  • Page 1 25/32 Standard 25/32 Steel Deck Model GT22895 Model GT22900 Model GT22885 17.5/34 Deluxe 25/34 V-Twin Deluxe 25/42 V-Twin Deluxe Greenfield Mowers Pty Ltd 123 Boundary Rd, Rocklea. QLD 4106 Ph: (07) 3875 9400 F: (07) 3875 9425 E: info@greenfield.com.au www.greenfield.com.au...
  • Page 2: Table Of Contents

    Contents Safety instructions Operating Instructions Mowing on Slopes Differential Instructions General Maintenance Brake System Cutting System Drive System Steering Adjustment Chain Adjustment Electrical Circuits Spare Parts Idler Pulleys - Drive Belt Linkages - Cutter Clutch and Drive Clutch Linkages - Brakes, Cutter Height and Notch Bar Engine and Electrics Drive Clutch and rear Axle Steering and Front Axle...
  • Page 3: Safety Instructions

    Before operating the mower, read the owner’s manual carefully. Your Greenfield has been designed to meet stringent safety standards - but we remind you that a mower is a cutting device - used incorrectly, it may cause personal injury or death.
  • Page 4 13. Use only an approved container for storing fuel. Never store fuel or the fueled machine in an unventilated area or near a source of ignition such as electrical switches or a gas hot water heater. 14. Do not run the engine in a confined space where carbon monoxide and poisonous exhaust fumes can collect. Carbon monoxide is a colourless, odourless, deadly poisonous gas.
  • Page 5 Safety Instructions The following images depict and describe safety symbols that may appear on this product. Please read, understand, and follow all of the safety instructions before attempting to assemble or operate this product. Read The Operator’s Manual(s) - Read, understand, and follow all instructions noted in the manual(s) before attempting to operate.
  • Page 6: Operating Instructions

    On twin cylinder models with separate choke control, push the CHOKE in fully for correct engine operation. Important - This Greenfield mower is fitted with a safety ‘Cut-Out’ switch, activated by the seat. The operator must be seated to start the engine and remain seated while operating the mower. If the operator does not remain seated, the engine will stop.
  • Page 7 Sudden or violent directional changes and/ or wheel spinning must be avoided. For a detailed explanation of the braking systems on this Greenfield FastCut mower, see the section on Braking Systems pg.12.
  • Page 8: Mowing On Slopes

    Mowing on Slopes Exercise extreme caution when operating a ride-on mower on a slope. Slopes are a major cause of tip-over and loss of control accidents involving ride-on mowers. Severe injury or death can occur. On any slope, the differential action must be locked out for best traction and braking i.e. both rear wheels driving. Speed should be reduced on slopes, particularly when changing direction.
  • Page 9: Differential Instructions

    Greenfield differentials are fully lubricated and sealed for life at the factory. If in the unlikely event that your differential needs service, it must be returned to Greenfield intact. Differentials that have been tampered with or dismantled will NOT be considered for warranty.
  • Page 10: General Maintenance

    Maintenance Warning: Remove the spark plug lead to avoid accidental starting BEFORE attempting any maintenance or inspection of the mower. Crankcase Lubrication Change the engine oil after the first five (5) hours of operation, then every six (6) months or twenty five (25) working hours, whichever comes first.
  • Page 11: Cutter Blades

    • The best way to clean your Greenfield is to use an air hose to blow loose grass, etc. from around pulleys, belts, and the top of the cutter deck. Wash the exterior with a sponge and bucket, then rinse off with a hose and wipe it down the same way as you would a car.
  • Page 12: Brake System

    Greenfield FastCut Braking Systems This Greenfield ride-on mower is equipped with a multi-purpose Drive/Brake Control Pedal, operated by the driver’s right foot. It also has an Emergency Brake operated by the left foot and a hand operated Parking Brake. All three systems are completely independent of one another.
  • Page 13: Cutting System

    Illustration B Brake Pads Adjustment Screw & Lock Nut Pad Retainer Bolt Pad Retainer Cutting System Cutter Deck Adjustment Before checking TILT, which is the forward slant on the Cutter Deck from front to rear, or TRIM, which holds the Cutter Deck level side to side, first check the tyres are inflated to correct pressures.
  • Page 14 Cutter Belt Adjustment Warning: Remove the spark plug lead to avoid accidental starting BEFORE attempting any maintenance or inspection of the mower. The self-adjusting belt tensioner will automatically adjust to compensate for normal wear and stretch of the V belt. However, as most belt stretch occurs during the early operating hours of the new belt, the first adjustment should be checked after approximately five (5) hours of operation with further checks at the fifty (50) hour services.
  • Page 15 Cutter V Belt Run Cutter V B el t Ru n Illust ration Electric Clutch 42” GT02630 Cutter V Belt GT02627 Cutter V-Pulley Belt Guide Sliding Bracket Pulley Fixed Bracket Pulley * GT22655 Belt Guide LH * GT22656 Belt Guide RH GT02466 Nyloc Nut GT02466 Nyloc Nut Note location and lower alignment hole width for Belt Guide.
  • Page 16: Drive System

    Drive System To Remove Drive V Belt Illustration F 1. Remove the spark plug lead to prevent accidental starting. 2. Remove the rear cover as follows - Lift up the seat and disconnect the wire to the seat cut out switch by separating the spade connector on the blue wire near the top of the battery.
  • Page 17: Steering Adjustment

    Steering Stop Adjustment The steering stops (Item B) are readily seen and accessible from under the right hand side of the chassis with the cutter deck in the LOW position. Adjustments should not be necessary, unless the steering has been damaged. 1.
  • Page 18: Chain Adjustment

    Chain Adjustments Rear Drive Chain Adjustment 1. Remove the spark plug lead to prevent accidental starting. 2. Remove the rear cover as follows - Lift up the seat and disconnect the wire to the seat cut out switch by separating the spade connector on the blue wire near the top of the battery. Undo the star knob at the top rear of the rear cover and position the height adjustment lever in a mid height position.
  • Page 19: Electrical Circuits

    Electrical Circuits Hour Meter PTO Switch Magnetic Clutch Starter & Brake Motor Key Switch Battery Starter Solenoid Lights Seat Switch Fuse Pressure Red Warning Light Switch Light Switches Index Part No. Description Colour Legend GT 6129 Red Cable - Solenoid to Starter Motor B - Black Red Cable - Battery to Solenoid O - Orange...
  • Page 20: Spare Parts

    Idler Pulleys - Drive Belt Square Hole Hex Wrench Use this pulley mounting hole Assembly of Allignment Pulleys Assembly of Flat Idler Pulleys Index Part Number Description Index Part Number Description GT02015 High tensile cap screw GT02466 Nyloc Nut GT16317 Washer GT01455 Bolt...
  • Page 21 To Remove V Alignment or Flat Pulleys 1. Hold the H.T. cap screw firmly by using a 5/16” hexagon wrench inserted down a hole in the step through the floor area. 2. Remove the Nyloc Nut and washer from the end of the cap screw - remove the pulley. To Replace V Pulley or Flat Idler Pulley 1.
  • Page 22 Linkages Cutter Deck Idler Pulleys Drive Clutch Left Side Belt Guide Right Side Belt Guide Index Part Number Description Index Part Number Description GT02592 V pulley & bearing GT20945 Yoke unit GT20395 Pivot pin assembly Bearing adaptor - fitted to pulley GT22655 L.H.
  • Page 23 Linkages Cutter Height Notch Bar Foot and Hand Brake 14 13 Index Part Number Description Index Part Number Description GT15270 Anchor - brake pad GT20006 Spring - tension GT22920 Brake pad unit GT18775 Tensioner GT18660 Brake disc GT21285 Height adjuster rack GT12093 GT01565 Knob...
  • Page 24: Engine And Electrics

    Engine and Electrical Index Part Number Description Index Part Number Description 17.5HP single cylinder engine GT20169 Throttle lever 25HP twin cylinder engine GT02026 Knob - throttle lever GT18047 Crankshaft spacer GT01252 Cable clamp GT22049 Pulley - engine GT20057 Choke cable - where fitted GT05542 GT20913 Throttle cable - single cyl...
  • Page 25: Drive Clutch And Rear Axle

    Drive Clutch & Rear Axle Tube 32 Solid Axel Model 34 Differential Model Index Part Number Description Index Part Number Description GT18006 Roller chain GT07017 Bearing plates GT00501 Connecting link GT00347 GT20510 Yoke - top half GT07303 Washer GT20191 Retainer GT00357 Spring GT20935...
  • Page 26: Steering And Front Axle

    Steering & Front axle Tube Index Part Number Description Index Part Number Description GT20540 R.H. king pin GT21345 Axle beam - 32” model GT07304 Washer GT20530 Axle beam - 34” model GT01766 Bush GT01924 Grease nipple GT07009 Collar GT13813 Roller chain complete GT18078 Tie rod - 32”...
  • Page 27: Cutter Deck 32 /34

    Cutter Deck 32 /34 Index Part Number Description Index Part Number Description GT22158 32” cutter deck drilled casting GT22159 Bottom link GT20162 34” cutter deck drilled casting GT01012 Washer GT20936 Stone guard GT02466 Nyloc nut GT02263 Jockey wheel GT20223 Spreader GT20049 Bush GT20192...
  • Page 28 Cutter Deck 42 Index Part Number Description Index Part Number Description GT22360 Cutter deck assembly GT00730 Bush GT20936 Stone guard GT02466 Nyloc nut GT22388 Pulley cover L.H. GT02627 V belt - cutters GT22389 Pulley cover R.H. GT02003 Nut M20 L.H. GT22053 Idle pulley adaptor GT14390...
  • Page 29: Body Work And Seat

    Body Work and Seat Decal Set Index Part Number Description Index Part Number Description GT22415 Front bumper - single cyl GT21340 Hinged seat base GT20570 Muffler guard/ bumper - twin cyl GT02367 Seat runners (set) GT22163 Grille - 32” model only GT02366 Seat GT22162...
  • Page 30: Warranty

    5. Any claim on the warranty must be notified to the authorized Greenfield dealer from whom you bought the mower or, if they are not reasonably close to you when you make the claim, then to any authorized Greenfield dealer conveniently close to you. You must give proof of purchase of the mower and provide the dealer with all information you can, and which the dealer might reasonably require about your claim, including where possible the claimed defective part.
  • Page 31 Warranty Registration Details Please Record Your Reference This record should be completed and held by the purchaser and presented should service under warranty be required. To register your warranty, please visit www.greenfield.com.au/product-registration/ or alternatively, complete and return the enclosed warranty card. Surname:...
