Electric Tugger | GUO133
Operator's Manual
Warning: Please read and thoroughly understand all instructions before operating. Failure to follow
safety rules and other basic safety precautions may result in serious personal injury. Keep these
instructions in a safe and easily accessible place so that they can be referred to when needed. Retain
these instructions to assist in future servicing.
© SuperHandy All Rights Reserved | Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GUO133 and is the answer not in the manual?

Questions and answers

Summary of Contents for Super Handy GUO133

  • Page 1 Electric Tugger | GUO133 Operator’s Manual Warning: Please read and thoroughly understand all instructions before operating. Failure to follow safety rules and other basic safety precautions may result in serious personal injury. Keep these instructions in a safe and easily accessible place so that they can be referred to when needed. Retain these instructions to assist in future servicing.
  • Page 2: Table Of Contents

    1. WARNING ------------------------------------------------------------------------------------------------------------------------------------ 1 2. TECHNICAL SPECIFICATIONS --------------------------------------------------------------------------------------------------------- 2 3. CONTROLS AND FEATURES ------------------------------------------------------------------------------------------------------------ 3 4. ASSEMBLY ------------------------------------------------------------------------------------------------------------------------------ 4~7 5. OPERATION ---------------------------------------------------------------------------------------------------------------------------- 5~10 6. MAINTENANCE AND STORAGE -------------------------------------------------------------------------------------------------- 10~11 7. WARRANTY ------------------------------------------------------------------------------------------------------------------------------- 12 8. TROUBLE SHOOTING ------------------------------------------------------------------------------------------------------------------- 12 1. WARNING A tugger is not a toy.
  • Page 3: Technical Specifications

    2. TECHNICAL SPECIFICATIONS Item No. GUO133 Performance Towing Capacity 2600 lbs (1200 kgs) Max. Load Capacity 350 lbs (160 kgs) Max. Forward Speed* 4.3 mph (7 km/h) Max. Backward Speed* 1.9 mph (3 km/h) Max. Slope* 15% (8.5°) Dimensions & Weight Total Dimension 51.2x25.2x37.4 in.
  • Page 4: Controls And Features

    3. CONTROLS AND FEATURES Handlebar Handlebar Adjustment Clamp Star Handle Bolt Battery Box Cover Middle Bar Power Switch Battery Shock Absorber Foot Plate Front Wheel Handlebar Connector Forward/Reverse Switch Parking Brake Battery LED Brake Lever Star handle bolt Console Switch Seat Tool Box Towbar Mounting Base...
  • Page 5: Assembly

    4. ASSEMBLY Fig. 01 4.1 Assemble Handlebar (Fig.01) Place the fixing base onto the frame and connect them with 4 M6x20 hex bolts and 4 M6 nuts. Recommended Tools: 10mm Open-end wrench, Fixing Base Hex key 5# 4.2 Assemble Rear Wheels (Fig.02) Assemble the rear wheel to both ends of the axle using 1 rear wheel , 4 elastic washers , and 4 M14x1.5 cap nuts.
  • Page 6 4.3 Assemble Front Wheel (Fig.04) Secure the front wheel between two shock absorbers using an M12X160 bolt,two bushings, and an M12 nut. Recommended Tools: 19mm socket wrench, 19mm Open-end wrench Shock Absorter M12*160 Bolt Bushing M12 Nut Note: After installation, please organize the wiring Bushing harness upwards so that it does not interfere with Wheel...
  • Page 7 4.6 Assemble Tool Box (Fig.07) Fig. 07 Assemble the Tool Bag to the rear of the Frame. Tool Bag Frame 4.7 Handlebar Height Adjustment (Fig.08) Fig. 04 Fig. 08 Loosen the clamp of the handle lock, adjust the handle to a proper position, and then tighten the lock of the handle lock.
  • Page 8 * Tow bar connector height adjustment Fig. 10 (Fig.10) Disassemble the tow-bar connect kit from the towbar mounting base, adjust it to the suitable position, then reinstall it with the bolts and nuts. M8 Nut Towbar Tow-bar M8*75 Nut Mount Base Connect Kit Fig.
  • Page 9: Operation

    5. OPERATION 5.1 General inspection before operation General inspection is effective to find the malfunctions or faults on this tugger. Check the following items before operation. DO NOT USE THE TUGGER IF ANY MALFUNCTION IS FOUND. • Check for scratches, deformation or cracks. •...
  • Page 10 For the power supply of the console, the red knob in left hand side is the power switch. Push on it, power is On. Push on again, power is off. (Fig. 14) Fig. 14 5.4 BATTERY LEVEL INDICATOR (Fig. 15) LED on battery also shows battery capacity: Fig.
  • Page 11: Maintenance And Storage

    5.7 Turn It is essential to slow down to a reasonably slow speed before initiating a turn. Use extreme caution when turning on slanted or uneven surfaces. Occasionally you may find yourself negotiating a curve or corner too fast and the inner rear wheel starts to lift off...
  • Page 12 6.3 CHARGER (Fig. 19) 1. The battery is charging when the LED light on the charger is red. When the battery is 100% charged, the light on the charger will turn solid green. 2. The provided charger has a built-in overcharge protection to prevent the battery from being overcharged.
  • Page 13: Warranty

    7. WARRANTY Twelve (12) months for workmanship of the product, except for wearing parts. Warranty period starts from the product purchase date. Warranty covers material quality and workmanship only. Warranty does not cover product for issues caused by improper usage or any operation not in accordance with the specifi- cations of this manual.
