Spire
Assembly manual
White
1063711
Spire
1063712
Spire
1063713
Spire
1063714
Spire
royalwell.nl
royalwell.be
Greengrey
Black
1063706
1063716
1063707
1063717
1063708
1063718
1063709
1063719
royalwellserres.fr
Height (mm)
Width (mm)
2145
1915
2145
1915
2145
1915
2145
1915
m
Depth (mm)
1915
3,7
2525
4,8
3135
6,0
3745
7,2
Advertisement
Related Manuals for Royal Well Spire 1063711
Summary of Contents for Royal Well Spire 1063711
- Page 1 Spire Assembly manual Greengrey White Black Height (mm) Depth (mm) Width (mm) 1063711 1063706 1063716 2145 1915 1915 Spire 1063712 1063707 1063717 2145 1915 2525 Spire 1063713 1063708 1063718 2145 1915 3135 Spire 1063714 1063709 1063719 2145 1915 3745 Spire royalwell.nl royalwell.be royalwellserres.fr...
- Page 2 STATEMENT Dear customer! We congratulate you on your new greenhouse. We are convinced that by following the detailed assembly instructions you will enjoy the actual building of the greenhouse as much as the time you will spend in your greenhouse in the future. The assembly instruction consists mainly of detailed illustrations. The greenhouse is packed in a box/boxes and includes the frame, fixing materials, downspout and foundation.
-
Page 3: Section Overview
SECTION OVERVIEW Section Section Profile Part no. Size in mm Part no. Profile Size in mm Spire Spire Spire Spire Spire Spire Spire Spire 6970 1886 6027 1836 6028 2446 6062 1415 6603 1107 6029 3066 6030 3666 6604 1107 6054 4276 6063... - Page 4 FRONT GABLE 6970 6062 6603 6604 6063 6064 6007 6067 6609 6060 mm 1886 1415 1107 1107 1857 1857 1494 M6x10 6603 6604 6603 6604 6609 6007 6007 6062 6063 6064 6062 6067 6067 6970...
- Page 5 FRONT GABLE 6604 6609 6007 6064 6064 6604 6060 6007 6067 6062 6064 6062 6067 6970 6970...
- Page 6 REAR GABLE 6920 6062 6613 6614 6063 6064 6031 6067 6060 1886 1415 1107 1107 1857 1857 1808 1494 M6x10 6613 6614 6613 6614 6031 6062 6063 6064 6062 6067 6067 6920...
- Page 7 REAR GABLE 6614 6031 6064 6614 6060 6031 6067 6062 6064 6062 6067 6920 6920...
- Page 8 SIDE WALL 6972 6973 6974 6975 6976 6066 6022 6023 6024 6025 6053 6074 mm 1886 2496 3106 3716 4326 1415 1836 2446 3056 3666 4276 1500 M6x10 M6 Spire 3,7 Spire 4,8 Spire 6,0 Spire 7,2 6022 Spire 3,6 6066 6023 Spire 4,8...
- Page 9 SIDE WALL SPIRE 7,2 SPIRE 6,0 SPIRE 4,8 SPIRE 3,7...
- Page 10 ROOF 6027 6028 6029 6030 6054 6635 6041 1836 2446 3056 3666 4276 1107 M6X10 SPIRE 3,7 SPIRE 4,8 SPIRE 6,0 SPIRE 7,2 6635 6635 6041 6635 6041 6635...
- Page 11 DOOR Door brush 6652 6675 6676 6077 6049 mm 1225 588 588 1802 378 M6x10 M6 Φ3.5x19 Φ3.5x35 M4x8 1802 1000 6675 6675 6077 6077 6077 6676 6077 6676 6676 6077 6077 6676 6676 6652 6049 6049 6652 a1/a2...
- Page 12 Cut a rubber piece about 20 mm long (part #p10) to fill the space between the glass and the aluminium frame on the inside of the greenhouse; 4 pieces per glass panel, at 4 corners. The door package includes a rubber piece of 1 metre long.
- Page 13 VENT 6037 6038 6039 6055 M6x10 M4x8 Φ4.2x9.5 spire 3,7 spire 4,8 spire 6,0 spire 7,2 6038 6037 6038 6037 6038 6039 6039 6055 6055...
- Page 14 VENT 6039 Section view On either side of the vent. p3/a4 Refer to page 12 of this manual on rubber parts (part #p10) for the skylight before installing the vent in the garden greenhouse.
- Page 15 GLASS If you are also going to mount shelf(s) and table(s) in this greenhouse, drill holes in the outer profiles and mount the shelf(s) and table(s) before installing the glass. More information can be found in the manual of the shelf(s) and table(s). Glazing tape Glazing tape spire 3,7 spire 4,8 spire 6,0 spire 7,2...
- Page 16 GLASS Step 1 Step 2 When glazing the roof: first insert the top end of the glass into the Roof ridge channel. Then insert the bottom end of the panel into the gutter. First apply glazing tape with masking paper to the frame, ridge beam and gutter and only remove the masking paper from the glazing tape before fitting the glass panels.
- Page 17 GLASS Use PVC bar capping & glazing tape to secure panels. SPIRE 3,7 SPIRE 4,8 SPIRE 6,0 SPIRE 7,2 Sizes in mm 602 x 22 / 444 602 x 585 598 x 18 / 227 / 18 602 x 449 / 660 / 449 602 x 1412 602 x 599 594 x 507...
- Page 18 GLASS Glass Glass Glass Use PVC bar capping & glazing tape to secure panels. PVC bar capping PVC bar capping Length in mm Length in mm spire 3,7 spire 4,8 spire 6,0 spire 7,2 spire 3,7 spire 4,8 spire 6,0 spire 7,2 1413 1413 1840...
- Page 19 DOWNPIPE Attach clip * We recommend attaching P9 with superglue, which we do not supply.
- Page 20 Drill holes in the surface at the height of the hole of the supplied base brackets (m5), insert a wall plug in each hole and finally screw a screw in each hole. Outdoor Life Group Nederland Gouderak B.V. is the owner of the Royal Well brand. (Construction) changes reserved.
