C6EU SERIES
Installation and Operation Manual
ENGLISH
Copyright
XCharge reserves all rights to this document and to the information and topics contained in it. This
also applies to any possible claims to copyright or patents. Forwarding and/or the duplicating of
this document without the express permission of XCharge is forbidden.
Copyright | C6EU1 User Manual, Version 1.4.1, approved by VDE Global Services
Advertisement
Table of Contents
Related Manuals for XCHARGE C6EU Series
Summary of Contents for XCHARGE C6EU Series
- Page 1 ENGLISH Copyright XCharge reserves all rights to this document and to the information and topics contained in it. This also applies to any possible claims to copyright or patents. Forwarding and/or the duplicating of this document without the express permission of XCharge is forbidden.
-
Page 2: Table Of Contents
Content C6EU SERIES ............................1 Installation and Operation Manual ....................1 Introduction and Safety Information ..................2 1.1 Preface..........................2 1.2 Proper Usage of the manual ....................2 1.3 Intended document user ..................... 2 1.4 Important safety instructions ....................2 1.5 important signs ........................ -
Page 3: Introduction And Safety Information
When any loss or damage occurs due to improper use or unauthorized modification of the product, XCharge shall not be liable for the product, the purchaser or third parties. The same is also valid if the maintenance provided by XCharge is not strictly complied. -
Page 4: Important Signs
WARNING (Safety instructions on a risk with medium risk level! Failure to comply can result in death or serious injury) Please confirm the voltage and current level before installation. The entire installation process needs to be conducted by qualified personnel. Please do not operate in the cloudy, rainy weather or similar conditions may causing possible leakage. - Page 5 Warning Signs Description Earthing Connect an earth terminal to the ground General Warning Sign identify a hazard which could result in damage to the operator, machinery, other equipment and / or pollution Electricity Hazard Warning of electrical voltage Crushing of Hands Touching the device may result in hand injury No access for people with active...
- Page 6 WEEE Symbol Do not dispose of the product with domestic waste. Please follow the valid disposal regulations in the installation site for electronic waste. CE Mark Figure 1.5.2 signs on nameplate Copyright | C6EU1 User Manual, Version 1.4.1, approved by VDE Global Services...
-
Page 7: Product Description
2. Product description 2.1 System overview Figure 2.1.1 HD/Touch screen with 22.5 cm diameter (HMI) LED Indicator Control panel with NFC reader Charging plug Emergency button Locker of door Air inlet Air outlet Table 2.1.1 Housing and elements outside This manual is valid for all the C6EU Versions, which are shown below in Table 2.1.2. Type Max. -
Page 8: Charging Plug System
“3” means the Half intelligent mode: two plugs output same power value or one plug outputs at maximum value; “4” means Intelligent mode: output multiple designated values. Figure 2.1.2 design sketch of construction for C6EU 2.2 Charging plug system CHAdeMO CCS Combo 2 Figure 2.2 Struktur of charging plug, CHAdeMO and CCS Combo 2 Copyright | C6EU1 User Manual, Version 1.4.1, approved by VDE Global Services... -
Page 9: Technical Data
3. Technical Data 3.1 Nameplate Figure 3.1.1 Nameplate Nameplate contains all the necessary information includes: - Product type and serial number - Input power and wiring - DC rated output voltage, current and power - Manufacture date 3.2 Electrical data Input Input voltage range 3 phase 400 V... -
Page 10: Mechanical Data
3.3 Mechanical Data Mechanical data Dimensions (H x W x D) 1750 mm x 600 mm x 720 mm Weight 300 kg(160kW) Volume 0.75m Dimensions including packaging 2000 mm x 800 mm x 920 mm Weight including packaging 340 kg(160kW) Weight concrete foundation Min. -
Page 11: Electrical Diagram
3.6 Electrical diagram To electricity meter To electricity meter Figure 3.6.1 electrical connection diagram Figure 3.6.2 Fans’ control diagram Notes: The diagram was already approved by TÜV Rheinland according to Standard EN 61851-23. Copyright | C6EU1 User Manual, Version 1.4.1, approved by VDE Global Services... -
Page 12: Function Structure Of C6Eu
3.7 Function Structure of C6EU The Figure 3.7.1 below introduces the structure of C6EU from basic to sophisticated functions Figure 3.7.1 Copyright | C6EU1 User Manual, Version 1.4.1, approved by VDE Global Services... -
Page 13: Installation
4. Installation The product will be delivered to a warehouse by logistic company and handed over to the customer. Normally XCharge is not responsible for the tranport of charger to final installation location. 4.1 Required space for placing and maintaining The space that C6EU needs is calculated as follows: •... -
Page 14: Construct Foundation
The height of the foundation is determined by the terrain of the site. Depending on rainfall and drainage a height between 15 cm and 30 cm above the ground is recommended by XCharge. Because of frost-proof the foundation has to be about 80 cm deep under the ground. -
Page 15: Power Supply And Power Cable
because of the frost-proof. • When plastic pipes are used for power distribution, flame-retardant type and wall thickness >2.0mm shall be adopted. When the steel pipe is used for underground pipe wiring, the wall thickness is >2.5mm and anticorrosive treatment is carried out. •... -
Page 16: Position
• Remove the inner shrink wrap WARNING risk of suffocation! The children are not allowed to play with plastic wrap and shrink wrap. Figure 4.5 4.6 Position CAUTION Material damage due to improper handling - Collisions and bumps can damage the charging station. - Move the charging station with the utmost caution. - Page 17 be achieved through four eyebolts included in delivery, which can be screwed into the tapped holes on the top. • The cable entrance on the bottom of charger is divided into three inlets, of which the first is for the power cable, the second is for the ground wire of foundation and the third is for the signal cable.
- Page 18 Gland for power cable Gland for ground wire of foundation when needed Gland for signal cable Figure 4.6.3 • After installing the cable into the charging station, the bottom of the charging station is fixed to the concrete platform by 4 fixed concrete anchor screws M10. Copyright | C6EU1 User Manual, Version 1.4.1, approved by VDE Global Services...
-
Page 19: Commissioning And Operation
5. Commissioning and operation 5.1 Power up WARNING Mortal danger due to electrocution! The contact with high power parts can result in electric shock, burns or death. If the charger is firmly fixed on the foundation and the power supply has been properly applied, then the charging station can be powered up by turning on the main switch, which is located in the left on bottom behind the front door. -
Page 20: Control Panel
5.2.2 Control panel Please press the arrow buttons and home button based on the guides on display to choose the options on screen. Home button Left right Arrow button arrow button card reader Figure 5.2.2 Control panel WARNING Danger of life through wrong installation! Extension cables are not permitted according to IEC 61851-1. -
Page 21: Indicator Lights
5.4 Indicator lights Above the respective cable suspension is a widely visible LED indicator, which shows different statuses of the charging station. Lights outline Status Sleep mode Charging percentage Fully -charged System activation Error System self-checking Figure 5.4.1 Status of LED indicator Copyright | C6EU1 User Manual, Version 1.4.1, approved by VDE Global Services... -
Page 22: Fault Diagnosis
6. Fault diagnosis • Charging station is equipped with automatic diagnosis function, and the fault will be directly displayed on the screen. • If the charging station is online, users can call customer service, we will arrange online engineer for remote repair charging fault. •... - Page 23 √ √ 10A0 AC surge protective device alarm. √ √ 10B0 Ground alarm. √ 2005 Plug 1 or Plug 2 temperature alarm. √ 2010 BMS CAN failed to detect. (vehicle malfunction) √ 2014 BMS communication failure. (vehicle malfunction) The Plug 1 or Plug 2 BMS timeout alarm.(vehicle √...
- Page 24 √ 4012 Detection point 2 voltage detection failure. The total voltage setting is reached. No exception, it is √ 4020 considered to be full. √ √ 4021 Pile front door open. √ √ 4022 The pile back door opens. The power module is faulty. The failed module must be √...
-
Page 25: Maintenance
7. Maintenance WARNING Mortal danger due to electrocution! The contact with high power parts can result in electric shock, burns or death. Before working please put on the required protection device such as Protective clothing and gloves: - Disconnect the system from the power supply. - Make sure that the power supply is disconnected while working. - Page 26 Figure 7.2.1 WARNING Danger of life! Please shut down the input power before cleaning the charging station. When opening the front and rear doors, please pay attention to prevent dust from entering the cabinet and clean if necessary. Copyright | C6EU1 User Manual, Version 1.4.1, approved by VDE Global Services...
-
Page 27: Information
Address: c/o WeWork Stadthaus Axel-Springer-Platz 3 - 20355 Hamburg Tel: +49-40808194740 Email: eu@xcharge.com Beijing, China Beijing XCharge Technology Co., Ltd. Address:10F Guobin Building. No.21 Jiuxianqiao Road, Chaoyang District, Beijing, China Tel: +86-1057215988 Email: b@xcharge.com Copyright | C6EU1 User Manual, Version 1.4.1, approved by VDE Global Services...
