Smeg CS20 Manual

Smeg CS20 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

1.
2.
INSTALLATION OF THE APPLIANCE ________________________36
3.
4.
FINAL OPERATIONS______________________________________40
5.
DESCRIPTION OF CONTROLS _____________________________42
6.
USE OF THE COOKING HOB _______________________________47
7.
USE OF THE OVENS _____________________________________48
8.
AVAILABLE ACCESSORIES ________________________________49
9.
COOKING HINTS_________________________________________50
10.
CLEANING AND MAINTENANCE ____________________________57
11.
EXTRAORDINARY MAINTENANCE __________________________60
THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES WHOSE
IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THIS MANUAL.
INSTRUCTIONS FOR THE INSTALLER: these are for the qualified
technician who must carry out a suitable check of the gas system,
install the appliance, set it functioning and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice,
description of the commands and the correct procedures for cleaning
and maintenance of the appliance.
Contents
33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS20 and is the answer not in the manual?

Questions and answers

Related Manuals for Smeg CS20

Summary of Contents for Smeg CS20

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR SAFE AND PROPER USE _______________34 INSTALLATION OF THE APPLIANCE ________________________36 ADAPTATION TO DIFFERENT TYPES OF GAS ________________38 FINAL OPERATIONS______________________________________40 DESCRIPTION OF CONTROLS _____________________________42 USE OF THE COOKING HOB _______________________________47 USE OF THE OVENS _____________________________________48 AVAILABLE ACCESSORIES ________________________________49 COOKING HINTS_________________________________________50 CLEANING AND MAINTENANCE ____________________________57 EXTRAORDINARY MAINTENANCE __________________________60 THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES WHOSE...

  • Page 2: Instructions For Safe And Proper Use

    Introduction 1. INSTRUCTIONS FOR SAFE AND PROPER USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE COOKER. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE COOKER.
  • Page 3 Introduction THE I.D. PLATE WITH TECHNICAL DATA, REGISTRATION NUMBER AND BRAND NAME IS POSITIONED VISIBLY IN THE STORAGE COMPARTMENT. THE PLATE MUST NOT BE REMOVED. DO NOT INSTALL THIS APPLIANCE ON A RAISED PLATFORM. DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO TOUCH THE HEATING ELEMENTS INSIDE THE OVEN.

  • Page 4: Installation Of The Appliance

    Instructions for the installer 2. INSTALLATION OF THE APPLIANCE It is the law that all gas appliances are installed by competent persons. Corgi gas installers are approved to work to safe and satisfactory standards. All gas installation, servicing and repair work must be in accordance with the gas safety regulations 1984 (installation and use) as amended 1990.
  • Page 5 Instructions for the installer 2.2 Ventilation requirements The room containing the appliance should have an air supply in accordance with B.S. 5440 part 2 1989. All rooms require an opening window or equivalent, and some rooms will require a permanent vent as well. For room volumes up to 5 m If the room has a door that opens directly to the outside, and the room exceeds 1 m...

  • Page 6: Adaptation To Different Types Of Gas

    Instructions for the installer 3. ADAPTATION TO DIFFERENT TYPES OF GAS Before performing any cleaning or maintenance work, detach the appliance from the electrical socket. The cooking hob of the cooker is inspection-tested for use with G 20 natural gas at a pressure of 20 mbars. If used with other types of gas, you have to replace the nozzles and regulate the primary air to the burners.
  • Page 7 Instructions for the installer 3.2 Regulation for LPG Loosen screw A and push air regulator B to the bottom. With a 7 mm wrench, remove nozzle C and replace it with the proper one (follow reference tables for the type of gas to be used).

  • Page 8: Final Operations

    Instructions for the installer 3.4 Regulation of primary air Referred to distance “X” in mm. 4. FINAL OPERATIONS Having carried out the above adjustments, reassemble the appliance following, backwards, the instructions in paragraph “3.1 Raising of cooking hob”. After adjustment to a different kind of gas from the one for which the cooker has been tested, replace the plate inside the storage compartment with one corresponding to the new kind of gas.
  • Page 9 Instructions for the installer 4.2 Regulation of minimum for LPG To regulate the minimum for LPG, completely tighten (clockwise) the screw inside or next to the gas tap pin (depending on the model). The diameters of the by-passes for each burner are given in table “3.2 Regulation for LPG”.

  • Page 10: Description Of Controls

    Instructions for the user 5. DESCRIPTION OF CONTROLS 5.1 Front control panel All the cooker controls and commands are on the front panel. Before using the main oven check that the electronic programmer is showing the symbol DESCRIPTION OF SYMBOLS BACK LEFT BURNER FRONT LEFT BURNER FRONT CENTRAL...
  • Page 11 Instructions for the user THERMOSTAT KNOB (OVENS) Selection of cooking temperature is carried out by turning the knob clockwise to the required temperature, between 50° and 250°C. The tell-tale light comes on to indicate that the oven is warming up. When it goes out it means that the required temperature has been reached.
  • Page 12 Instructions for the user 5.2 Electronic Programmer The programmer user instructions are valid only for the main oven. LIST OF FUNCTIONS MINUTE-COUNTER KEY COOKING TIME KEY END-OF-COOKING KEY DECREASE TIME KEY INCREASE TIME KEY 5.2.1 Clock adjustment When using the oven for the first time, or after a power failure, the display flashes regularly and indicates the same time the keys minute either up or down.
  • Page 13 Instructions for the user 5.2.2 Semiautomatic cooking Use this setting for automatic oven switch-off at the end of cooking time. By pressing key , the display lights up, showing pressed and at the same time, press keys time. Release key to start the programmed cooking time count.
  • Page 14 Instructions for the user 5.2.5 Adjusting alarm volume The acoustic alarm has three different settings. These can be operated, while the alarm is sounding, by pressing key 5.2.6 Switching off the alarm The alarm switches off automatically after seven minutes. They can be manually de-activated by pressing the keys 5.2.7 Minute Counter The programmer can also be used as a simple minute counter.

  • Page 15: Use Of The Cooking Hob

    Instructions for the user 6. USE OF THE COOKING HOB 6.1 Lighting of the cooking hob burners Before lighting the cooking hob burners check that the flame cap crowns are properly positioned with their appropriate burner caps: niche A must be centred with pin B.

  • Page 16: Use Of The Ovens

    Instructions for the user 6.3 Diameter of containers 7. USE OF THE OVENS 7.1 Warnings and general advice Before using the oven for the first time, pre-heat it to maximum temperature (250°C) long enough to burn any manufacturing oily residues which could give the food a bad taste. After a power failure, the display will flash at regular intervals showing .

  • Page 17: Available Accessories

    Instructions for the user 8. AVAILABLE ACCESSORIES The oven features 4 support positions for plates and racks of different height. Oven grill: for cooking food on plates, small cakes, roasts or food requiring light grilling. Plate grill: for placing above plate for cooking foods that might drip.

  • Page 18: Cooking Hints

    Instructions for the user 9. COOKING HINTS In fan-assisted mode preheating should be carried out at 30/40°C above the cooking temperature. This considerably shortens cooking times and reduces power consumption, as well as giving better cooking results. Keep the oven door closed during cooking 9.1 Traditional cooking (main and auxiliary ovens) FUNCTION SWITCH THERMOSTAT SELECTOR SWITCH FROM...
  • Page 19 Instructions for the user 9.2 Hot-air cooking (main oven) FUNCTION SWITCH THERMOSTAT SELECTOR SWITCH FROM 50° TO 250°C This system is suitable for cooking on several levels, including different types of food (fish, meat etc.), without the tastes and smells mingling. Air circulation in the oven ensures a uniform distribution of heat.
  • Page 20 Instructions for the user 9.4 Hot-air grilling (main oven) FUNCTION SWITCH THERMOSTAT SWITCH FROM 50° TO 200°C Ensures uniform heat distribution with greater heat penetration into the food. Food will be lightly browned on the outside and remain soft inside. Keep the oven door closed during cooking.
  • Page 21 Instructions for the user 9.6 Defrosting (main oven) FUNCTION SWITCH THERMOSTAT SWITCH IN POSITION 0 The flow of air produced by the fan ensures quicker defrosting. The air circulating inside the oven is at room temperature. The advantage of defrosting at room temperature is that it does not alter the taste and appearance of the food.
  • Page 22 Instructions for the user 9.7 Spit cooking (auxiliary oven) FUNCTION SWITCH THERMOSTAT SWITCH AT MAXIMUM This type of cooking is only for the auxiliary oven. Use it for small size pieces. Prepare the spit with the food, blocking fork screws A. Insert frame B into the third guide from the bottom.

  • Page 23: Recommended Cooking Table

    Instructions for the user 9.8 Recommended cooking table Cooking times, especially meat, vary according to the thickness and quality of the food and to consumer taste. FIRST COURSES LASAGNE OVEN-BAKED PASTA MEAT ROAST VEAL ROAST BEEF ROAST PORK CHICKEN DUCK GOOSE - TURKEY RABBIT LEG OF LAMB...
  • Page 24 Instructions for the user FIRST COURSES LASAGNE OVEN-BAKED PASTA CREOLE RICE MEAT ROAST VEAL ROAST PORK ROASTED BEEF FILLET OF BEEF ROAST LAMB ROAST BEEF ROAST CHICKEN ROAST DUCK ROAST TURKEY ROAST RABBIT ROAST HARE ROAST PIGEON FISH PIZZA DESSERTS (PASTRIES) CIAMBELLA FRUIT CAKE SPONGE-CAKE...

  • Page 25: Cleaning And Maintenance

    Instructions for the user 10.CLEANING AND MAINTENANCE 10.1 Cleaning stainless steel To keep stainless steel in good condition it should be cleaned regularly after use. Let it cool first. 10.1.1 Ordinary Daily Cleaning To clean and preserve the stainless steel surfaces, always use only specific products that do not contain abrasives or chlorine-based acids.
  • Page 26 Instructions for the user 10.2.2 Burner caps, flame cap crowns and burners The burner caps, flame cap crowns and burners are extractable to facilitate cleaning. Wash them with hot water and non-abrasive detergent, taking care to remove incrustation, and leave them to dry completely.
  • Page 27 Instructions for the user 10.3.1 Self-cleaning liners (main oven) The main oven is equipped with continuous self-cleaning enamelled liners. These liners make the oven easier to clean and ensure its efficiency over time. 10.3.2 Using the self-cleaning liners Periodically, to prevent food residues and unpleasant smells from accumulating inside the oven, the appliance should be operated empty at temperatures of not less than 200°C for a time varying from 30 to 60 minutes, in order to allow the self-cleaning liners to oxidise the residues...

  • Page 28: Extraordinary Maintenance

    Instructions for the user 11.EXTRAORDINARY MAINTENANCE Ovens periodically replacement of parts subject to wear and tear such as gaskets, electric bulbs etc. Specific instructions for each intervention of this type appear below. Before performing any operations requiring access to powered parts, switch off the power supply to the machine.
  • Page 29 Instructions for the user 11.2 Dismantling of the doors Hold the door on both sides with both hands near hinges A and raise levers B. Lift up the door forming an angle of about 45° and remove. To refit, slide the hinges A in the grooves, drop the door and release levers B.
