810
WIRELESS
O W N E R ' S M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JBL QUANTUM 810 WIRELESS and is the answer not in the manual?

Questions and answers

Related Manuals for Harman JBL QUANTUM 810 WIRELESS

Summary of Contents for Harman JBL QUANTUM 810 WIRELESS

  • Page 1 WIRELESS O W N E R ’ S M A N U A L...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ......................1 WHAT’S IN THE BOX ..................... 2 PRODUCT OVERVIEW ....................3 Controls on headset .............................3 Controls on 2.4G USB wireless dongle ....................5 Controls on 3.5mm audio cable ......................5 GETTING STARTED....................... 6 Charging your headset ..........................6 Wearing your headset ..........................7 Power on ................................8 First-time setup (for PC only) ........................8...

  • Page 3: Introduction

    Introduction Congratulations on your purchase! This manual includes information on the JBL QUANTUM810 WIRELESS gaming headset. We encourage you to take a few minutes to read this manual, which describes the product and includes step-by-step instructions to help you to set up and get started. Read and understand all the safety instructions before using your product.

  • Page 4: What's In The Box

    What’s in the box JBL QUANTUM810 WIRELESS headset USB charging cable (USB-A to USB-C) 3.5mm audio cable 2.4G USB wireless dongle QSG, warranty card and safety sheet Windshield foam for boom microphone - 2 -...

  • Page 5: Product Overview

    PRODUCT OVERVIEW Controls on headset ANC* / TalkThru** LED • Lights up when the ANC feature is enabled. Flashes quickly when the TalkThru feature is enabled. • button • Press briefly to turn ANC on or off. • Hold for more than 2 seconds to turn TalkThru on or off. dial Balances the chat volume in relation to the game audio volume.
  • Page 6 Mic mute / unmute LED • Lights up when the microphone is muted. button • Press to mute or unmute the microphone. Hold for more than 5 seconds to turn the RGB light on or off. • Charging LED Indicates the charging and battery status. •...

  • Page 7: Controls On 2.4G Usb Wireless Dongle

    Controls on 2.4G USB wireless dongle CONNECT button Hold for more than 5 seconds to enter 2.4G wireless pairing mode. • • Indicates the status of 2.4G wireless connection. Controls on 3.5mm audio cable slider Slide to mute or unmute the microphone in 3.5mm audio connection. •...

  • Page 8: Getting Started

    Getting started Charging your headset 3.5hr Before use, fully charge your headset through the supplied USB-A to USB-C charging cable. TIPS: • It takes approximately 3.5 hours to fully charge the headset. You can also charge your headset through a USB-C to USB-C charging cable •...

  • Page 9: Wearing Your Headset

    Wearing your headset 1. Put the side marked L onto your left ear and the side marked R onto your right ear. 2. Adjust the earpads and headband for a comfortable fit. 3. Adjust the microphone as necessary. - 7 -...

  • Page 10: Power On

    Power on Slide the power switch upwards to power on the headset. • • Slide downwards to power off.  The status LED glows solid white upon powering on. First-time setup (for PC only) Download from jblquantum.com/engine to gain full access to features on your JBL Quantum headset - from headset calibration to adjusting 3D audio to suit your hearing, from creating customized RGB lighting effects to determining how the boom microphone side-tone works.
  • Page 11 1. Connect the headset to your PC via 2.4G USB wireless connection (See “With 2.4G wireless connection”). 2. Go to “Sound Settings” -> “Sound Control Panel”. 3. Under “Playback” highlight “JBL QUANTUM810 WIRELESS GAME” and select “Set Default” -> “Default Device”. 4.

  • Page 12: Using Your Headset

    Using your headset With 3.5mm audio connection 1. Connect the black connector to your headset. 2. Connect the orange connector to the 3.5mm headphone jack on your PC, Mac, mobile or gaming console device. Basic operation Controls Operation Volume dial on 3.5mm audio cable Adjust master volume.

  • Page 13: With 2.4G Wireless Connection

    With 2.4G wireless connection 2.4G 1. Plug the 2.4G USB wireless dongle into a USB-A port on your PC, Mac, PS4/PS5 or Nintendo Switch™. 2. Power on the headset. It will pair and connect with the dongle automatically. Basic operation Controls Operation Volume dial...
  • Page 14 To pair manually >5S >5S 1. On the headset, slide the power switch upwards and hold for more than 5 seconds until the status LED flashes white. 2. On the 2.4G USB wireless dongle, hold CONNECT for more than 5 seconds until the LED flashes white quickly.

  • Page 15: With Bluetooth (Secondary Connection)

    With Bluetooth (secondary connection) >2S Settings Bluetooth Bluetooth DEVICES JBL Quantum810 Wireless Connected Now Discoverable With this function, you can connect your mobile phone to the headset while playing games, without worrying about missing important calls. 1. Hold on the headset for more than 2 seconds.  The status LED flashes quickly (pairing).
  • Page 16 Control calls ×1 ×1 ×2 When there is an incoming call: Press once to answer. • Press twice to reject. • During a call: Press once to hang up. • TIP: Use volume controls on your Bluetooth connected device to adjust volume. •...

  • Page 17: Product Specifications

    Product Specifications • Driver size: 50 mm Dynamic drivers • Frequency response (Passive): 20 Hz - 40 kHz Frequency response (Active): 20 Hz - 20 kHz • Microphone frequency response: 100 Hz -10 kHz • • Max input power: 30 mW Sensitivity: 95 dB SPL @1 kHz / 1 mW •...

  • Page 18: Troubleshooting

    Troubleshooting If you have problems using this product, check the following points before you request service. No power • The headset turns off automatically after 10 minutes of inactivity. Power on the headset again. Recharge the headset (see “Charging your headset”).
  • Page 19 You may experience obvious sound quality degradation when using the headset • near a USB 3.0 enabled device. This is not a malfunction. Use an extension USB dock instead to keep the dongle as far from the USB 3.0 port as possible. In 2.4G wireless connection: •...

  • Page 20: License

    License The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HARMAN International Industries, Incorporated is under license. Other trademarks and trade names are those of their respective owners.
  • Page 21 HP_JBL_Q810_OM_V2_EN...
  • Page 22 WIRELESS Q U I C K S T A R T G U I D E...
  • Page 23 JBL QuantumENGINE Download JBL QuantumENGINE to gain full access to features on your JBL Quantum headsets - from headset calibration to adjusting 3D audio to suit your hearing, from creating customized RGB lighting effects to determining how the boom microphone side-tone works. JBLquantum.com/engine Software requirements Platform: Windows 10 (64 bit only) / Windows 11 500MB of free hard drive space for installation...
  • Page 24 WHAT'S IN THE BOX Windshield foam for boom microphone QSG | WARRANTY CARD | USB charging 3.5MM AUDIO USB WIRELESS Safety Sheet JBL quantum810 WIRELESS headset cable CABLE DONGLE...
  • Page 25 Requirements SOFTWARE REQUIREMENTS Platform: Windows 10 (64 bit only) / Windows 11 500MB OF FREE HARD DRIVE SPACE FOR INSTALLATION System compatibility PC | Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR Connectivity PS4/PS5 XBOX™ Nintendo Switch™ Mobile 3.5 mm Audio Cable Stereo...
  • Page 26 OVERVIEW ANC / TALKTHRU LED ANC / TALKTHRU button Game audio-chat balance dial Volume Control Detachable Windshield foam Notification LED for mic mute / unmute Microphone Mute / unMute CHARGING LED 3.5mm Audio Jack USB-C port Voice Focus Boom Microphone Bluetooth pairing button POWER ON / OFF slider POWER / 2.4G / Bluetooth LED...
  • Page 27 POWER ON & CONNECT 2.4G Wireless PC | mac | PLAYSTATION |Nintendo Switch™ MANUAL CONTROLS >5S >5S power on...
  • Page 28 Bluetooth ×1 ×1 ×2 Settings Bluetooth Bluetooth DEVICES JBL Quantum810 Wireless Connected >2S Now Discoverable...
  • Page 29 SETUP Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR...
  • Page 30 BUTTON COMMAND ANC on/off TALKTHRU ON/OFF >2 INCREASE GAME VOLUME INCREASE CHAT VOLUME INCREASE MASTER VOLUME DECREASE MASTER VOLUME Microphone Mute / unMute >5 ON / OFF >2 BT PAIRING MODE...
  • Page 31 First time setup Connect the headset to your PC via 2.4G USB wireless connection. Go to “Sound Settings” -> “Sound Control Panel”. Under “Playback” highlight “JBL QUANTUM810 WIRELESS GAME” and select “Set Default” -> “Default Device”. Highlight “JBL QUANTUM810 WIRELESS CHAT” and select “Set JBL Quantum810 WIRELESS JBL Quantum810 WIRELESS Default”...
  • Page 32 009 MICROPHONE Notification LED for mic mute / unmute mute unmute...
  • Page 33 010 CHARGING 3.5hr...
  • Page 34 011 LED BEHAVIOURS ANC ON ANC OFF TALKTHRU ON 2.4G PAIRING 2.4G PAIRING 2.4G CONNECTING 2.4G CONNECTING MIC MUTE 2.4G CONNECTED 2.4G CONNECTED MIC UNMUTE BT PAIRING BT CONNECTING LOW BATTERY BT CONNECTED CHARGING FULLY CHARGED POWER ON POWER OFF...
  • Page 35 TECH SPEC Driver size: 50 mm Dynamic drivers Frequency response (Passive): 20 Hz - 40 kHz Frequency response (Active): 20 Hz - 20 kHz Microphone frequency response: 100 Hz -10 kHz Max input power 30 mW Sensitivity: 95 dB SPL @1 kHz / 1 mW Maximum SPL: 93 dB Microphone sensitivity:...
  • Page 36 Connectivity PS4/PS5 XBOX™ Nintendo Switch™ Mobile 3.5 mm Audio Cable Stereo Stereo Stereo Stereo Stereo Stereo Stereo 2.4G Wireless Stereo Not Compatible Stereo Not Compatible Stereo Stereo Bluetooth Stereo Not Compatible Not Compatible Stereo Stereo Stereo Not Compatible Forbindelser | PC | PS4/PS5 | XBOX™ | Nintendo Conectividad | PC | PS4/PS5 | XBOX™...
  • Page 37 IC RF Exposure Information and Statement Utilisation au niveau de la tête The SAR limit of Canada (C) is 1.6 W/kg averaged over one gram of tissue. Device types: (IC: 6132A-JBLQ810WL) has also been tested against this L’appareil est testé dans un cas d’utilisation typique autour de la tête. Pour respecter les standards d’exposition RF, une distance de SAR limit According to this standard, the highest SAR value reported during product certification for head use is 0.002 W/Kg.
  • Page 38 The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use Гарантийный период: 1 год of such marks by HARMAN International Industries, Incorporated is under license. Other trademarks and trade names are those of their respective owners.
  • Page 39 HP_JBL_Q810_QSG_SOP_V10...
  • Page 40 Sound is Survival. Features Dual surround sound Level up to the JBL Quantum 810 Wireless with Hi-Res certified JBL QuantumSOUND that Hear every detail with Hi-Res drivers makes even the tiniest audio details come in crystal clear and JBL QuantumSURROUND, the Dual wireless best spatial surround sound for gaming with DTS Headphone:X version 2.0 technology.
  • Page 41 ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HARMAN HARMAN International Industries, Incorporated International Industries, Incorporated is under license. Other trademarks and trade names are those of their 8500 Balboa Boulevard, Northridge, CA 91329 USA www.jbl.com...
