ES30 & ES50
Food Waste Disposal
1-800-558-5700
®/TM/© 2025 InSinkErator. All rights reserved.
262-233-2231
1
DANGER
indicates a hazardous situation
which, if not avoided, will result in
death or serious injury.
WARNING
indicates a hazardous situation
which, if not avoided, could result
in death or serious injury.
CAUTION
indicates a hazardous situation
which, if not avoided,could result in
minor or moderate injury.
N O T I C E
is used to address practices not
related to personal injury.
SAFETY
INSTRUCTIONS
(or equivalent) signs indicate
specific safety-related instructions
or procedures.
80864 Rev B
Advertisement
Table of Contents
Related Manuals for InSinkErator essentials ES30
Summary of Contents for InSinkErator essentials ES30
- Page 1 N O T I C E is used to address practices not related to personal injury. SAFETY INSTRUCTIONS (or equivalent) signs indicate specific safety-related instructions or procedures. ES30 & ES50 Food Waste Disposal 1-800-558-5700 262-233-2231 ®/TM/© 2025 InSinkErator. All rights reserved. 80864 Rev B...
- Page 2 Includes Includes Ring Mounting Gasket Stopper Sink Flange Removable Sink Baffle Fiber Gasket Lower Mounting Ring Backup Flange Dishwasher Inlet Mounting Ring Tailpipe Disposer Screws Flange Discharge Tube Snap Ring Gasket Bolts Tools and Materials (Not Included) Plumber’s putty...
-
Page 3: Before You Begin
Before You Begin IMPORTANT: If connecting a dishwasher, drain plug MUST be removed. See step 15. From Dishwasher Drain Plug Dimensions WARNING Read these instructions carefully. Failure to follow the Installation, Operating and User-Maintenance Instructions may result in personal injury or property damage. -
Page 4: Remove Existing Disposer
Remove existing disposer WARNING SHOCK HAZARD Turn off electric power at circuit breaker or fuse box. If you are replacing an existing disposer, continue to Step 2. If there is no existing disposer, disconnect sink drain and skip to Step 9. Turn off electrical power at circuit breaker or fuse box. - Page 5 Remove existing disposer Is the new disposer mounting the same as the old one? If YES, you may choose to skip to step 15. If NO, continue to step 7. Disconnect the disposer wires from the electrical supply. Using a flathead screwdriver, loosen the 3 Using a flathead screwdriver, pry off the screws on the mounting assembly.
-
Page 6: Install Flange In Sink Hole
Install flange in sink hole Evenly apply 1/2” thick rope of plumber’s Remove flange from sink. Remove old putty around sink flange (B). plumber’s putty from sink with putty knife . NOTICE Property Damage: Risk of long/short term water leakage if not properly assembled. Press sink flange (B) firmly into sink drain. - Page 7 Attach upper mounting assembly Insert fiber gasket (C), backup flange (D) Place a weight, such as the disposer, on and mounting ring (E). Hold in place while the sink flange to hold it in place. Use a inserting snap ring (G). Pull snap ring (G) towel to avoid scratching sink.
- Page 8 Attach upper mounting assembly IMPORTANT: Dishwasher Drain Plug connection only NOTICE If the dishwasher connection is made without removing the plug, the dishwasher may overflow. NOTICE: Drain plug cannot be replaced once it is knocked out. Turn disposer (H) onto side and knock out drain plug with screwdriver.
- Page 9 Connect to electrical supply Feed power cable through metal cable Using wire nuts, connect white (neutral) wires together. Then connect black (hot) connector. wires together. WARNING Improper grounding can result in electric shock hazard. (1) Loosen green ground screw from Tuck wires into lower end frame housing grounding bracket.
- Page 10 Install discharge tube You may need to trim discharge tube (I) to Slide flange (K) over discharge tube (I). ensure proper fit. Insert gasket (J) into discharge outlet. Secure flange and discharge tube to disposer with two bolts (L). Although the supplied discharge tube is preferred, a straight discharge tube may be used.
- Page 11 Connect disposer to mounting assembly with Lift & Latch and Complete Installation ® NOTE BEFORE INSTALLING THE DISPOSAL: Lift & Latch Technology features a lower mounting ring that is fixed with a tab; the lower mounting ring will not turn freely on the disposal. (This is intentional for ease of installation and lifting the disposal with two hands).Tip: Review how the lower mounting ring tabs interact with the ramps on the bottom of the flange prior to install.
- Page 12 Connect disposer to mounting assembly with Lift & Latch and Complete Installation ® Rotate disposer to align with plumbing and To test for leaks, insert (M) into (B), press reconnect plumbing (and dishwasher down evenly until it snaps into place. reconnection if used.) Insert (A) into sink opening, fill sink with water, remove (A) to drain, then look...
-
Page 13: Grounding Instructions
INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, INJURY TO PERSONS OR DAMAGE TO PROPERTY IMPORTANT SAFETY INSTRUCTIONS W A R N I N G W A R N I N G Personal Injury: Do not position your head Improper connection of the equipment-grounding or body under disposer;... -
Page 14: User Maintenance Instructions
OPERATING INSTRUCTIONS 1. Remove stopper from sink opening and run cold water. 2. Turn on disposer. 3. Slowly insert food waste into disposer. WARNING! Position stopper to minimize possible ejection of material while grinding. 4. After grinding is complete, turn disposer off and run water for a few seconds to flush drain line. DO... - Page 15 (b) the date shown on your purchase receipt. subject to the exclusions described below, for the warranty period, commencing on the later of: (a) the date your InSinkErator Manufacturer or its authorized service representative will Product is originally installed, (b) the date of purchase (or...
