Delta Electronics SMT Power Inductor SIB86 Specification Sheet

SMT Power Inductor
SIB86 Type

Features

RoHS compliant.
Low profile (6.35mm max. height) SMD type.
Unshielded.
Self-leads, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.

Mechanical Dimension:

A

Electrical Characteristics:

L
PART NO.
(uH)
SIB86 - R33 0.33
SIB86 - R68 0.68
SIB86 - 1R0 1.00
SIB86 - 1R5 1.50
SIB86 - 2R2 2.20
SIB86 - 2R7 2.70
SIB86 - 3R3 3.30
SIB86 - 4R7 4.70
1. Tolerance of inductance: 20%.
2. Isat is the DC current which cause the inductance drop less than 10% of its nominal inductance without current.
3. Ir is the DC current which cause the surface temperature of the part increase less than 45
4. Operating temperature : -20
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
B
C
o
25 C : 100KHz, 0.1V
1 2
DCR Isat
(m )MAX (Adc)
2.0 20.0
5.0 13.0
6.0 11.0
8.0 9.0
11.0 7.8
12.0 7.0
14.0 6.4
18.0 5.4
o o
C to 105 C (including self-temperature rise).
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
4.0
1.5
10
3
Ir
(Adc)
16.0 4R7
12.0
3R3
10.0
2R7
9.0
2R2
7.4
6.6
1R5
5.9
4.8
1R0
1.00
R68
R33
0.10
0.10
77
UNIT:mm/inch
A = 13.2 / 0.520 Max.
B = 9.9 / 0.390 Max.
C = 6.35 / 0.250 Max.
1.00 10.00 100.00
CURRENT (A)
o
C.
