Greenfield A22521K Owner's Manual

18/34 steel deck, 24/34 steel deck
Hide thumbs

Advertisement

Table of Contents

Owners Manual
Model A22521K
Product GC18C34
18/34 Steel Deck
READ THIS MANUAL BEFORE OPERATING MACHINE
DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UN-
LESS INSTRUCTIONS IN THIS MANUAL ARE FOLLOWED
NOTE: Bring this Manual when Service & or Warranty work is required.
REGISTER YOUR WARRANTY ONLINE
Use the QR code or go to http://www.coxmowers.com.au/warranty-registration
Model A22521K
Product GD24C34
24/34 Steel Deck

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A22521K and is the answer not in the manual?

Questions and answers

Related Manuals for Greenfield A22521K

Summary of Contents for Greenfield A22521K

  • Page 1 Owners Manual Model A22521K Model A22521K Product GC18C34 Product GD24C34 18/34 Steel Deck 24/34 Steel Deck READ THIS MANUAL BEFORE OPERATING MACHINE DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UN- LESS INSTRUCTIONS IN THIS MANUAL ARE FOLLOWED NOTE: Bring this Manual when Service & or Warranty work is required.
  • Page 8 GTC02868 GTC02929 GTC02956 GTC02957 GTC02958 GTC10488 GTC02861 GTC02425...
  • Page 10 34” Drive V Belt - GTC02369 34” Cutter V Belt - V78 34” Cutter Blade and Bolt, Nut & Washer Set - GTC02139...
  • Page 18 We are proud that you have purchased a Greenfield Ride-on and urge you to follow these instructions to obtain the maximum life for your machine. If in doubt check with your Dealer. MAINTENANCE SCHEDULE BEFORE EACH USE Check engine oil level, adjust if required Check mowing attachment cutter blades, bolts, nuts, Check engine air cleaner &...
  • Page 19 6 MONTHS OR 50 HOURS which ever occurs first Change engine oil Check mowing attachment electric clutch brake air gap, adjust If fitted clean engine exhaust spark arrester if req. Check engine air cleaner & foam pre-cleaner, service if req * Check mowing attachment electromagnetic clutch/brake for Check engine rotating screen/finger guard, clean if required * operation, service if required...
  • Page 20 18 MONTHS OR 150 HOURS which ever occurs first Change engine oil. Check steering chain and sprockets for wear, adjust if If fitted clean engine exhaust spark arrestor. required. Check engine air cleaner & foam pre-cleaner, service if Grease stub axles *. req*.
  • Page 21 30 MONTHS OR 250 HOURS which ever occurs first Change engine oil. Check mowing attachment electric clutch brake air gap, adjust If fitted clean engine exhaust spark arrestor. if req. Check engine air cleaner & foam pre-cleaner, service if req*. Check mowing attachment cutter blades, bolts, nuts, Check engine rotating screen/finger guard, clean if req *.
  • Page 22 42 MONTHS OR 350 HOURS which ever occurs first If fitted replace engine oil filter Change engine oil Check belts for wear or damage, replace if required Check engine spark plug, clean, adjust, or replace if required Check battery condition, service if required If fitted clean engine exhaust spark arrestor Check for loose fasteners, tighten if required Check engine air cleaner &...
  • Page 23 54 MONTHS OR 450 HOURS which ever occurs first If fitted replace engine oil filter Change engine oil Check belts for wear or damage, replace if required Check engine spark plug, clean, adjust, or replace if required Check battery condition, service if required If fitted clean engine exhaust spark arrestor Check for loose fasteners, tighten if required Check engine air cleaner &...

  • Page 24: Idler Pulleys - Drive Belt

    IDLER PULLEYS - DRIVE BELT...
  • Page 25 ITEM PART NUMBER DESCRIPTION GTC02015 High Tensile Cap Screw GTC16317 Washer GTC02602 V-Pulley GTC01009 Flat Idler Pulley GTC01012 Washer GTC02466 Nyloc Nut M10 SH0820M Bolt,Hex,M8X20,Pc8.8 GTC01020 Nyloc Nut M8 GTC18312 Bracket GTC00118 Bolt SH0825M Bolt,Hex,M8X25,Pc8.8...

  • Page 26: Engine And Electrical

    ENGINE AND ELECTRICAL...
  • Page 27 ENGINE AND ELECTRICAL ITEM PART NUMBER DESCRIPTION GTC22194 Clamp - Fuel Tank Screws, Hex, Socket with Collar,M6X20 Spring Nuts Type B,M6 GTC02249 Cap - Fuel Tank GTC02579 Fuel Tank A210224 Seal, Petrol Tap A210223 Petrol Tap RM00907 Fuel Hose GTC02309 Fuel Filter GTC02221 Hose Clamp...

  • Page 28: Electrical Circuit

    ELECTRICAL CIRCUIT...
  • Page 29 ELECTRICAL CIRCUIT ITEM PART NUMBER DESCRIPTION GTC06129 Red Cable - Solenoid to Starter Motor GTC14364 Red Cable - Battery to Solenoid GTC14370 Black Cable -Battery to Engine Ground GTC20219 Red Wire - Key Switch to Hour Meter GTC22047 Wiring Harness- Key Switch GTC20216 Red Wire - Warning Light GTC20215...

  • Page 30: Drive Clutch

    DRIVE CLUTCH ITEM PART NUMBER DESCRIPTION GTC20945 Yoke Unit GTC14309 Clutch Link GTC02036 Spring Clip SH0816M Bolt,Hex,M8X16,PC8.8 GTC23470 Steady - Clutch Yoke GTC01020 Nyloc Nut M8 GTC02057 Retainer GTC20405 Pivot Arm Assembly GTC18785 F - R Link GTC22151 Support GTC20395 Pivot Pin Assembly SH0825M Bolt,Hex,M8X25,PC8.8...
  • Page 31 LINKAGES- CUTTER HEIGHT ITEM PART NUMBER DESCRIPTION GTC01565 Knob GTC18705 Handle Washer GTC07071 Spring - Compression GTC02466 Nyloc Nut M10 GTC21285 Height Adjuster Rack BCHSNM8X20 Bolt,Cup,Sq Neck M8X20 PC8.8 SH0820M Bolt,Hex,M8X20,Pc8.8 GTC18313 Pivot Bracket GTC18314 Packer GTC01020 Nyloc Nut M8 GTC18820 Height Adjuster Shaft GTC20006...
  • Page 32 LINKAGES- NOTCH BAR ITEM PART NUMBER DESCRIPTION GTC07308 Anchor - Spring GTC20006 Spring - Tension GTC18765 Notch Bar GTC00608 Slide Bush GTC18760 Bracket GTC00023 Washer GTC00579 Wave Washer GTC02602 V Pulley GTC01012 Washer GTC02466 Nyloc Nut M10 SH0825M Bolt,Hex,M8X25,PC8.8 SH1020M Bolt,Hex,M10X20,PC8.8 GTC14023 Leaf Spring...
  • Page 33 LINKAGES- FOOT AND HAND BRAKE ITEM PART NUMBER DESCRIPTION GTC22920 Brake pad unit GTC01020 Nyloc Nut M8 GTC15270 Anchor - brake pad SH0820M Bolt,Hex,M8X20,Pc8.8 Nut M8 GTC01023 Adjusting screw GTC02466 Nyloc Nut M10 GTC00579 Wave washer GTC22485 Brake arm 34” model GTC22177 Pivot bush GTC22176...
  • Page 34 DRIVE CLUTCH...
  • Page 35 DRIVE CLUTCH ITEM PART NUMBER DESCRIPTION GTC06012 Clutch Lining USE ITEM 23 Drive Plate GT22174 Drive Block Rubber PR0206 Rivets GTC20510 Yoke - Top Half GTC20191 Retainer GTC20515 Yoke - Bottom Half GTC20935 Clutch Bearing Unit B0830M Bolt, Hex, M8X30, Pc8.8 GTC01020 Nyloc Nut M8 GTC22470...
  • Page 36 Rear Axle-Deluxe Model...
  • Page 37 Rear Axle-Deluxe Model Index Part Number Description GTC18006 Drive Chain S231904 Connecting link GTC2525 Bolt M8X80 Bolt/Nut lock GTC2982 Chain Sprocket GTC2938 Bronze Bush GTC2978 Housing GTC2987 Wear Plate O Ring 114.3x1.78 GTC2985 Spindle GTC2988 Idler Gear GTC2519 Cone Lock Nut GTC2836 Hollow Shaft Assy GTC2940...
  • Page 38 STEERING & FRONT AXLE...
  • Page 39 STEERING & FRONT AXLE ITEM PART NUMBER DESCRIPTION GTC20530 Axle Beam GTC02476 Bolt M16X50 GTC02042 Nyloc Nut M16 GTC00520 Socket Grub Screw GTC07009 Collar GTC01766 Bush GTC01924 Grease Nipple Washer 6.4X12X1.6 GTC20545 L.H. King Pin GTC20540 R.H. King Pin GTC22185 Bush GTC07304 Washer...

  • Page 40: Body Work And Seat

    BODY WORK AND SEAT...
  • Page 41 BODY WORK AND SEAT Index Part Number Description GTC20570 Muffler Guard/ Bumper - Twin Cyl GTC06081 Plastic Bung - Bumper Bar Bolt, Hex ,M10X20, PC8.8 W10MN Washer 10.5x20x2 Lock Nut M10 GTC22611 Bonnet - Deluxe RM906 X 1m Pinch Weld - front or rear GTC07015 Strap - Bonnet Screw,Cross Pan Head ,M5X12 PC8.8...
  • Page 42 Cutter Deck Idler Pulleys...
  • Page 43 Cutter Deck Idler Pulleys ITEM PART NUMBER DESCRIPTION GTC13280 Retainer GTC18855 Fixed pulley bracket GT02592 V pulley & bearing GTC22655 L.H. belt guide Bolt,Hex,M10x60,PC8.8 Washer 11x25x1.5 GTC02466 Nyloc Nut M10 Washer 8.4x16x1.6 GTC01020 Nyloc Nut M8 Bolt,cup,sq neck M8X20,PC8.8 GTC22315 Rail assembly GTC01766 Bush...
  • Page 44 Cutter Deck 34”...
  • Page 45 Cutter Deck 34” ITEM PART NUMBER DESCRIPTION GTC20162 34” cutter deck drilled casting GTC20192 Stiffener - 34” only Nyloc nut M8 Bolt,cup,sq neck M8X25,PC8.8 Washer 8.4x16x1.6 Bolt,cup,thin sq neck M8X20,PC8.8 GTC02466 Nyloc nut GTC20936 Stone guard Bolt,Hex,M10x90,PC8.8 GTC02263 Jockey wheel GTC20049 Bush GTC01012...
  • Page 46 COX INDUSTRIES MOWER WARRANTY POLICY DEFINITIONS: purchase, model, make and serial number of the Mower. The effective transfer “Commercial Use” means all uses other than Domestic use, including any use of this Warranty does not otherwise alter the terms of this Warranty in any way. that is income producing, rental, or is in relation to use in schools, by government departments or charity operators.
  • Page 47 COX INDUSTRIES (AUST) PTY LTD coxmowers.com.au Email: sales@coxmowers.com.au...

This manual is also suitable for:

Gc18c34Gd24c34
