Summary of Contents for Greenfield GT03716
- Page 1 Owners Manual Instructions & Original Equipment Parts Listings Model GT03716 Model GT03030 Model GT03580 Grass Catcher Tip Trailer Dozer Blade Greenfield Mowers Pty Ltd 123 Boundary Rd, Rocklea. QLD 4106 Ph: (07) 3875 9400 F: (07) 3875 9425 E: info@greenfield.com.au www.greenfield.com.au...
-
Page 2: Table Of Contents
Contents Safety Instructions - Grass Catcher Fitting Instructions - Grass Catcher Assembly Instructions - Grass Catcher Catcher Mounting Arm Parts Listings - Catcher Operating Instructions - Grass Catcher Safety Instructions - Tip Trailer Spare Parts & Assembly - Tip Trailer Frame Assembly- Dozer Blade Blade Attachement &... -
Page 3: Safety Instructions - Grass Catcher
Thank you for purchasing an Australian made Greenfield attachment. Your Greenfield attachment is designed to be used as an accessory to your Greenfield FastCut ride-on lawn mower. Please ensure to follow the manufacturer’s safety, operating, and maintenance instructions for many years of trouble free operation and service. -
Page 4: Fitting Instructions - Grass Catcher
Fitting Instructions - Grass Catcher To Fit the Catcher Location Peg to the Cutter Deck 1. Fit the cup head bolt (GT00181) from the underside of the chute into the round hole between the two (2) stone guard fixing bolts. 2. -
Page 5: Assembly Instructions - Grass Catcher
Assembly Instructions - Grass Catcher Catcher arm to be halfway along slot. Figure 1 Figure 3 Skid attachment as seen with Catcher turned upside down. Pivot plate positioning as seen from under Catcher. Inside Catcher. Figure 2 Figure 4 Boot bracket attachment. Pivot plate attachment. -
Page 6: Catcher Mounting Arm
Catcher Mounting Arm Mounting Washers Clip Grip... -
Page 7: Parts Listings - Catcher
Parts List - Catcher Index Part # Description Qty Supplied GT03720 Catcher Body 30/32 L.H GT03611 Pivot Plate GT03612 Wear Plate GT03727 Spring Bracket GT03735 Lever GT03653 Boot Bracket GT03713 Spacer - 12mm GD05546 Knob GT00748 Spring GT02094 Grip Clip GT01022 Washer - 1/4”... -
Page 8: Operating Instructions - Grass Catcher
Parts List - Catcher Arm Index Part # Description Qty Supplied GT03711 Bracket Assmebly GT03717 Arm Assembly GT00218 Hitch Pin GT01020 Nyloc Nut - 5/16” UNC GT01451 Set Screw - 5/16” UNC x 1 ZP Operating Instructions - Grass Catcher 1. -
Page 9: Safety Instructions - Tip Trailer
1. Do not carry passengers. 2. Ensure the towing vehicle is in good condition. 3. This trailer has been specifically designed to be towed with a Greenfield ride-on mower. Use only the approved drawbar hitch as shown. 4. Limit loads to those you can safely control. This trailer weighs 30kg. The load should not exceed 120kg. -
Page 10: Spare Parts & Assembly - Tip Trailer
Spare Parts and Assembly - Tip Trailer Item Part# Description GT3031 Plastic Tray GT3035 Metal Pan GT3040 Axle Beam GT3045 Draw bar GT3055 Tie rail GT3060 Wheel comp. GT0628 Collar GT3053 Catch GT20009 Spring GT1234 Bolt GT2466 Nyloc nut GT1012 Washer GT0730 Bush... -
Page 11: Frame Assembly- Dozer Blade
Frame Assembly- Dozer Blade Item Part# Description GT01093 Bolt - 3/8” GT02466 Nyloc Nut - 3/8” x 1” GT09407 Thick Washer - 3/8” x 1” GT02246 Black PVC Cap GT12323 Spring Anchor GT01554 Tension Spring GT02444 Bolt - 1/2” UNC x 3” GT00023 Washer - 1/2”... -
Page 12: Blade Attachement & Articulation - Dozer Blade
Blade Attachment & Articulation Item Part# Description GT00023 Washer - 1/2” x 1” GT02495 Nyloc Nut - 1/2” UNC GT03565 Load Transfer Assembly GT03376 Bolt Retainer GT02494 Bilt - 1/2” UNC x 32 GT03390 Dozer Blade Assembly Blade Articulation The Blade can be used in the straight across position or up to 20 degrees angle to either side by loosening the two nuts on the bolt retainer. -
Page 13: Handle & Link Assembly - Dozer Blade
Handle & Link Assembly Item Part# Description GT02466 Nyloc Nut - 3/8” GT03575 Rear Link GT03832 Handle Assembly GT03573 Front Link GT03568 latch GT02242 Handle Grip GT01012 Washer - 3/8” x 7/8” GT00730 Pivot Bush GT01474 Cup HD Bolt - 3/8” x 1 1/4” GT02425 Screw - 1/4”...
