CABINET TYPE AIR CONDITIONER
OPERATION MANUAL AND INSTALLATION MANUAL
AP140S2SK1FA
AP140S2SK1FA(H)
AP160S2SK1FA(H)
No.0150561435
This product must only be installed or serviced by qualified personnel.
Please read this manual carefully before installation.This appliance is filled
with R32. Keep this manual for future reference.
Original instructions
Contents
3
5
7
8
9
10
13
14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Haier AP140S2SK1FA
Summary of Contents for Haier AP140S2SK1FA
-
Page 1: Table Of Contents
Operation Energy Saving Maintenance Troubleshooting Indoor & Outdoor Unit Connertion Installation Procedure AP140S2SK1FA AP140S2SK1FA(H) AP160S2SK1FA(H) No.0150561435 This product must only be installed or serviced by qualified personnel. Please read this manual carefully before installation.This appliance is filled with R32. Keep this manual for future reference. - Page 3 Haier Industrial Park, No.1 Haier road, Qingdao,P.R.China EUROPEAN REGULATIONS IMPORTANT INFORMATION REGA- CONFORMITY FOR THE MODELS RDING THE REFRIGERANT USED Contains fluorinated greenhouse gases covered by the Kyoto Protocol All the products are in conformity with the following European provision:...
-
Page 4: Cautions
Cautions Disposal of the old air conditioner Before disposing an old air conditioner that goes out of use, please make sure it's inoperative and safe. Unplug the air conditioner in order to avoid the risk of child entrapment. It must be noticed that air conditioner system contains refrigerants, which require specialized waste disposal. The valuable materials contained in a air conditioner can be recycled. - Page 5 Cautions Specifications The refrigerating circuit is leak-proof. The machine is adaptive in following situation Applicable ambient temperature range: max. DB/WB 32/23 C Indoor temperature min. DB/WB 18/14 C Cooling max. DB/WB 46/26 C Outdoor temperature min. DB/WB 10/6 C max. DB/WB 27 C Indoor temperature min.
-
Page 6: Parts And Functions
Parts and Functions AP140S2SK1FA AP140S2SK1FA(H) AP160S2SK1FA(H) SWING... -
Page 7: Functional Description
Parts and Functions External View of Remote Controller Functional description 1.ON/OFF Button: Remote Controller function description This remote Controller is a general remote Turning on the units:Press the button to turning on the Controller, and some functions are valid according units. -
Page 8: Operation
Operation 17.TIME Right-and-left SWING Angle adjustment (1) When the controller is on, you can only set the TIMER OFF. And Each time you press the button , the remote control will when the controller is off, you can only set the TIMER ON. display the following cycle: When the remote controller is off, press the button to enter... -
Page 9: Energy Saving
Energy Saving Keep proper room temperature Too cold or too warm is no good to your health, and power consumption will be increased as well. Proper temp. Air filter should be periodically cleaned If air filter is clogged, it will cause poor cooling and heating efficiency, higher power consumption and even problem may occur. -
Page 10: Maintenance
Maintenance Disconnect power supply Don't touch it with wet hand Don't wash with hot water or solvent to clean the unit Don't splash water directly on indoor unit. Don't spray any paint or insecticide on the unit. This could be very dangerous This will cause damage or even fire accident. -
Page 11: Troubleshooting
Troubleshooting Followings are not problems Sound of water flowings are not During unit start and operation or at stop, a swishing or gurgling noise may problems. be heard. This noise is generated by refrigerant flowing in the system. Sound of cracking is heard. During unit operation, a cracking noise may be heard. -
Page 12: Poor Cooling
Troubleshooting Before asking services, please firstly check your unit according to following. Air conditioner won't start. Is power supply switch turned on? Is leakage current breaker activated? Is city power supply normal? This is very dangerous, please disconnect power supply immediately Power supply switch Power and contact your dealer. - Page 13 Troubleshooting LED flash times Malfunction of indoor PCB Contents of Malfunction Possible reasons display LED6 LED1 Malfunction of indoor unit Sensor disconected,or broken,or ambient temperature sensor at wrong position,or short circuit Malfunction of indoor unit Sensor disconected,or broken,or piping temperature sensor at wrong position,or short circuit The pressure switch is dama- Outdoor high pressure...
-
Page 14: Indoor & Outdoor Unit Connertion
Indoor & Outdoor Unit Connection Installation figure please refers to AP60KS1ERA(S) AP160S2SK1FA(H) pipe direction Left Rear Right Bottom... -
Page 15: Installation Procedure
Installation Procedure Installation Preparation Tools necessary Installation accessories Following parts shall be field supplied 1. Screw driver 2. Hacksaw Part name 3. 70mm dia. hole core drill Adhesive tape 4. Spanner (dia. 22, 36mm) 5. Spanner (16, 18, 22, 36mm) Pipe clip 6. - Page 16 Installation Procedure Indoor Unit Selection of indoor unit installation place Place where it is easy to route drainage pipe and outdoor piping. Place away from heat source and with less direct sunlight. Place where cool and warm air could be delivered evenly to every corner of the room. Place near power supply socket.
-
Page 17: Piping Connection
Installation Procedure Piping Connection Connecting method Apply refrigerant oil at half union and flare nut. To bend a pipe, give the roundness as large as possible not to crash the pipe. When connecting pipe, hold the pipe centre to centre then screw nut on by hand, refer to Fig. Be careful not to let sundries, such as sands enter the pipe. -
Page 18: Electrical Wiring
Installation Procedure Electrical wiring Note: Electrical wiring must be done by qualified person. The power supply connects from the outdoor unit. The connecting cable and power cable are self-provided. Use copper wire only. Air conditioner must use an exclusive line (over 30A) When installing air conditioner in a wet place, try to use a circuit breaker against current leakage. - Page 19 Installation Procedure Test Run Installation inspection and test run: Please operate unit according to this Manual. Items to be checked during test run. Please made a " " in " " Are there any gas leakage? How is insulation at piping connection carried out? Are electric wires of indoor and outdoor unit firmly inserted into terminal block? Is electric wiring of indoor and outdoor securely fixed? Is drainage securely carried out?
- Page 20 Address:Haier Industrial Park,Qianwangang Road,Eco-Tech Development Zone,Qingdao 266555,Shandong,P.R.China. Contacts: TEL +86-532-88936943; FAX +86-532-8893-6999 Website: www.haier.com...
