HEATIT
WIFI6
Installers manual
White RAL 9003
54 305 42
TABLE OF CONTENTS
1. Introduction
2. Quick start
3. Installation disclaimer
4. Connections
5. Installation
6. Add/Remove
7. Factory reset
8. Startup
9. Principles of regulation
10. Local settings menu
11. Display menu structure
12. Temperature shown in
display
13. Standby and main screen
14. KWh value in menu
15. Choice of sensor
GET THE MYHEATIT APP HERE
PRODUCT
DOCUMENTS
Firmware version
Document version
FW 1.0
2024-A
Article no.
Document date
54 305 41
54 305 42
02.04.2024
54 305 43
Org. doc. date 02.04.2024
Black matt
54 305 43
White RAL 9010
54 305 41
16. Selecting sensor value
17. Calibration
18. Brightness
19. Display on/off
20. Display icons
21. Child lock
22. Open window detection
23. Error codes
24. Safety features
25. Associations (pending)
26. Configuration parameters
27. Indicator
28. Thermostat dimensions
29. Thermostat controls
30. Chart - display menu
Product info
1. INTRODUCTION
Heatit WiFi6 is an electronic thermostat designed for electrical
heating. The thermostat can be controlled using the "MyHeatit"
App via Wi-Fi, Bluetooth (BLE), or by the buttons on the front of
the thermostat. The thermostat has a user friendly interface.
Heatit WiFi6 has 3 modes; Heat - Cool and Eco.
The thermostat fits in standard European junction boxes and
may be used with most System 55 frames. It has a sturdy metal
frame for secure fastening on the junction box. The thermostat
has a built-in room temperature sensor. Two additional external
temperature sensors may also be connected. The device has
an open API and supports Amazon Alexa and Google Home
(open API, Amazon Alexa and Google Home is pending).
The thermostat can communicate over a local API, where
the user can make integration with a local gateway, server,
controller that offers such a service.
The installer can configure and set up the system via
Bluetooth. After the system is set up, the installer can transfer
the property to the customer. The customer can then transfer
the system to their Wi-Fi network.
Heatit WiFi6 has active power metering and it gives you real
time information about your power consumption. It also
allows you to set the power metering value manually in case
of connection with a contactor.
The device has implemented ZeroX technology. This
technology makes sure the relay switches at 0V when turning
on and off. With this technology the thermostat will have a
much longer lifetime.
The device can withstand a load of max. 16A/3600W at
230VAC. We recommend a contactor for loads above 13A.
2. QUICK START
Upon connecting the device to power, it will automatically
enter add mode for a duration of 60 minutes.
1. Switch off the mains voltage (disable the fuse).
2. Open the junction box.
3. Connect the wires according to the description in chapter
"Connections". Optional: Connect external wired sensors.
4. After verifying the connections, switch on the mains voltage.
5. In the "MyHeatit" App, choose "Add Device", enter your Wi-Fi
details, search for and select your device.
6. The thermostat will display "INCL" when the thermostat is
successfully added.
NB! If adding/removing fails, Err (error) will appear in the
display.
Advertisement
Table of Contents
Related Manuals for Heatit Controls Heatit WiFi6
Summary of Contents for Heatit Controls Heatit WiFi6
- Page 1 White RAL 9010 54 305 42 54 305 41 Heatit WiFi6 has active power metering and it gives you real time information about your power consumption. It also allows you to set the power metering value manually in case of connection with a contactor.
-
Page 2: Installation
3. INSTALLATION DISCLAIMER 1. Hold the center button for 5 seconds. Installation must be done by a qualified electrician in The display will show “OFF”. accordance with national building codes. Before installation, 2. Press the ”+” button once to see “CON” in the display. disconnect the power to the device from the mains. - Page 3 SIZE OF LOAD 9.1 Hysteresis Hysteresis will turn on and off the load based on the hysteresis In the “load” menu or from Parameter 26 “Size of load”, the load value can be set manually if the load is not directly value in comparison to the setpoint.
- Page 4 19. DISPLAY ON/OFF (DON/DOFF) Err6 Overheating. The thermostat has a display ON/OFF function which decides Contact your electrician. whether the display should turn completely off when in Err7 Overload. Standby. To enable/disable this function, hold the Left and Contact your electrician. Center buttons for 10 seconds.
-
Page 5: Configuration Parameters
26. CONFIGURATION PARAMETERS Heatit products are supposed to work out of the box after SHORT DESCRIPTION inclusion. Some device configuration may, however, alter NAME DESCRIPTION / COMMENT OF VALUE 5°C to 40°C. the functionality to better serve user needs or unlock further Set setpoint for ECO mode. - Page 6 30. CHART - DISPLAY MENU STRUCTURE Hold the middle button for 5 seconds to enter menu. Success Fail TDS: Temperature displayed in standby mode Hold button for 2 seconds SETT: Setpoint temperature RELT: Real time temperature...
- Page 7 Only shows available options Only shows available options...
- Page 8 Only shows available options Hold the middle button to set HYST value, from 0.3-3.0 Default Short hold to change the mode Default Load value from 100-9900W, by increments of 100. Hold to reset the Kwh.
-
Page 9: Product Info
Any wrongful installation, misuse, damage of the product, is not covered under warranty. Heatit Controls AB · Läkarvägen 4, 454 31 BRASTAD, SWEDEN Updated documentation is available at www.heatit.com and/or documents.heatit.com. Heatit Controls AB can not be held liable for any type of errors or omittances in our product information.
