S e r v i c e L i t e r a t u r e

ML296UHVK(X) series units are 90% efficiency gas fur-

naces used for downflow applications only, manufactured

with Lennox Duralok heat exchangers formed of alumi-

nized steel. ML296UHVK(X) units are available in heating

capacities of 44,000 to 110,000 Btuh and cooling appli-

cations up to 5 tons. Refer to Engineering Handbook for

proper sizing.

Units are factory equipped for use with natural gas. Kits

are available for conversion to LPG operation. ML296U-

HVK(X) unit meets the California Nitrogen Oxides (NOx)

Standards and California Seasonal Efficiency require-

ments. All units use a redundant gas valve to assure safe-

ty shut-off as required by C.S.A.

All specifications in this manual are subject to change.

Procedures outlined in this manual are presented as a

recommendation only and do not supersede or replace lo-

cal or state codes. In the absence of local or state codes,

the guidelines and procedures outlined in this manual (ex-

cept where noted) are recommendations only and do not

constitute code

WARNING

This furnace is equipped with an ignition control

factory enabled for use with Lennox A2L refrigerant

systems.

Disabling

functionality on A2L system is prohibited by safety

codes. Refer to furnace installation instructions for

non-A2L and non-Lennox refrigerant system setup.

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2

Blower Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4

I Unit Components . . . . . . . . . . . . . . . . . . . . . . . . Page 7

II Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21

III Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 43

IV Heating System Service Checks

V Typical Operating Characteristics

VI Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . Page 47

VII Low GWP Application . . . . . . . . . . . . . . . . . . . . . Page 50

VIII Diagram and DIP Switch Settings. . . . . . . . . . .Page 53

UNIT INFORMATION

ML296UHVK(X) With R-454B SERIES UNITS

the

refrigerant

detection

. . . . . . . . . Page 44

. . . . . . . . . Page 47

100179

Improper

installation,

service or maintenance can cause property damage,

personal injury or loss of life. Installation and service

must be performed by a licensed professional HVAC

installer (or equivalent), service agency or the gas

supplier.

As with any mechanical equipment, contact with

sharp sheet metal edges can result in personal

injury. Take care while handling this equipment and

wear gloves and protective clothing.

ELECTROSTATIC DISCHARGE (ESD)

Precautions and Procedures

Electrostatic discharge can affect electronic

components. Take precautions to neutralize

electrostatic charge by touching your hand

and tools to metal prior to handling the

control.

Page 1

ML296UHVK(X)

C C C C

I I I I

WARNING

adjustment,

CAUTION

alteration,

Table of Contents
