Remington PROluxe CI91AW Manual

PARTS

Adjustable barrel dial
Adjustable barrel
Fixed barrel
Temperature indicator lights
Barrel lock

Swivel cord Controls:
On/off button
+/– Temperature functions

ADDITIONAL FEATURES

Fast heat up—ready to use in 30 seconds.
Automatic safety shut off – this unit will switch itself off if no button is pressed or it is left on after 60 minutes.

INSTRUCTIONS FOR USE

Before use, ensure the hair is clean, dry and tangle-free.
For extra protection use a heat protection spray.
Section the hair prior to styling. Style the lower layers first.

Selecting the style
Use the adjustable barrel dial to set the wave style:

Pull the dial outwards (fig. A)
While holding the dial out, rotate it clockwise to lower, or counter clockwise to raise the adjustable barrel (fig. B). The dial moves one half turn (180º) between each setting. Note that if the barrel is at it's lowest position (style 1), you won't be able to turn the dial clockwise.
Once the desired setting is selected, release the dial and it will return to its rest position (fig. C).

Style	Adjustable Barrel Position
Style 1 Undone, tousled waves
Style 2 Flowing, mermaid waves
Style 3 Loose, beach waves
Style 4 Deep, defined waves

Using

Select the desired style using the adjustable barrel dial.
Plug the product into the mains power supply.
Press and hold the on/off (C) button to switch on.
Select the appropriate temperature for your hair type using the "+" and "-" temperature controls on the side of the product. Start styling on lower temperatures first.
The "+" button will increase the temperature and the "-" button will decrease the temperature.

Recommended Temperatures

Temperature	Hair type
150°C - 175°C	Thin / fine, damaged or bleached hair
185°C - 195°C	Normal, healthy hair
210°C	Thick and difficult to style hair

the hottest temperatures should only be used by experienced stylers.

The temperature display LED will flash until the selected temperature is reached.
Take a section of hair and place it between the barrels at the point of where you want the wave to start.
Clamp the section of hair by closing the barrels together and hold in place for 5-8 seconds
Open the barrel and move your waver down the section of hair, positioning it where you want the next wave to start.
Repeat this around the head to create as many waves as desired.

After use, press and hold the on/off (C) button to turn off then unplug the appliance.
Tip: let the waves cool before styling or brushing; this will help to prolong the style.

Pro+ Setting

To activate the PRO+ setting, press and hold the + button for 2 seconds. This will select a temperature of 185ºC for healthier styling. PRO+ will appear on the display.

Temperature Lock Function

Set the desired temperature using the + and - buttons then lock the settings by pressing the "-" button for 2 seconds. The light will come on.
To unlock the temperature setting, press and hold the "-" button for 2 seconds.

STORAGE, CLEANING AND MAINTENANCE

Let the appliance cool down before cleaning and storing away

Wipe all the surfaces with a damp cloth.
Don't use harsh or abrasive cleaning agents or solvents.

The barrels can be locked together for easy storage
To lock, close the barrels and move the barrel lock to the locked position
To unlock move the barrel lock to the unlocked position
NOTE: Do not heat the unit in the locked position

Please read these instructions carefully and keep them safe. Remove all packaging before use.

This appliance is hot. Keep out of reach of children at all times.

IMPORTANT SAFEGUARDS

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been supervised/instructed and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be done by children unless they are older than 8 and supervised. Keep the appliance and cable out of reach of children under 8 years.
Do not use this appliance near bathtubs, showers, basins or other vessels containing water.
When the appliance is used in a bathroom, unplug it after use since the proximity of water presents a hazard even when the applaince is switched off.
For additional protection, the installation of a residual current device (RCD) having a rated residual operating current not exceeding 30 mA is advisable in the electrical circuit supplying the bathroom*.
* Currently, the fitting in a bathroom of an electrical socket suitable or capable of operating the appliance is not permitted in the UK (see BS7671).
Burn hazard. Keep the appliance out of reach from young children, particularly during use and while cooling down.
Never leave the appliance unattended when it is connected to the power supply.
Always place the appliance with its stand, if any, on a heat-resistant, stable flat surface.
If the supply cord of this unit becomes damaged, discontinue use immediately and return the appliance to your nearest authorised Remington® service dealer for repair or replacement in order to avoid a hazard.

Do not allow any part of the appliance touch the face, neck or scalp.
Keep the power plug and cord away from heated surfaces.
Do not use attachments other than those we supply.
Do not use the appliance if it is damaged or malfunctions.
Do not twist or kink the cable, or wrap it round the appliance. Check the cord regularly for any sign damage.
This appliance is not intended for commercial or salon use.
