INSTALLATION, OPERATIONS & MAINTENANCE MANUAL
HEAT & ENERGY RECOVERY VENTILATORS
EK125-TQG, EK125-TF, EK150-TQG, HK150-TQG, EK150-TF,
HK150-TF, EK150-TQX, EK150-TFX, EK150-TQG-V5, EK150-
TF-V5, EK150-TQX-V5, EK150-TFX-V5, E170-TQG
TO BE COMPLETED BY CONTRACTOR AFTER INSTALLATION
I
nstalling Contractor
Serial Number
REGISTER YOUR PRODUCT ONLINE AT ALDES-NA.COM
InspirAIR
FOR MODELS:
"This product earned the ENERGY STAR® by
meeting strict energy efficiency guidelines
set by Natural Resources Canada and the
US EPA. This product meets ENERGY STAR
requirements only when used in Canada."
FOR EK125-TQG, HK150-TQG, EK150-TQG & EK150-TQX MODELS
ONLY
Installer: Leave this manual for the homeowner
Model
ELITE
®
Telephone / Contact
Installation Date
Meets Standards:
C22.2 no 113 and
UL 1812
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for aldes InspirAIR ELITE HK150-TQG
Summary of Contents for aldes InspirAIR ELITE HK150-TQG
- Page 1 Canada." FOR EK125-TQG, HK150-TQG, EK150-TQG & EK150-TQX MODELS ONLY TO BE COMPLETED BY CONTRACTOR AFTER INSTALLATION Installer: Leave this manual for the homeowner Model nstalling Contractor Telephone / Contact Serial Number Installation Date REGISTER YOUR PRODUCT ONLINE AT ALDES-NA.COM...
-
Page 2: Table Of Contents
TABLE OF CONTENTS I. INTRODUCTION 3 II. GENERAL HRV/ERV TERMINOLOGY AND FEATURES 3 Definitions 3 How Heat & Energy Recovery Ventilators Work 3 Ventilation with an HRV/ERV 4 III. WARNINGS AND PRECAUTIONS 4 Ducting Configurations Locating the Air Exchanger 9 Type of Ducts to Be Installed 9 Connecting the Ducts 9 Vent Hood Locations 11... -
Page 3: Introduction
Residential HRV/ERV I. INTRODUCTION Thank you for purchasing a ventilation product from ALDES. To get the most out of your device, we recommend reading the user manual. II. GENERAL HRV/ERV TERMINOLOGY AND FEATURES Definitions Heat Recovery Ventilator: A ventilation device consisting of two fans and a heat recovery module to provide exhaust of stale indoor air, plus a balanced supply of fresh air, without mixing the two airstreams. -
Page 4: Ventilation With An Hrv/Erv
The way your home was built • Your preferences regarding the level of ventilation ALDES HRV/ERVs create a fresh air supply by recovering part of the energy from the exhaust air. A properly installed, well used, and well-maintained HRV/ERV: •... - Page 5 Residential HRV/ERV CAUTION Before installation, careful consideration must be given to how this system will operate if connected to any other piece of mechanical equipment like a forced-air central heating unit or a fan with a higher static pressure, for example.
-
Page 6: Ducting Configurations
Residential HRV/ERV ATTENTION This product is intended for residential use in accordance with the requirements of the International Residential Building and Mechanical Codes, NFPA 90B for the United States and the National Building Code of Canada. It is recommended to turn the unit off during renovations to avoid clogging the filters and loading the fans with dust. - Page 7 This system is not connected to an air handling unit or furnace. This system is normally balanced on high speed. If ALDES patented ZRT® are integrated into the ventilation system, Refer to the ZRT brochure for more airflow balancing should be performed at normal speed.
- Page 8 Residential HRV/ERV During the hot, humid season, continuous operation of the AHU can cause evaporation in the cooling tower, resulting in a loss of humidity control. If the AHU is not in phase with the HRV/ERV, this can lead to condensation in the supply system and ducts. Running the AHU continuously can cause draft effects in winter.
-
Page 9: Locating The Air Exchanger
This helps optimize the ventilation system. The Aldes unit must be installed in such a way that it is easily accessible for maintenance, inspection, repair or other work on the unit. -
Page 10: Avoiding Condensation In Your Unit
Residential HRV/ERV To ensure an optimal performance of the air exchanger, position the ducts so that they are as straight as possible. Ducts should be short and have no bends to maximize airflow. Forty-five-degree elbows are preferable to 90-degree elbows. Use “Y” rather than “T” joints wherever possible. -
Page 11: Vent Hood Locations
Residential HRV/ERV Vent Hood Locations (Manufacturer’s recommendation. Also consult your local building code). Wall-mounted hoods (sold separately) must be installed where they are easily accessible for cleaning. Note: Please refer to wall hood installation instructions. Fresh Air (Intake) Wall hoods: •... -
Page 12: Locating The Exhaust Air Grilles Or Registers
Residential HRV/ERV Locating the Exhaust Air Grilles or Registers The air exchanger system must have at least one exhaust air register. Exhaust air registers should be installed in areas where humidity is highest, such as bathrooms, kitchens or laundry rooms, but not in steam showers, jacuzzi, indoor pools or solariums. Do not connect the cooker hood to the HRV/ERV. -
Page 13: Humidity Control
ASHRAE 62.2 standards recommend maintaining a relative humidity rate between 30% and 60%. The average person is comfortable between 30 and 50% relative humidity (RH). ALDES offers several wall controls with a dehumidistat function. Please refer to the wall control user guide for detailed information. -
Page 14: Drain Connections
Residential HRV/ERV Drain Connections (HRV Models only) Regardless of mounting method, the device should be installed level to ensure that conden- sation (produced during a defrost cycle) drains from the unit. The water should flow into a nearby drain or bucket. CAUTION: HRV must be installed level to ensure proper condensate drainage. -
Page 15: Mounting The Unit
Residential HRV/ERV Mounting the Unit The air exchanger is designed to be suspended or installed on a wall bracket (sold separately, P/N 699921). To suspend the unit, screw the hooks at the top corners of the unit into the holes provided. Using chains and springs, hook the air exchanger chains to the ceiling joints. To facilitate installation, you have the option of putting the second hook on the centre holes to clear the duct for a special installation (duct in front position). -
Page 16: Configuration Options
Residential HRV/ERV Configuration Options In order to configure the different modes on your unit, you may need to move a jumper on the unit’s printed circuit board. This can be done without any special tools following the directions below. Suggestion: it is easiest to do this prior to installation, on a table with the unit on its back. Disconnect the unit power cable to avoid electric shock or damaging the PCB. - Page 17 Residential HRV/ERV 5a) Defrost Modes By default, the HRV/ERV is configured for Normal Defrost, with no jumpers on pin sets 5 and 6. Normal Defrost is optimized for most climate zones. The unit will automatically protect the core from frost build up by periodically switching to high- speed recirculation or exhaust.
-
Page 18: Unit Wiring
Unit Wiring A) Unit wiring to accessories All units can be used with the following ALDES wall accessories: 611227: Electronic Humidistat with Liquid Crystal Display 611229: Speed Control 611230: Mode Control 611242-FC: Digital Multifunction Wall Control These can all be used on their own or with a timer (611228). - Page 19 Residential HRV/ERV B) Unit wiring for Relay Mode In relay mode, an external device or controller will send a signal to indicate when the unit is to be activated. This is the case when using a VentZone® system or an external integrated controller.
-
Page 20: Wiring To The Power Source
(P/N 611242-FC) The Digital Multifunction Control (P/N 611242-FC) can be used with any type of ALDES Residential HRV/ERV. The controller should be installed in the place where excess humidity is most likely to be detected, for example near a bathroom, kitchen or in the basement. - Page 21 Residential HRV/ERV Set the ON/OFF switches to correspond to your HRV/ERV model, as listed in the following table: Without recirculation ON OFF With recirculation Models: EK125-TF, EK150-TF, Models: EK125-TQG, EK150-TQG, EK150-TFX, AND HK150-TF EK150-TQX, HK150-TQG AND E170-TQG Connect each wire to the terminal board on the back of the controller face plate according to the connection chart shown on the diagram.
-
Page 22: Digital Multi-Function Control Operation Modes
Residential HRV/ERV Digital Multi-Fuction Control Operation Modes Installing the 20/40/60 Minute Timer (P/N 611228) This controller provides the ventilation unit with high-speed exterior exchange for the following durations: • 20 minutes • 40 minutes • 60 minutes A sHRV/ERVice box is recommended when installing the timer switch. Run a 3-conductor low-voltage (24 V) wire through the wall until it reaches the HRV/ERV. -
Page 23: Installing The Speed Controller (P/N 611229)
Residential HRV/ERV Installing the Speed Control (P/N 611229) This controller provides the ventilation unit with 4 modes of operation: • Intermittent mode; successive cycles, low-speed 20 min exchange, 40 min stop mode or recirculation • Low-speed exterior exchange mode • High-speed exterior exchange mode •... - Page 24 Residential HRV/ERV It is recommended to use the 20/40/60 timer (P/N 611228) to avoid over-ventilating and/ or damaging the air exchanger in cold climates, or creating frost in the ventilation system. The basic VentZone® system is designed to provide continuous low-speed ventilation, with temporary high speed on demand via a ZRT.
-
Page 25: Measuring And Balancing Airflow
Residential HRV/ERV V. MEASURING & BALANCING AIRFLOW Measure and Balance The installer must measure and balance the airflow brought in from the outside and the exhaust airflow so that the difference between the two is less than 10% of the maximum airflow. - Page 26 Residential HRV/ERV Prepare the HRV/ERV and select the operating speed. For most installations, measuring at high speed permits a more accurate reading, and the system will normally remain balanced at lower speeds. For the VentZone system, balancing at low speed is recommended.
-
Page 27: Balancing Airflow And Adjusting Motor Speed
Residential HRV/ERV Balancing Airflow and Adjusting Motor Speed – FLEXControl User Interface The FlexControl allows the independent control of speed between the two fans. Detail of the potentiometers on the HRV/ERV To adjust SUPPLY (FAN IN) airstream: Connect the tubes like the diagram above shows, then turn the FAN IN potentiometer to the desired level. -
Page 28: Maintenance
With the door removed, remove the filters. Follow the cleaning schedule and procedure for your unit’s filter type. See the table below to determine the filter that comes standard with your unit and what replacement filter options are available from ALDES. FILTER TYPE MERV 6... -
Page 29: Replacement Filters
Residential HRV/ERV Cabinet (twice a year) With the door removed, wipe down the inside of the cabinet with a damp cloth to remove any dust or debris. ONLY USE WATER. DO NOT USE PRODUCTS CONTAINING SOLVENTS. DO NOT USE HOUSEHOLD CLEANING PRODUCTS. Wipe the interior with a dry cloth. -
Page 30: Troubleshooting
Residential HRV/ERV Energy Use: The way your HRV/ERV is installed can make a considerable difference to the electrical ener- gy you use. To reduce HRV/ERV electrical consumption, a fully ducted, self-contained instal- lation is recommended. If you choose a simplified installation that operates your furnace’s air handler for room-to-room ventilation, a low-power furnace with a variable-speed, electron- ically commutated fan motor will reduce your electrical energy consumption and operating costs. - Page 31 Residential HRV/ERV Symptom Possible Causes Solution Wall Dehumidistat is not working • The wall control is not set • For control 611242-FC, ensure properly that the AUTO mode is selected • Outdoor RH is higher than and the target RH level is below the control setpoint the outdoor RH.
-
Page 32: Service Parts For Your Hrv/Erv
Residential HRV/ERV Service Parts for your HRV/ERV 38 10 11 DESCRIPTION 609464 (HK150), HRV COUNTERFLOW CORE (HK150) 699764 (EK150), ERV COUNTERFLOW CORE (EK150) 609463 (E170) ERV CROSSFLOW CORE CORE (E170) 699765 or 699054 PSC MOTOR (TQG/TF VERSIONS ONLY) or EC MOTOR (TQX/TFX VERSIONS ONLY) 606398 SERVOMOTOR (TQG/TQX VERSIONS ONLY) 699039 or 699041... -
Page 33: Warranty
Residential HRV/ERV DESCRIPTION 699761 (EK150) 5'' EXTERNAL DUCT PORTS (HK150, EK150, EK150-V5 and E170 models) or 699933 (EK125) 4’’ EXTERNAL DUCT PORTS (EK125 models) 604056 5'' INTERNAL DUCT PORTS 699860 5'' DAMPER 699763 ELECTRICAL BOX CASING PART1 699762 ELECTRICAL BOX CASING PART2 699757 PLASTIC ARM FOR SERVOMOTOR (TQG/TQX VERSIONS ONLY) 699758... -
Page 34: How To File A Warranty Claim
If a part is proved defective, it will be replaced with another part or repaired according to the company’s assessment. Before returning a defective product for repair, contact ALDES customer service to obtain a Return Materials Authorization (RMA). Send the defective part postage paid to the address below based on your residence. - Page 35 Residential HRV/ERV NOTES Date of Purchase ______________________________ Retailer ______________________________________ *Keep receipt as proof of purchase MAINTENANCE PERFORMED DATE...
- Page 36 1-800-262-0916 www.ALDES-na.com © 2025 ALDES Canada. Reproduction or distribution, in whole or in part, of this document, in any form or by any means, without the express written consent of ALDES Canada, is strictly prohibited. The information contained within this document is subject to change without prior written notice.
