min. 35 "... - Page 8 Installation Cabinet clearances min. clearance from the sides of range to side wall or other combustible material; min. cabinet opening width; upper cabinet to countertop; max. upper cabinet depth. The side cabinet depth (clearance B) must match the front edge of the range side panel.
- Page 9 Installation Location of the electric outlet Keep a minimum clearance of 5 " (150 mm) between the appliance and the other furnishings or decorative elements according to the diagram below. Min. 300 mm min. 11 ” min. 2” min. 51 mm Max.
-
Page 10: Unpacking, Moving And Positioning The Range
Installation 1.2 Unpacking, moving and • Legs should be installed near to where the appliance will be used as they are positioning the range not secure for long transit. Keep the unit raised so that the legs can be screwed CAUTION into their couplings, then lower the range gently to prevent the legs and mounting... -
Page 11: Electrical Connection
Installation The appliance must sit level on the floor to 3. Once you have fixed the backguard to ensure stability: the appliance, you must insert the screws and spacers provided that are necessary • Screw or unscrew the bottom part of the for the slot-in installation. -
Page 12: Wall And Floor Attachment
Installation The rating plate is visibly located on the WARNING right side of the oven door frame. This ID plate must never be removed. Electrical shock hazard • Disconnect the electrical supply before servicing the appliance • It is the personal responsibility of the consumer to have the appropriate outlet or junction box with the correct, properly grounded wall receptacle installed by a... - Page 13 Installation CAUTION WARNING : Tip Over Hazard • Contact a qualified installer or • A child or adult contractor to determine the proper method for drilling holes through the could tip the wall or floor material (such as ceramic range over and tile, hardwood, etc.) be killed.
- Page 14 Installation Installing the anti-tip bracket NOTE: The wall attachment is 1. Ensure that the electrical connection is in recommended if the appliance is the correct position. placed against a wall. Floor 2. Assemble the bracket. attachment is recommended in case of island installation. 5.
- Page 15 Installation 7. Use the following distances for the distance from the side of the appliance WARNING to the bracket holes. The rear vent trim has ” (5 mm) standoffs to keep the appliance slightly away from the back wall. Do not remove or tamper with standoffs due to potential temperature issues.
-
Page 16: For The Installer
Installation Door removal It is not necessary to remove the door in order to install the range, but is an added convenience. Refer to the Use and Care Guide for the oven door removal instructions. 1.5 For the installer • The plug must remain accessible after the installation is complete.
