PREFACE
This Service Manual describes the
technical features and servicing
procedures for the KYMCO SUPER8 50
Section 1 contains the precautions for all
operations stated in this manual. Read
them carefully before starting any
operation.
Section 2 is the removal/installation
procedures for the frame covers which
are subject to higher removal/installation
frequency during maintenance and
servicing operations.
Section 3 describes the inspection/
adjustment procedures, safety rules and
service information for each part, starting
from periodic maintenance.
Sections 6 through 17 give instructions
for disassembly, assembly and inspection
of engine, chassis frame and electrical
equipment.
Most sections start with an assembly or
system illustration and troubleshooting
for the section. The subsequent pages
give detailed procedures for the section.
Our company reserves the right to make
any alteration in the design.
information and contents included in
this manual may be different from the
motorcycle in case specifications are
changed.
KWANG YANG MOTOR CO., LTD.
OVERSEAS SALES DEPARTMENT
OVERSEAS SERVICE SECTION
The

TABLE OF CONTENTS

SYSTEM
SUPER8 50
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
