Installation:
1.
Place the base plinths (B) onto the base of the tap (A).
2.
Place the upper seals (C) onto the base of the base plinths (B).
3.
Place the tap (A), base plinths (B) and upper seals (C) onto the bath (D).
4.
Pass lower seals (E) over the ¾" inlets, flush to the underside of the bath.
5.
Hand tighten the supplied fixing nuts (F) onto the inlets to hold the tap loosely.
6.
Ensure all parts are central to the bath holes (D) and will create a seal. With the product
correctly positioned tighten the fixing nuts (F) fully using an adjustable basin spanner or
similar.
7.
Connect the hot and cold feed pipes to inlets using the appropriate sized 3/4" fittings
(not supplied).
After Installation:
Once you have visually checked the new fittings and connections, ensure that all taps and drains are closed
except the new product which should be left open. Turn on (reconnect) the water supplies, check carefully for
leaks around the installation and product function. Once you are sure of no leaks, close the new product and
recheck for leaks, turn on the water heating power.
Clean and dry the product of any marks from installation then cover the product with the bag provided to
protect it until use.
Important Technical Data
Minimum operating pressure (Bath): 0.75 bar
Minimum operating pressure (Shower): 1.4 bar (without limiter)
Maximum operating pressure: 5.5 bar*
*If these temperatures or pressures are exceeded, even for short periods, damage can result and will void your warranty.
In these instances, reduce the incoming water temperature and or install a pressure reducing valve. Ensure that your Abode
product is fitted in accordance with Local Water Byelaws or regulations by a qualified installer.
These installation guidelines have been prepared for your direction and you must exercise due care at all times. We do not
accept responsibility for problems that may occur through improper installation. Whilst installing the product take care not to
accidentally loosen any screwed assemblies.
Manufacturers Product Reference: AB2823, AB2833, AB2843
Flow characteristics: Single flow
Maximum hot water temperature: 60°C*
Recommended hot water temperature: 46°C
©Abode - 03/2024
Unit L, Zenith Park, Whaley Road, Barnsley, S75 1HT
Tel: (+44) 01226 283434 or www.abodedesigns.co.uk
All errors and omissions excepted.
Aquip Bath Mixer
Warranty:
All Abode products are made using the highest quality materials and components, to ensure that
they meet or exceed all UK or European Standards.
All products are thoroughly tested, and quality checked.
All products are backed with a comprehensive warranty and we are confident that they will give
many years of trouble-free service.
The warranty applies to products used for normal domestic purposes and where the installation,
care and maintenance instructions have been observed.
The warranty extends to the original purchaser only.
Details of Warranty duration and Terms & Conditions for each product type can be found on our
website (www.abodedesigns.co.uk).
Important Care Instructions for your Product:
To maintain the appearance of this product, ensure that it is regularly cleaned only using a clean, soft damp
cloth. A solution of warm water and a mild liquid detergent may be used where necessary, and then the
fitting rinsed thoroughly and wiped dry. Any other cleaning action or use of common domestic cleaning
products will invalidate your warranty.
If the product has a plastic aerator insert at the end of the spout it should be unscrewed and the plastic internal
insert only removed and cleaned or descaled to maintain flow performance. Do not use descaling solution on
any decorative metal housing, rinse the insert thoroughly before reattaching in the reverse order.
Abrasive cleaners, scouring cleaners and acidic cleaners must not be used on this product under any
circumstances. Avoid contact with all solvents (including chlorinated solvents, ketones or acetones as these
may result in surface deterioration or etching). Also avoid contact with any harsh household chemicals such as
oven cleaners, drain cleaners, rust removers, paint strippers and toilet bowl cleaners, bar keepers friend or
Brasso.
Please leave these instructions for your customer.
