FROST-FREE REFRIGERATOR-FREEZER
BUILT-IN VEHICLE
MODEL (LIPPERT PN)
SRD-360W TG-ED (2022302041)
INSTRUCTION MANUAL
MANUEL D'INSTRUCTION
This manual contains the product's basic information, operation instructions, fault diagnosis and basic troubleshooting
methods. In order to better understand and use this product, please take good care of this manual, and read it carefully.
* Picture shown here is for reference only.
* L'image présentée ici n'est qu'une référence.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Everchill SRD-360WTG-ED and is the answer not in the manual?

Questions and answers

Related Manuals for Furrion Everchill SRD-360WTG-ED

Summary of Contents for Furrion Everchill SRD-360WTG-ED

  • Page 1 FROST-FREE REFRIGERATOR-FREEZER BUILT-IN VEHICLE MODEL (LIPPERT PN) SRD-360W TG-ED (2022302041) INSTRUCTION MANUAL MANUEL D’INSTRUCTION * Picture shown here is for reference only. * L’image présentée ici n’est qu’une référence. This manual contains the product's basic information, operation instructions, fault diagnosis and basic troubleshooting methods.

  • Page 2: Table Of Contents

    Thank you and congratulations on purchasing this Furrion product. Before operating your new product, please read these instructions carefully. This instruction manual contains information for safe use, installation and maintenance of the product. Please keep this instruction manual in a safe place for future reference. This will ensure safe use and reduce the risk of injury.

  • Page 3: Important Safety Instructions

    Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your refrigerator. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your refrigerator. WARNING 1.

  • Page 4: Power Source Requirement

    7. WARNING - Do not use electrical appliances inside the food storage compartments of the refrigerator unless they are of the type recommended by the manufacturer. 8. Maintenance - Disconnect the power source from your refrigerator before carrying out user maintenance on it. 9.

  • Page 5: Parts And Features

    Parts and Features Preparation and Installation Refrigerator unit preparation 1. Packaging: Remove all packaging, including the foam backing at the bottom of refrigerator and the tape fixing accessories in the box. 2. Standing time: Place the refrigerator in a proper up-right position for more than one hour before connecting power to ensure refrigerant is settled for normal operation.

  • Page 6: Site Preparation And Installation

    Site preparation and installation 1. Ventilation requirements: The position you select for the refrigerator installation should be well-ventilated with minimal hot air. Do not place your refrigerator close to a heat source and avoid exposure to direct sunlight to guarantee optimum refrigerator performance with minimum energy use.
  • Page 7 4. Fixing the refrigerator to the cabinetry: The user can install the screw into the holes on the inner compartment to fix the refrigerator to the RV cabinetry. 5. Fixing the shelves in the refrigerator compartment: The holes are to fix the refrigerator to cabinetry The glass shelves in the refrigerator compartment are affixed in production for safety considerations.

  • Page 8: Preparation And Installation

    Preparation and Installation Out of the Box Settings Temperature settings out of the box may vary. Please ensure you modify temperature settings to your personal cooling preferences. When the refrigerator system is connected to the power supply for the first time, all icons on the display panel will illuminate 3.

  • Page 9: Battery Monitor

    Battery Monitor The “Battery Monitor” function can display the current input voltage value of the refrigerator, helping the user understand the current battery level. 1. Enable the "Battery Monitor” function: ● Press and hold down the “SET” button for more than 5 seconds (but within 10 seconds). 2.

  • Page 10: Instructions For Food Storage

    Instructions for Food Storage Precautions for Use ● The appliance might not operate consistently (there is possibility of defrosting or temperature becoming too warm in the frozen food compartment) when for an extended period of time below the cold limit of the temperature range for which the refrigerating appliance is designed.

  • Page 11: Maintenance And Cleaning

    Maintenance and Cleaning Do not use hands to clean under the base of the refrigerator to avoid harm from sharp metal edges. nternal cleaning and external cleaning Any food residue in the refrigerator is liable to produce bad odor, so the refrigerator must be cleaned regularly. The fresh food compartment is usually cleaned once a month.

  • Page 12: Troubleshooting

    Troubleshooting You can solve many common refrigerator problems easily, avoiding the need for a service call. Try the suggestions below to see if you can solve the problem before calling for service. Trouble Symptom Possible Reason Solutions No power • Power source connection is OK? •...
  • Page 13 Furrion, LLC (Furrion) are wholly owned subsidiaries of Lippert Components, Inc. (Lippert) Furrion, LLC (Furrion) sont des filiales en propriété exclusive de Lippert Components, Inc. (Lippert) Furrion, LLC (Furrion) son subsidiarias de propiedad total de Lippert Components, Inc. (Lippert) Furrion, LLC: 52567 Independence Ct., Elkhart, IN, 46514 Furrion Innovation Center &...
