Luminex GIGACORE 10t-IP Safety Instructions And Quick Start Manual

Hide thumbs

Advertisement

Table of Contents

GIGACORE 10t-IP
SAFETY
INSTRUCTIONS &
QUICKSTART
GUIDE
GIGACORE PRODUCT FAMILY
GigaCore t Range: 10t-IP
Thanks for choosing Luminex.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GIGACORE 10t-IP and is the answer not in the manual?

Questions and answers

Related Manuals for Luminex GIGACORE 10t-IP

Summary of Contents for Luminex GIGACORE 10t-IP

  • Page 1 GIGACORE 10t-IP SAFETY INSTRUCTIONS & QUICKSTART GUIDE GIGACORE PRODUCT FAMILY GigaCore t Range: 10t-IP Thanks for choosing Luminex.

  • Page 2: Important Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS: Read these instructions. Only use attachments/accessories specified by the manufacturer. ƒ ƒ Keep these instructions. Unplug this apparatus during lightning storms or when unused for long ƒ ƒ Pay attention to all warnings. periods of time.

  • Page 3: Précautions Concernant La Sécurité

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS PRÉCAUTIONS CONCERNANT LA SÉCURITÉ : Lisez ces instructions. N’utilisez que les accessoires spécifiés par le fabricant. ƒ ƒ Conservez ces instructions. Débranchez cet appareil pendant les orages ou s’il n’est pas utilisé pendant ƒ ƒ Tenez compte de tous les avertissements. de longues périodes.

  • Page 4: Ventilation And Cooling

    To prevent your product from overheating, do not operate it in an area that ES3/PS3 CIRCUIT. ƒ exceeds the maximum recommended ambient temperature of 50°C for the GigaCore 10t-IP. SAFETY CLASSIFICATION OF TRAFFIC PORTS The equipment must be installed and protected from extreme ƒ...
  • Page 5 CAUTION/ SHOCK HAZARD CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN. THIS UNIT HAS ONE AC CONNECTION. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR DISCONNECT THE CONNECTION TO THE POWER SUPPLY BEFORE SERVICING TO MOISTURE.
  • Page 6 FCC requirements. Modifications not expressly approved by This symbol on the products, packaging, and/or accompanying documents means that used Luminex Lighting Control Equipment nv may void your authority, granted by the electrical and electronic products should not be mixed with general household waste. For prop- FCC, to use the product.
  • Page 7 The complete user manual can be found in the download section of our website: www.luminex.be/support-2/product-downloads The GIGACORE 10t-IP is fitted with a passive NFC module that enables the users to use their smart device to make on-the-go changes to the device’s settings in powered and unpowered state.
  • Page 8 NFC tag of the GIGACORE 10i-IP, follow the instructions while in the tion. Araneo app to change the settings of the GIGACORE 10t-IP. 4. Scan the NFC tag of the GIGACORE 10t-IP Align the antenna of the smartphone with the NFC marking on the GIGACORE 10i-IP and wait until your device is done reading the tag, this will be followed by a message or a vibration.

  • Page 9: Mounting The Device

    1. MOUNTING THE DEVICE 1.1 VESA mount 1.2 Threaded insert mounts The threaded (M4) holes on the bottem of the unit, placed in a The Device is equipped with a wide variety of mounting options in the form 100mmx100mm VESA-style pattern are there to provide diverse mounting of M10 threaded inserts for mounting of brackets of clamps.

  • Page 10: Power Up The Device

    After connecting the power cable correctly, the power LED indicator on the front of AC power 100-240VAC, 3.5 – 1.5A, 50/60Hz. ƒ the device will light up green. The GIGACORE 10t-IP requires standard AC power 100- 240VAC, 50/60Hz. Current required, depends on the model and PoE++ load . (E) RJ45 Ports: 8 x 1Gbps RJ45 ƒ...

  • Page 11: Led Indicators

    4. LED INDICATORS There are various LEDs on the GIGACORE 10t-IP. Here is a list of the LEDs, the possible With the use of the mode button, the user can get all the necessary information colours, and the meaning of each colour: immediately.

  • Page 12: Connecting To The Web Interface

    If you need to ask our team for more help or you need to return a device to ƒ Type the IP address of the switch in the address field followed by enter. Luminex for diagnostics or repair, you can also find the option on this page to ƒ request an RMA or start a support ticket.
  • Page 13 GigaCore 10t-IP Safety & Quickstart Guide (LU 77 00387 rev.1.0.0) Slamstraat 13 | 3600 Genk | Belgium | T +32 11 812 189 info@luminex.be | www.luminex.be...
