- Page 1 SPIREHUSET Assembly manual Height (mm) Width (mm) Depth (mm) Black White 1063787 1063789 0,91 Spirehuset 0,91 1063790 1063792 1,34 Spirehuset 1,34 royalwell.nl royalwell.be royalwellserres.fr...
- Page 2 STATEMENT Dear customer! We congratulate you on your new greenhouse. We are sure that by following the detailed assembly instruction you will enjoy the actual building of the greenhouse as much as the time you will spend in your greenhouse in the future. The assembly instruction consists mainly of detailed illustrations. All aluminium profiles are marked with a part number corresponding to the numbers on the drawings and in the parts list.
- Page 3 OVERVIEW TOOLS FITTINGS 10 11 0,91 1,34 ×12 12 13 ×10...
- Page 4 FOUNDATION 0,91 1,34 0,91 1,34 A2 / A3 Terrace condition...
- Page 5 FRONT GABLE Spirehuset 0,91m² 120A 723P 119A Bottom Bottom 0,91 723P 119A 1241 119A 1508 6×12 6×12 120A 1508 723P 1508 1241 6×12 119A 723P...
- Page 6 FRONT GABLE Spirehuset 1,34m² 120A 723P 723P 119A 1,34 Bottom Bottom 723P 119A 1862 119A 1508 6×12 6×12 120A 1508 723P 1508 1862 6×12 119A 723P...
- Page 7 ROOF & SIDE WALL Spirehuset 0,91m² 0,91 121A 1753 122A 1753 121A 122A 119A 723P 120A 1241 6×12 Roof Side Wall Side Wall 120A 122A 6×12 120A 6×12 6×12 Roof Roof Roof 6×12 6×12 723P 122A...
- Page 8 ROOF & SIDE WALL Spirehuset 1,34m² 1,34 121A 1753 122A 1753 121A 119A 723P 122A 1862 723P 120A 6×12 Side Wall Side Wall Roof 120A 122A 6×12 6×12 120A 6×12 Roof Roof Roof 6×12 6×12 122A 723P...
- Page 9 FIXATION TO BASE 111/112 122A 121A 0,91 1,34 111/ 121/...
- Page 10 DOOR Glass E Glass F Glass Glass E Glass 0,91 1,34 1485 M6 x12 M4 x16...
- Page 11 DOOR slide into profile slide into profile Spirehuset 0,91m² Spirehuset 1,34m²...
- Page 12 WINDOWS 1738 Glass 8588 8617 8632 0,91 1,34 1738 1738 1738 6×10 8632 6×10 8616 8617 3.5×6 M6×10 Glass B 8588 8632 6×10 6×10 8632 Glass B...
- Page 13 WINDOWS slide into profile 8617 111/112 8632 8617 8616 106/107 8616...
- Page 14 GLASS GLASS GLASS GLASS GLASS H - Strip GLASS H - Strip GLASS...
- Page 15 GLASS 0,91 1,34 1755 1510...
